TECHNICAL DATA
IN74HC4052
Analog Multiplexer/Demultiplexer
High-Performance Silicon-Gate CMOS
The IN74HC4052 utilise silicon-gate CMOS technology to
achieve fast propagation delays, low ON resistances, and low OFF
leakage currents. These analog multiplexers/demultiplexers control
analog voltages that may vary across the complete power supply
range (from V
CC
to V
EE
).
The Channel-Select inputs determine which one of the Analog
Inputs/Outputs is to be connected, by means of an analog switch, to
the Common Output/Input. When the Enable pin is high, all analog
switches are turned off.
The Channel-Select and Enable inputs are compatible with
standard CMOS outputs; with pull-up resistors, they are compatible
with LS/ALS TTL outputs.
•
Fast Switching and Propagation Speeds
•
Low Crosstalk Between Switches
•
Diode Protection on All Inputs/Outputs
•
Analog Power Supply Range (V
CC
-V
EE
) = 2.0 to 12.0 V
•
Digital (Control) Power Supply Range (V
CC
-GND) = 2.0 to 6.0 V
•
Low Noise
16
1
16
1
D SUFFIX
SOIC
ORDERING INFORMATION
IN74HC4052N
Plastic DIP
IN74HC4052D
SOIC
IZ74HC4052
chip
T
A
= -55° to 125° C for all
packages
PIN ASSIGNMENT
LOGIC DIAGRAM
Double-Pole, 4-Position
Plus Common Off
FUNCTION TABLE
Control Inputs
Enable
B
L
L
L
PIN 16 =V
CC
PIN 7 = V
EE
PIN 8 = GND
L
L
L
H
H
Select
A
L
H
L
H
X
Y0
Y1
Y2
Y3
X0
X1
X2
X3
None
ON
Channels
H
X
H = high level
L = low level
X = don’t care
INTEGRAL
1
IN74HC4052
MAXIMUM RATINGS
*
Symbol
V
CC
V
EE
V
IS
V
IN
I
P
D
Tstg
T
L
*
Parameter
Positive DC Supply Voltage (Referenced to GND)
(Referenced to V
EE
)
Negative DC Supply Voltage (Referenced to GND)
Analog Input Voltage
Digital Input Voltage (Referenced to GND)
DC Input Current Into or Out of Any Pin
Power Dissipation in Still Air, Plastic DIP+
SO Package+
Storage Temperature
Lead Temperature, 1 mm from Case for 10 Seconds
(Plastic DIP or SO Package)
Value
-0.5 to +7.0
-0.5 to +14.0
-7.0 to +0.5
V
EE
- 0.5 to V
CC
+0.5
-1.5 to V
CC
+1.5
±25
750
500
-65 to +150
260
Unit
V
V
V
V
mA
mW
°C
°C
Maximum Ratings are those values beyond which damage to the device may occur.
Functional operation should be restricted to the Recommended Operating Conditions.
+Derating - Plastic DIP: - 10 mW/°C from 65° to 125°C
SO Package: - 7 mW/°C from 65° to 125°C
RECOMMENDED OPERATING CONDITIONS
Symbol
V
CC
V
EE
V
IS
V
IN
V
IO*
T
A
t
r
, t
f
Parameter
Positive Supply Voltage (Referenced to GND)
(Referenced to V
EE
)
Negative DC Supply Voltage (Referenced to GND)
Analog Input Voltage
Digital Input Voltage (Referenced to GND)
Static or Dynamic Voltage Across Switch
Operating Temperature, All Package Types
Input Rise and Fall Time (Channel Select
or Enable Inputs)
(Figure 5)
V
CC
=2.0 V
V
CC
=4.5 V
V
CC
=6.0 V
Min
2.0
2.0
- 6.0
V
EE
GND
-
-55
0
0
0
Max
6.0
12.0
GND
V
CC
V
CC
1.2
+125
1000
500
400
Unit
V
V
V
V
V
°C
ns
*
For voltage drops across the switch greater than 1.2 V (switch on), excessive V
CC
current may be drawn;
i. e., the current out of the switch may contain both V
CC
and switch input components. The reliability of the
device will be unaffected unless the Maximum Ratings are exceeded.
