MAX8559EBAAA+

Description
Fixed Positive LDO Regulator, 2 Output, 3.3V1, 3.3V2, BICMOS, PBGA8, 2.06 X 1.03 MM, LEAD FREE, UCSP-8
CategoryPower/power management    The power supply circuit
File Size236KB,12 Pages
ManufacturerMaxim
Websitehttps://www.maximintegrated.com/en.html
Environmental Compliance
Download Datasheet Parametric Compare View All

MAX8559EBAAA+ Overview

Fixed Positive LDO Regulator, 2 Output, 3.3V1, 3.3V2, BICMOS, PBGA8, 2.06 X 1.03 MM, LEAD FREE, UCSP-8

MAX8559EBAAA+ Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerMaxim
Parts packaging codeBGA
package instructionVFBGA,
Contacts8
Reach Compliance Codecompliant
ECCN codeEAR99
Maximum drop-back voltage 10.12 V
Maximum drop-back voltage 20.12 V
Maximum input voltage6.5 V
Minimum input voltage2.5 V
JESD-30 codeR-PBGA-B8
JESD-609 codee1
length2.02 mm
Humidity sensitivity level1
Number of functions1
Output times2
Number of terminals8
Working temperatureTJ-Max150 °C
Maximum output current 10.3 A
Maximum output current 20.3 A
Maximum output voltage 13.399 V
Minimum output voltage 13.201 V
Nominal output voltage 13.3 V
Maximum output voltage 23.399 V
Minimum output voltage 23.201 V
Nominal output voltage 23.3 V
Package body materialPLASTIC/EPOXY
encapsulated codeVFBGA
Package shapeRECTANGULAR
Package formGRID ARRAY, VERY THIN PROFILE, FINE PITCH
Peak Reflow Temperature (Celsius)260
Certification statusNot Qualified
Regulator typeFIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR
Maximum seat height0.67 mm
surface mountYES
technologyBICMOS
Terminal surfaceTin/Silver/Copper (Sn/Ag/Cu)
Terminal formBALL
Terminal pitch0.5 mm
Terminal locationBOTTOM
Maximum time at peak reflow temperatureNOT SPECIFIED
width1.02 mm
19-3121; Rev 2; 8/05
KIT
ATION
EVALU
BLE
AVAILA
Dual, 300mA, Low-Noise Linear Regulator
with Independent Shutdown in UCSP or TDFN
General Description
The MAX8559 dual, low-noise, low-dropout (LDO) linear
regulator operates from a 2.5V to 6.5V input voltage
and delivers at least 300mA of continuous output cur-
rent. It offers low output noise and low dropout of only
60mV at 100mA. Typical output noise for this device is
32µV
RMS
, and PSRR is 70dB at 10kHz. Designed with
an internal P-channel MOSFET pass transistor, the
MAX8559 maintains a low 115µA supply current per
LDO, independent of the load current and dropout volt-
age. Other features include short-circuit protection and
thermal-shutdown protection. The MAX8559 includes
two independent logic-controlled shutdown inputs and
is capable of operating without a bypass capacitor to
further reduce total solution size. The MAX8559 is avail-
able in a miniature 8-bump UCSP™ (2mm x 1mm) or
8-pin TDFN (3mm x 3mm) package.
Features
Two Low-Dropout-Voltage Regulators
Low 32µV
RMS
Output Noise
300mA Output Current for Each LDO
70dB PSRR at 10kHz
Independent Shutdown Controls
Low 60mV Dropout at 100mA Load
115µA Operating Supply Current per LDO
1.5V to 3.3V Factory-Preset Output
Small Ceramic Output Capacitors
Output Current Limit
Thermal-Overload and Short-Circuit Protection
1.95W Power-Dissipation Capability (TDFN)
2mm
2
Footprint (UCSP)
MAX8559
Ordering Information
Applications
Cellular and Cordless Phones
PDAs and Palmtop Computers
Notebook Computers
Digital Cameras
PCMCIA Cards
Wireless LAN Cards
Handheld Instruments
PART
MAX8559EBAxy*-T
MAX8559EBAxy*+T
MAX8559ETAxy*-T
MAX8559ETAxy*+T
TEMP RANGE
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
PIN-PACKAGE
8 UCSP (B8-1)
8 UCSP (B8-1)
8 TDFN-EP**
8 TDFN-EP**
*xy
= Output voltage code (see the Output Voltage
Selector Guide).
**EP
= Exposed pad.
+Denotes
lead-free package.
Typical Operating Circuit
OUTA
TOP VIEW
Pin Configurations
GND
BP
OUTB
INPUT
2.5V TO 6.5V
2.2μF
min
8
7
6
5
INA
INB
OUTA
1.5V TO 3.3V
2.2μF/150mA
4.7μF/300mA
MAX8559ETA
ON
OFF
ON
OFF
SHDNB
GND
BP
0.01μF
(OPTIONAL)
SHDNA
MAX8559
OUTB
1.5V TO 3.3V
2.2μF/150mA
4.7μF/300mA
INA
2
SHDNA
3
SHDNB
4
INB
TDFN
3mm x 3mm
A "+" SIGN WILL REPLACE THE FIRST PIN INDICATOR ON LEAD-FREE PACKAGES.
Pin Configurations continued at end of data sheet.
UCSP is a trademark of Maxim Integrated Products, Inc.
Output Voltage Selector Guide appears at end of data sheet.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.

