SURFACE MOUNT HCMOS/TTL OSCILLATOR
The KFO90AT, a plastic encased surface mount oscillator, maintains
the same land pattern as our FSO series, but with smaller overall
dimensions. This reliable J-leaded component drives up to 10TTL
gates or a 50pF HCMOS load, and offers low current consumption
and tight symmetry.
KFO SERIES
FEATURES
OSCILLATORS
50pF / 10TTL
Industry Standard Footprint
Tri-state Enable/Disable
Fast Rise/Fall Times
Tape and Reel (1,000 pcs. STD)
Available in -40° C to +85° C (KFO90FT)
Available with ±50 PPM stability (KFO95AT)
PARAMETERS
Frequency Range (Fo)
Frequency Stability
Temperature Range
Operating
(T
OPR
)
Storage
Supply Voltage
Input Current
Output Symmetry
Rise Time
Fall Time
Output Voltage
Output Current
Output Load
(T
R
)
(T
F
)
(V
OL
)
(V
OH
)
(I
OL
)
(I
OH
)
(T
STG
)
(V
DD
)
(I
DD
)
FREQUENCY RANGE
1.500 ~ 67.000
MODEL NUMBER SELECTION
Frequency Stability Operating Temperature Frequency Range
(PPM)*
(MHz)
(ºC)
+/-100
1.500 ~ 67.000
-10 ~ +70
+/-100
1.500 ~ 67.000
-40 ~ +85
+/-50
1.500 ~ 67.000
-10 ~ +70
Model Number
KFO90AT
KFO90FT
KFO95AT
ELECTRICAL CHARACTERISTICS (V
DD
= 5.0V, C
L
= 50pF)
CONDITIONS
All Conditions *
MIN
1.500
-100
-50
-10
-40
-55
+4.5
MAX
67.000
+100
+70
+85
+125
+5.5
27
45
60
55
60
7
7
0.5
16
-16
10
50
10
100
UNITS
MHz
PPM
ºC
V
mA
%
nS
V
mA
TTL
pF
mS
nS
OUTPUT (Pin 3)
ACTIVE
ACTIVE
High Z
1.500 ~ 32.000
32.000+ ~ 50.000
50.000+ ~ 67.000
1.500 ~ 50.000
50.000+ ~ 67.000
1.500 ~ 67.000
1.500 ~ 67.000
1.500 ~ 67.000
1.500 ~ 67.000
1.500 ~ 67.000
1.500 ~ 67.000
1.500 ~ 67.000
2.5V
0.5V to 4.5V
4.5V to 0.5V
I
OL
= 16 mA
I
OH
= -16 mA
V
OL
= 0.5 V
V
OH
= 4.5 V
TTL
HCMOS
See Table**
45
40
4.5
* Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging, shock, and vibration.
*** An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.
Note: A 0.01 µF bypass capacitor should be placed between V
DD
(Pin 4) and GND (Pin 2) to minimize power supply line noise.
See page 44 for mechanical specifications, test circuits, and output waveform.
All specifications subject to change without notice. Rev. 03/02/00
Start-up Time
(T
S
)
Enable/Disable Time
ENABLE / DISABLE FUNCTION**
INH (Pin 1)
OPEN ***
'1' Level V
IH
³
2.2 V
'0' Level V
IL
£
0.8 V
All dimensions are in millimeters.
See page 74 for tape and reel specifications.
54
FOXElectronics
5570 Enterprise Parkway
Fort Myers, Florida 33905
941-693-0099
FAX 941-693-1554
http://www.foxonline.com
© 2000 FOX ELECTRONICS
