PSMN2R0-60PS

4 October 2012

N-channel 60 V 2.2 mΩ standard level MOSFET in TO-220

Product data sheet

1. Product profile

1.1 General description

Standard level N-channel MOSFET in a TO-220 package qualified to 175 °C. This

product is designed and qualified for use in a wide range of industrial, communications

and domestic equipment.

1.2 Features and benefits

•

High efficiency due to low switching and conduction losses

•

Suitable for standard level gate drive sources

1.3 Applications

•

DC-to-DC converters

•

Load switching

•

Motor control

•

Server power supplies

1.4 Quick reference data

Table 1.

Symbol

tot

DSon

Quick reference data

Parameter

drain-source voltage

drain current

total power dissipation

junction temperature

Conditions

≥ 25 °C; T

≤ 175 °C

= 25 °C; V

= 10 V;

Fig. 1

= 25 °C;

Fig. 2

[1]

Min

-55

Typ

Max

120

338

175

Unit

°C

Static characteristics

drain-source on-state

resistance

= 10 V; I

= 25 A; T

= 25 °C;

Fig. 12

= 10 V; I

= 25 A; T

= 100 °C;

Fig. 12; Fig. 13

Dynamic characteristics

G(tot)

gate-drain charge

total gate charge

= 10 V; I

= 75 A; V

= 30 V;

Fig. 14; Fig. 15

137

192

3.5

mΩ

[2]

1.8

2.2

mΩ

Scan or click this QR code to view the latest information for this product