MAX8559EBAAA+ Related Products

MAX8559EBAAA+ MAX8559ETA11+ MAX8559ETA88+ MAX8559ETAO1+ MAX8559ETAG2+ MAX8559ETAAJ+ MAX8559ETAAA+ MAX8559ETAJG+ MAX8559EBAJJ+
Description Fixed Positive LDO Regulator, 2 Output, 3.3V1, 3.3V2, BICMOS, PBGA8, 2.06 X 1.03 MM, LEAD FREE, UCSP-8 Fixed Positive LDO Regulator, 2 Output, 1.85V1, 1.85V2, BICMOS, 3 X 3 MM, 0.80 MM HEIGHT, LEAD FREE, MO229/WEEC, TDFN-8 Fixed Positive LDO Regulator, 2 Output, 1.5V1, 1.5V2, BICMOS, 3 X 3 MM, 0.80 MM HEIGHT, LEAD FREE, MO229/WEEC, TDFN-8 Fixed Positive LDO Regulator, 2 Output, 2.6V1, 1.85V2, BICMOS, 3 X 3 MM, 0.80 MM HEIGHT, LEAD FREE, MO229/WEEC, TDFN-8 Fixed Positive LDO Regulator, 2 Output, 3V1, 1.8V2, BICMOS, 3 X 3 MM, 0.80 MM HEIGHT, LEAD FREE, MO229/WEEC, TDFN-8 Fixed Positive LDO Regulator, 2 Output, 3.3V1, 2.85V2, BICMOS, 3 X 3 MM, 0.80 MM HEIGHT, LEAD FREE, MO229/WEEC, TDFN-8 Fixed Positive LDO Regulator, 2 Output, 3.3V1, 3.3V2, BICMOS, 3 X 3 MM, 0.80 MM HEIGHT, LEAD FREE, MO229/WEEC, TDFN-8 Fixed Positive LDO Regulator, 2 Output, 2.85V1, 3V2, BICMOS, 3 X 3 MM, 0.80 MM HEIGHT, LEAD FREE, MO229/WEEC, TDFN-8 Fixed Positive LDO Regulator, 2 Output, 2.85V1, 2.85V2, BICMOS, PBGA8, 2.06 X 1.03 MM, LEAD FREE, UCSP-8
Is it lead-free? Lead free Lead free Lead free Lead free Lead free Lead free Lead free Lead free Lead free
Is it Rohs certified? conform to conform to conform to conform to conform to conform to conform to conform to conform to
Maker Maxim Maxim Maxim Maxim Maxim Maxim Maxim Maxim Maxim
Parts packaging code BGA DFN DFN DFN DFN DFN DFN DFN BGA
package instruction VFBGA, HVSON, SOLCC8,.12,25 HVSON, SOLCC8,.12,25 HVSON, SOLCC8,.12,25 HVSON, HVSON, SOLCC8,.12,25 HVSON, HVSON, VFBGA, BGA8,2X4,20
Contacts 8 8 8 8 8 8 8 8 8
Reach Compliance Code compliant compli compli compli compliant compliant compliant compliant compliant
ECCN code EAR99 EAR99 EAR99 EAR99 EAR99 EAR99 EAR99 EAR99 EAR99
Maximum drop-back voltage 1 0.12 V 0.12 V 0.12 V 0.12 V 0.12 V 0.12 V 0.12 V 0.12 V 0.12 V
Maximum drop-back voltage 2 0.12 V 0.12 V 0.12 V 0.12 V 0.12 V 0.12 V 0.12 V 0.12 V 0.12 V
Maximum input voltage 6.5 V 6.5 V 6.5 V 6.5 V 6.5 V 6.5 V 6.5 V 6.5 V 6.5 V
Minimum input voltage 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
JESD-30 code R-PBGA-B8 S-XDSO-N8 S-XDSO-N8 S-XDSO-N8 S-XDSO-N8 S-XDSO-N8 S-XDSO-N8 S-XDSO-N8 R-PBGA-B8
JESD-609 code e1 e3 e3 e3 e3 e3 e3 e3 e1
length 2.02 mm 3 mm 3 mm 3 mm 3 mm 3 mm 3 mm 3 mm 2.02 mm
Humidity sensitivity level 1 1 1 1 1 1 1 1 1
Number of functions 1 1 1 1 1 1 1 1 1
Output times 2 2 2 2 2 2 2 2 2
Number of terminals 8 8 8 8 8 8 8 8 8
Working temperatureTJ-Max 150 °C 150 °C 150 °C 150 °C 150 °C 150 °C 150 °C 150 °C 150 °C
