Home > Products > Relays > Product Feature Selector > Product Details
ODC15 Product Details
Solid State Relays
Converted to EU RoHS but not ELV Compliant
(
Statement of Compliance
)
Product Highlights:
Relay
Relay Type = Solid State Input/Output Module
ODC Series
Switch Arrangement = 1 Form A (SPSTNO)
Current Rating = 3 A
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
ODC15
(413930281)
TE Internal Number: 413930281
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
View 3D PDF
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
IAC/OAC IDC/ODC Input/Output Modules (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files: (CAD Format & Compression Information)
2D Drawing (DXF, Version 0304)
3D Model (IGES, Version 0304)
3D Model (STEP, Version 0304)
Additional Information:
Product Line Information
Additional Product Images:
Schematic
Wiring Diagram
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Relay
Relay Type = Solid State Input/Output Module
Mechanical Attachment:
Mounting Options = Board Mount
Electrical Characteristics:
Current Rating (A) = 3
Input Voltage (VDC) = 15
Output Type = DC
Output Voltage, Max. (V) = 60
Output Current, Min. (A) = 0.01
Termination Features:
Termination Type = Printed Circuit Terminals
Dimensions:
Approx. Dimensions (L x W x H) (mm [in]) = 43.20 x 15.20 x 31.80
[1.702 x .598 x 1.252]
Body Features:
Case Color = Red
Contact Features:
Switch Arrangement = 1 Form A (SPSTNO)
Output Switching = Random
Coupling = Optical
Housing Features:
Housing Style = Industry Standard
Industry Standards:
RoHS/ELV Compliance = RoHS/Not ELV Compliant
Lead Free Solder Processes = Wave solder capable to 260°C, Wave
solder capable to 240°C
RoHS/ELV Compliance History = Converted to comply with RoHS not
ELV directives
Approved Standards = UL Recognized, CSA Certified
Other:
Series = ODC
Brand = Potter & Brumfield
