HDSP-311x, HDSP- 313x
10.16 mm (0.4 inch) Single Digit General Purpose
Seven Segment Display
Data Sheet
Description
This 10.16 mm (0.4 inch) LED single digit seven segment
display uses industry standard size package and pinout.
The device is available in either common anode or
common cathode. The choice of colors includes High Effi-
ciency Red (HER), Green, AlGaAs Red, and Yellow. The gray
face displays are suitable for indoor use.
Features
Industry standard size
Industry standard pinout
– 10.16 mm (0.4 inch) character height
– DIP lead on 2.54 mm
Choice of colors
– High Efficiency Red (HER), Green, AlGaAs Red, and
Yellow
Excellent appearance
– Evenly lighted segments gray package gives
optimum contrast
– ± 50 ft. viewing angle
Design flexibility
– Common anode right hand decimal point or
common cathode right hand decimal point
Categorized for luminous intensity
– Green and yellow categorized for color
Applications
Suitable for indoor use
Not recommended for industrial application, i.e.,
operating temperature requirements exceeding +85° C
or below -25° C
[1]
Extreme temperature cycling not recommended
Note:
1. For additional details, please contact your local Avago sales office or
an authorized distributor.
Devices
HER
HDSP-311E
HDSP-313E
Green
HDSP-311G
HDSP-313G
AlGaAs Red
HDSP-311A
HDSP-313A
Yellow
HDSP-311Y
HDSP-313Y
Description
Common Anode Right Hand Decimal
Common Cathode Right Hand Decimal
Package Drawing
A
B
Part Numbering System
5 082 - x x x x - x x x xx
H DSP - x x x x - x x x xx
Mechanical Options
[1]
00: No Mechanical Option
Color Bin Options
[1,2]
0: No Color Bin Limitation
Maximum Intensity Bin
[1,2]
0: No Maximum Intensity Bin Limitation
Minimum Intensity Bin
[1,2]
0: No Minimum Intensity Bin Limitation
Device Configuration/Color
[1]
A: AlGaAs Red
E: High Efficiency Red
G: Green
Y: Yellow
Device Specific Configuration
[1]
Refer to Respective Datasheet
Package
[1]
Refer to Respective Datasheet
Notes:
1. For codes not listed in the figure above, please refer to the respective datasheet or contact your nearest Avago representative for details.
2. Bin options refer to shippable bins for a part number. Color and Intensity Bins are typically restricted to 1 bin per tube (exceptions may apply).
Please refer to respective datasheet for specific bin limit information.