Maximum output current 1 0.3 A 0.3 A 0.3 A 0.3 A 0.3 A 0.3 A 0.3 A 0.3 A 0.3 A
Maximum output current 2 0.3 A 0.3 A 0.3 A 0.3 A 0.3 A 0.3 A 0.3 A 0.3 A 0.3 A
Maximum output voltage 1 3.399 V 1.9055 V 1.545 V 2.678 V 3.09 V 3.399 V 3.399 V 2.9355 V 2.9355 V
Minimum output voltage 1 3.201 V 1.7945 V 1.455 V 2.522 V 2.91 V 3.201 V 3.201 V 2.7645 V 2.7645 V
Nominal output voltage 1 3.3 V 1.85 V 1.5 V 2.6 V 3 V 3.3 V 3.3 V 2.85 V 2.85 V
Maximum output voltage 2 3.399 V 1.9055 V 1.545 V 1.9055 V 1.854 V 2.9355 V 3.399 V 3.09 V 2.9355 V
Minimum output voltage 2 3.201 V 1.7945 V 1.455 V 1.7945 V 1.746 V 2.7645 V 3.201 V 2.91 V 2.7645 V
Nominal output voltage 2 3.3 V 1.85 V 1.5 V 1.85 V 1.8 V 2.85 V 3.3 V 3 V 2.85 V
Package body material PLASTIC/EPOXY UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED PLASTIC/EPOXY
encapsulated code VFBGA HVSON HVSON HVSON HVSON HVSON HVSON HVSON VFBGA
Package shape RECTANGULAR SQUARE SQUARE SQUARE SQUARE SQUARE SQUARE SQUARE RECTANGULAR
Package form GRID ARRAY, VERY THIN PROFILE, FINE PITCH SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE GRID ARRAY, VERY THIN PROFILE, FINE PITCH
Peak Reflow Temperature (Celsius) 260 260 260 260 260 260 260 260 260
Certification status Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified
Regulator type FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR
Maximum seat height 0.67 mm 0.8 mm 0.8 mm 0.8 mm 0.8 mm 0.8 mm 0.8 mm 0.8 mm 0.67 mm
surface mount YES YES YES YES YES YES YES YES YES
technology BICMOS BICMOS BICMOS BICMOS BICMOS BICMOS BICMOS BICMOS BICMOS
Terminal surface Tin/Silver/Copper (Sn/Ag/Cu) MATTE TIN Matte Tin (Sn) MATTE TIN Matte Tin (Sn) Matte Tin (Sn) Matte Tin (Sn) MATTE TIN Tin/Silver/Copper (Sn/Ag/Cu)
Terminal form BALL NO LEAD NO LEAD NO LEAD NO LEAD NO LEAD NO LEAD NO LEAD BALL
Terminal pitch 0.5 mm 0.65 mm 0.65 mm 0.65 mm 0.65 mm 0.65 mm 0.65 mm 0.65 mm 0.5 mm
Terminal location BOTTOM DUAL DUAL DUAL DUAL DUAL DUAL DUAL BOTTOM
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
width 1.02 mm 3 mm 3 mm 3 mm 3 mm 3 mm 3 mm 3 mm 1.02 mm
Factory Lead Time - 1 week 1 week 1 week 1 week 12 weeks 6 weeks 1 week -
Adjustability - FIXED FIXED FIXED - FIXED - - FIXED
Nominal dropback voltage 1 - 0.06 V 0.06 V 0.06 V - 0.06 V - - 0.06 V
Maximum absolute input voltage - 7 V 7 V 7 V - 7 V - - 7 V
Maximum grid adjustment rate - 0.0126% 0.011% 0.0148% - 0.0153% - - 0.0152%
Maximum operating temperature - 85 °C 85 °C 85 °C - 85 °C - - 85 °C
Minimum operating temperature - -40 °C -40 °C -40 °C - -40 °C - - -40 °C
Encapsulate equivalent code - SOLCC8,.12,25 SOLCC8,.12,25 SOLCC8,.12,25 - SOLCC8,.12,25 - - BGA8,2X4,20
Maximum voltage tolerance - 3% 3% 3% - 3% - - 3%
