UQQ Series
Wide Input Range Single Output DC/DC Converters
Typical unit
For applications requiring wide range input, improved electrical
and thermal perfomance consider MPS's new UQQ Series “Quarter-
Brick” DC/DC Converters. They measure just .45 x 2.30 x 0.43 inches
(36.8 x 58.4 x 0.92mm) and fit the industry-standard footprint.
PRODUCT OVERVIEW
From an 9-36V or 8-75V input, UQQ’s deliver outputs
of 3.3V, 5V,2V,5V, or 24V. They employ an inter-
leaved, synchronous-rectifier topology that exploits
00% of their duty cycle. They simultaneously achieve
ultra-high efficiency (to 9%), tight line/load regula-
tion, low noise, and quick step response.
A state of the art, single-board, open-frame
design with reduced component count, high efficiency,
low-on-resistance FET’s, and planar magnetics
embedded in heavy-copper pc boards all contribute to
impressive thermal derating.
The UQQ’s feature set includes high isolation, input
pi filters, input undervoltage shutdown, output overvolt-
age protection, current limiting, short-circuit protection
and thermal shutdown. The standard footprint carries
on/off control (positive or negative polarity), output trim
(+0/–20%) and output sense functions.
All UQQ quarter-bricks are designed to meet the
BASIC-insulation requirements of UL/EN/IEC60950-
and they will carry the CE mark. Safety certifications,
EMC compliance testing and qualification testing
(including HALT) are currently in progress. Contact
MPS for latest updates.
FEATURES
n
compliant
RoHS
n
Standard quarter-brick package/pinout in
through-hole version
n
cost; Low profile, 0.43”(0.92mm)
Low
n
9-36V or 8-75V wide range inputs
n
Output current: 4 to 25 Amps
n
Output voltages: 3.3, 5, 2, 5 or 24V
n
Interleaved synchronous-rectifier topology
n
Ultra high efficiency
n
No output reverse conduction
n
Outstanding thermal performance
n
On/off control, trim & sense functions
n
isolated, up to 2250Vdc (BASIC)
Fully
n
Output overvoltage protection
n
I/O protected; Thermal shutdown
Fully
n
UL/EN/IEC60950- safety approvals
n
Designed for RoHS compliance
SIMPLIFIED SCHEMATIC
Typical topology is shown.
For full details go to
www.murata-ps.com/rohs
www.murata-ps.com
Technical enquiries
email: sales@murata-ps.com, tel:
+ 508 339 3000
MDC_UQQ_A03
Page of 7
UQQ Series
Wide Input Range Single Output DC/DC Converters
Performance Specifications and Ordering Guide
➀
PERFORMANCE SPECIFICATIONS AND ORDERING GUIDE
Output
Root Model
UQQ-3.3/25-Q12
UQQ-3.3/25-Q48
UQQ-5/17-Q12
UQQ-5/20-Q48
UQQ-12/8-Q12
UQQ-12/8-Q48
UQQ-15/7-Q12
UQQ-24/4-Q12
V
OUT
(V)
3.3
3.3
5
5
2
2
5
24
I
OUT
(A)
25
25
7
20
8
8
7
4
Power
(Watts)
82.5
82.5
85
00
96
96
05
96
R/N (mVp-p)
Typ.
50
50
40
40
40
95
40
25
Max.
80
00
75
75
75
50
75
70
Line
±0.05%
±0.05%
±0.05%
±0.05%
±0.05%
±0.05%
±0.05%
±0.05%
Regulation
Load
±0.075%
±0.2%
±0.06%
±0.%
±0.05%
±0.%
±0.%
±0.075%
V
IN
Nom.
(Volts)
2
48
2
48
2
48
2
2
Range
(Volts)
9-36
8-75
9-36
8-75
9-36
8-75
9-36
0-36
Input
I
IN
, no load
I
IN
, full load
(mA)
(A)
80
80
50
50
80
70
250
20
7.8
.942
7.83
2.29
8.99
2.3
9.67
8.99
Efficiency
Min.
86%
87%
88.5%
89.5%
87%
87.5%
89%
87.7
Typ.
88%
88.5%
90.5%
9%
89%
89.5%
90.5%
89%
Package
(Case/
Pinout)
C68,P32
C68,P32
C68,P32
C68,P32
C68,P32
C68,P32
C68,P32
C68,P32
Typical at TA = +25°C under nominal line voltage and full-load conditions. All models are
specified with an external 1μF multi-layer ceramic and 10μF capacitors across their output pins
and 100μF external input capacitor.
Ripple/Noise (R/N) measured over a 20MHz bandwidth.
Devices have no minimum-load requirements and will regulate under no-load conditions.
Regulation specifications describe the output voltage deviation as the line voltage or load is
varied from its nominal/midpoint value to either extreme. (Load step = 50%.)
Nominal line voltage, no load/full load condition.
These are incomplete part numbers, refer to the part number structure when ordering.
U QQ
-
5
/
17
-
Q12 N B 9 Lx
-
C
Output Configuration
Quarter-Brick Package
Nominal Output Voltage
Maximum Rated Output
Input Voltage Range
Remote On/Off Control Polarity:
Add "P" for positive polarity
Add "N" for negative polarity
Some model options may require minimum order quantities.
RoHS-6 compliant
(please include this designator for all models)
Pin Length Option
L1
= 0.0 (2.79mm)
Alternate pin lengths
L2
= 0.45 (3.68mm)
require quantity order.
Blank
= Std. pin length
Baseplate Pin 9
(special order):
Note:
9 = Pin 9 installed, connects to baseplate
Not all model number
Blank = No pin 9
combinations are
}
Baseplate:
B = baseplate installed
Blank = no baseplate
available. Contact MPS.
Pin 9 Baseplate Connection
The UQQ series may include an optional installed baseplate for extended
thermal management. This baseplate is electrically isolated from the rest of the
converter. Various UQQ models are also available with an additional pin 9 on
special quantity order which electrically connects to the baseplate. Pin 9 is also
isolated from the rest of the converter. Please refer to the mechanical drawings.
Pin 9 offers a positive method of controlling the electrical potential of the base-
plate, independent of the converter. If you do not include pin 9, the baseplate
may also be grounded by the mounting bolts.
The baseplate may be ordered by adding a “B” to the model number tree
and pin 9 will be pre-installed by adding a “9”. The two options are separate.
Please refer to the Ordering Guide.
Do not order pin 9 without the baseplate.
Note that “pin 9” converters may be on limited forecast, requiring minimum
order quantities and scheduled deliveries.
Please see page 9 for heatsink information.
www.murata-ps.com
D C / D C C O N
+
R
339 3000
Technical enquiries
email: sales@murata-ps.com, tel:
V E
508
T E R S
MDC_UQQ_A03
Page 2 of 7