This device contains protection circuitry to guard against damage due to high static voltages or electric
fields. However, precautions must be taken to avoid applications of any voltage higher than maximum rated
voltages to this high-impedance circuit. For proper operation, V
IN
and V
OUT
should be constrained to the range
indicated in the Recommended Operating Conditions..
Unused digital input pins must be tied to an appropriate logic voltage level (e.g., either GND or V
CC
).
Unused Analog I/O pins may be left open or terminated.
INTEGRAL
2
IN74HC4052
DC ELECTRICAL CHARACTERISTICS
Digital Section (Voltages Referenced to GND) V
EE
=GND, Except Where Noted
V
CC
Symbol
V
IH
Parameter
Minimum High-Level
Input Voltage,
Channel-Select or
Enable Inputs
Maximum Low -Level
Input Voltage,
Channel-Select or
Enable Inputs
Maximum Input
Leakage Current,
Channel-Select or
Enable Inputs
Maximum Quiescent
Supply Current
(per Package)
Test Conditions
R
ON
= Per Spec
V
2.0
4.5
6.0
2.0
4.5
6.0
6.0
Guaranteed Limit
-55
°C
to
25°C
1.5
3.15
4.2
0.3
0.9
1.2
±0.1
≤85
°C
1.5
3.15
4.2
0.3
0.9
1.2
±1.0
≤125
°C
1.5
3.15
4.2
0.3
0.9
1.2
±1.0
Unit
V
V
IL
R
ON
= Per Spec
V
I
IN
V
IN
=V
CC
or GND,
V
EE
=-6.0 V
μA
I
CC
Channel Select = V
CC
or
GND
Enable = V
CC
or GND
V
IS
= V
CC
or GND
V
EE
= GND
V
IO
= 0 V
V
EE
= -6.0
V
μA
6.0
6.0
2
8
20
80
40
160
DC ELECTRICAL CHARACTERISTICS
Analog Section
V
CC
Symbol
R
ON
Parameter
Maximum “ON” Resistance
Test Conditions
V
IN
=V
IL
or V
IH
V
IS
= V
CC
to V
EE
I
S
≤
2.0 mA
V
IN
=V
IL
or V
IH
V
IS
= V
CC
or V
EE
(Endpoints)
I
S
≤
2.0 mA
ΔR
ON
Maximum Difference in
“ON” Resistance Between
Any Two Channels in the
Same Package
Maximum Off- Channel
Leakage Current, Any One
Channel
Maximum Off- Channel
Leakage Current, Common
Channel
I
ON
Maximum On- Channel
Leakage Current, Channel
to Channel
V
IN
=V
IL
or V
IH
V
IS
= 1/2 (V
CC
- V
EE
)
I
S
≤
2.0 mA
V
IN
=V
IL
or V
IH
V
IO
= V
CC
- V
EE
Switch Off
V
IN
=V
IL
or V
IH
V
IO
= V
CC
- V
EE
Switch Off
V
IN
=V
IL
or V
IH
Switch to Switch =
V
CC
- V
EE
V
4.5
4.5
6.0
4.5
4.5
6.0
4.5
4.5
6.0
6.0
V
EE
V
0.0
-4.5
-6.0
0.0
-4.5
-6.0
0.0
-4.5
-6.0
-6.0
Guaranteed Limit
25
°C
to
-55°C
190
120
100
150
100
80
30
12
10
0.1
≤85
°C
240
150
125
190
125
100
35
15
12
0.5
≤125
°C
280
170
140
230
140
115
40
18
14
1.0
Ω
Unit
Ω
I
OFF
μA
6.0
-6.0
0.1
1.0
2.0
6.0
-6.0
0.1
1.0
2.0
μA
INTEGRAL
3
IN74HC4052
AC ELECTRICAL CHARACTERISTICS
(C
L
=50pF, Input t
r
=t
f
=6.0 ns)
V
CC
Symbol
t
PLH
, t
PHL
Parameter
Maximum Propagation Delay, Channel-Select to
