Model IDCP-2218
Vishay Dale
Inductors
High Current, Surface Mount
FEATURES
• High energy storage.
• Low resistance.
• Tape and reel packaging for automatic handling.
ELECTRICAL SPECIFICATIONS
Inductance Range:
10µH to 220µH.
Inductance Tolerance:
20%, 10%.
Operating Temperature:
- 20°C to + 80°C.
Storage Temperature:
- 25°C to 85°C.
Resistance to Solder Heat:
260°C for 10 seconds.
MATERIALS
Core:
Ferrite.
Wire:
Enamelled copper wire.
Terminal:
Ag + Ni + Sn/Pb.
DIMENSIONS
in inches (millimeters)
STANDARD ELECTRICAL SPECIFICATIONS
INDUCTANCE
(
µ
H)
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
120.0
150.0
180.0
220.0
TEST
FREQUENCY
L
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
1KHz
1KHz
1KHz
1KHz
1KHz
DCR
MAXIMUM
(Ohms)
0.10
0.12
0.14
0.15
0.18
0.20
0.23
0.32
0.37
0.42
0.46
0.60
0.70
0.93
1.10
1.38
1.57
RATED
DC
CURRENT*
(A)
1.44
1.40
1.30
1.23
1.11
0.97
0.88
0.80
0.72
0.68
0.61
0.58
0.52
0.48
0.40
0.38
0.35
E
E
D
F
C
A
B
*Rated Current: Value obtained when current flows and the temperature
has risen 40°C or when DC current flows and the
initial value of inductance has fallen by 10%,
whichever is smaller.
ORDERING INFORMATION
IDCP-2218
MODEL
10
µ
H
INDUCTANCE
VALUE
A
B
0.177
±
0.01
[4.5
±
0.35]
E
0.085
[2.15]
C
0.205
±
0.01
[5.2
±
0.3]
F
0.067
[1.7]
±
20%
INDUCTANCE
TOLERANCE
0.229
±
0.01
[5.8
±
0.3]
D
0.217
[5.5]
www.vishay.com
58
Document Number 34096
Revision 04-May-01