Analog Output (Figures 1 and 2)
Maximum Propagation Delay , Analog Input to
Analog Output (Figures 3 and 4)
Maximum Propagation Delay , Enable to Analog
Output (Figures 5 and 6)
Maximum Propagation Delay , Enable to Analog
Output (Figures 5 and 6)
Maximum Propagation Delay, Channel-Select to
Analog Input (Figures
5
and
6)
Maximum Input Capacitance, Channel-Select or
Enable Inputs
Maximum Capacitance
Analog
I/O
Common O/I
Feedthrough
Power Dissipation Capacitance (Per Package)
C
PD
Used to determine the no-load dynamic power
consumption:
P
D
=C
PD
V
CC2
f+I
CC
V
CC
All Switches Off
-
-
V
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
-
-
Guaranteed Limit
25
°C
to
-55°C
370
74
63
60
12
10
290
58
49
345
69
59
370
74
63
10
35
≤85°C
465
93
79
75
15
13
364
73
62
435
87
74
465
93
79
10
35
≤125°C
550
110
94
90
18
15
430
86
73
515
103
87
550
110
94
10
35
Unit
ns
t
PLH
, t
PHL
ns
t
PLZ
, t
PHZ
ns
t
PZL
, t
PZH
ns
t
PLZ
, t
PHZ
,
t
PZL
, t
PZH
C
IN
C
I/O
ns
pF
pF
80
1.0
80
1.0
80
1.0
Typical @25°C,V
CC
=5.0 V,
V
EE
=0 V
80
pF
INTEGRAL
4
IN74HC4052
ADDITIONAL APPLICATION CHARACTERISTICS
(GND = 0.0 V)
Symbol
B
W
Parameter
Maximum On-
Channel
Bandwidth or
Minimum
Frequency
Response
Off-Channel
Feedthrough
Isolation
Test Conditions
f
in
=1 MHz Sine Wave
Adjust f
in
Voltage to Obtain 0 dBm at V
OS
Increase f
in
Frequency Until dB Meter
Reads -3 dB
R
L
=50
Ω,
C
L
=10 pF
f
in
= Sine Wave
Adjust f
in
Voltage to Obtain 0 dBm at V
IS
f
in
= 10 kHz, R
L
=600
Ω,
C
L
=50 pF
V
CC
V
V
EE
V
Limit
25
°C
MHz
2.25
4.50
6.00
-2.25
-4.50
-6.00
95
95
95
dB
2.25
4.50
6.00
2.25
4.50
6.00
-2.25
-4.50
-6.00
-2.25
-4.50
-6.00
-50
-50
-50
-40
-40
-40
mVpp
2.25
4.50
6.00
2.25
4.50
6.00
-2.25
-4.50
-6.00
-2.25
-4.50
-6.00
25
105
135
35
145
190
dB
2.25
4.50
6.00
2.25
4.50
6.00
-2.25
-4.50
-6.00
-2.25
-4.50
-6.00
-50
-50
-50
-60
-60
-60
%
2.25
4.50
6.00
-2.25
-4.50
-6.00
0.10
0.08
0.05
Unit
K
Doff
f
in
= 1.0 MHz, R
L
=50
Ω,
C
L
=10 pF
V
AO/I
Feedthrough
Noise, Channel
Select Input to
Common O/I
f
in
≤
1 MHz Square Wave (t
r
= t
f
= 6 ns)
Adjust R
L
at Setup so that I
S
= 0 A
Enable = GND
R
L
=600
Ω,
C
L
=50 pF
R
L
=10
Ω,
C
L
=10 pF
K
Don
Crosstalk
Between Any
Two Switches
f
in
= Sine Wave
Adjust f
in
Voltage to Obtain 0 dBm at V
IS
f
in
= 10 kHz, R
L
=600
Ω,
C
L
=50 pF
f
in
= 1 MHz, R
L
=50
Ω,
C
L
=10 pF
THD
Total Harmonic
Distortion
f
in
= 1 kHz, R
L
=10 kΩ, C
L
=50 pF
THD = THD
Measured
- THD
Source
V
IS
=4.0 V
PP
sine wave
V
IS
=8.0 V
PP
sine wave
V
IS
=11.0 V
PP
sine wave
INTEGRAL
5
