Amphenol
D Subminiature Interconnects
DSub SD/G17C Series
Standard Density Right Angle PCB Mount
Most popular Part Numbers noted below.
Both SD and G17C conform to Mil-C-24308.
SD is supplied form Europe while G17C is
supplied from ASIA.
Materials
– Tin plated Steel
– Tin/Lead over Nickel
plated Carbon Steel
Insulator
– 94V-0 thermoplastic
Contacts Pin
– Brass
Contacts Sockets – Phosphor Bronze
Finish
– Gold Flash
Board-locks
– P/B
Screw-locks
– Brass
G17C
Part Number:
G17C0910132
G17C1510132
G17C2510132
G17C3710132
G17C0900132
G17C1500132
G17C2500132
G17C3700132
A
30.84
39.24
53.04
69.32
30.84
39.24
53.04
69.32
Available Upon Request
►
50 Way Versions
►
Various Contact Finishes for durability
»15µ”Au – 125 Cycles/30µ”Au – 250 Cycles
►
Various Footprints
»5mm or 10.4mm or 14.99mm
►
Various Shell Finishes
»Zinc Chromate or Nickel
►
Various Board Mounting Options
»∅3.05mm Clear Hole/4 Claw Board Locks
►
Various Flange Mounting Options
»∅3.05mm Hole/M3 Screw Locks
SD
G17C
Electrical
Current
Voltage
– 5A
– 250VAC/rms 60Hz
– 75 Cycles
SD
Part Number:
717SDE09PA4CH4F
717SDA15PA4CH4F
717SDB25PA4CH4F
717SDC37PA4CH4F
77SDE09SA4CH4F
77SDA15SA4CH4F
77SDB25SA4CH4F
77SDC37SA4CH4F
Mechanical
Durability
Common Parts
Gender
Positions
9 Way
15 Way
25 way
37 Way
9 Way
15 Way
25 way
37 Way
Female
Male
DSub R/A PCB CONNECTOR
Through Hole 2.54mm pitch
FOOTPRINT
C: 8.08mm
D: 5mm
E: 10.4mm
J: 8.08mm Metal backshell w/o boarlocks
NUMBER OF POSITIONS
09: 9 Position
15: 15 Position
25: 25 Position
37: 37 Position
50: 50 Position (G17C only)
CONTACT STYLE
0: Receptacle
CONTACT FINISH
1: Plug
0: Gold Flash
1: 15µ” Gold
2: 30µ” Gold
3: Full gold flash
B
Dimensions (mm)
C
D
16.24
24.56
38.38
54.76
16.24
24.56
38.38
54.76
E
11.09
19.39
33.24
49.86
11.09
19.39
33.24
49.86
For ‘G’ Part Numbers
Suffix
may added.
This
Suffix
is for.
internal use mainly
Additional
Suffix
‘EU’
or ‘LF’ will be added for
RoHS compliant product.
For other Part Numbers
Add
Prefix
‘L’ for RoHS
Compliant product.
Detailed Part Number System
G17X XX XXXXX
FLANGE MOUNTING OPTION
0:
∅3.05mm
clear hole
1: #4-40 threaded hole
2: #4-40 threaded screw-lock
installed
3: #4-40 threaded screw-lock
bulk-packed
4: M3 threaded hole
5: M3 screw-lock installed
7: #4-40 threaded screw-lock
clinch-mounted installed
BOARD MOUNT OPTION
(NOT G17J)
24.99
16.92
33.32
24.70
47.04
38.96
63.50
55.42
24.99
16.92
33.32
24.70
47.04
38.96
63.50
55.42
Common Part Specifications
B±0.05 (.002)
1.42 (.06)
7.9±0.13 (.31±0.005)
A±0.38 (.015)
B±0.13 (.005)
C±0.13 (.005)
D±0.13 (.005)
E±0.05 (.002)
12.55±0.38 (.49±0.015)
E±0.05 (.002)
F±0.1 (.004)
POSITION #1
10°
1.42
8.38±0.13 (.13±0.005)
2-Ø3.2 (.126)
Ø1 (.04)
POSITION #1
POSITION #1
RECOMMENDED PCB LAYOUT
2.8±0.4
(.11±0.016)
SD - 4 Finger Board Lock
G17C - 2 Finger Board Lock
DSub DFR/G17K
Standard Density IDC Terminations for Ribbon Cable
Most popular Part Numbers noted below.
Both DFR and G17K conform to Mil-C-24308.
DFR is supplied form Europe while G17K is
supplied from ASIA.
Materials
DFR
G17K
– Tin plated Steel
– Tin/Lead over Nickel
plated Carbon Steel
Insulator
– 94V-0 thermoplastic
Contacts Pin
– Brass
Contacts Sockets – Phosphor Bronze
Finish
– Gold Flash
Screw-locks
– Brass
G17K
Part Number:
G17K09101021
G17K15101021
G17K25101021
G17K37101021
G17K09001021
G17K15001021
G17K25001021
G17K37001021
Available Upon Request
►
50 Way Versions
►
Various Contact Finishes
»15µ”Au/30µ”Au
►
Insulator Support
►
Various Shell Finishes
»Zinc Chromate or Nickel
►
Various Flange Mounting Options
»∅3.05mm Hole/M3 Screw Locks
Electrical
Current
Voltage
– 5A
– 250VAC/rms 60Hz
Mechanical
Durability
– 75 Cycles
Common Parts
DFR
Gender
Positions
Part Number:
9 Way
17DEFRCA09P
15 Way
17DAFRCA15P
25 way
17DBFRCA25P
37 Way
17DCFRCA37P
9 Way
17DEFRCA09S
15 Way
17DAFRCA15S
25 way
17DBFRCA25S
37 Way
17DCFRCA37S
Detailed Part Number System
G17K XX XXXXX X
DSub PCB CONNECTOR
IDC Termination
NUMBER OF POSITIONS
09: 9 Position
15: 15 Position
25: 25 Position
37: 37 Position
50: 50 Position
CONTACT STYLE
0: Receptacle
1: Plug
CONTACT FINISH
0: Gold Flash
1: 15µ” Gold
FRONT SHELL FINISH
2: 30µ” Gold
0: Zinc chromate
1: Tin/Lead over Nickel
3: Full gold flash
2: Nickel
3: Whole plastic type
STRAIN RELIEF OPTION
0: None
1: With strain relief
A
30.84
39.24
53.04
69.32
30.84
39.24
53.04
69.32
B
Dimensions (mm)
C
24.99
16.92
33.32
24.70
47.04
38.96
63.50
55.42
24.99
16.92
33.32
24.70
47.04
38.96
63.50
55.42
Common Part Specifications
Female
Male
12.55
±0.38
(.494±.015)
7.8 (.307)
A±0.38 (.015)
8.38
±0.13
(.33±.005)
FLANGE MOUNTING OPTION
0:
∅3.05mm
clear hole
1: #4-40 threaded hole
2: #4-40 threaded screw-lock
installed
3: #4-40 threaded screw-lock
bulk-packed
4: M3 threaded hole
5: M3 screw-lock installed
7: #4-40 threaded screw-lock
clinch-mounted
BRACKET OPTION
0: Without insulator support
1: With insulator support
C±0.13 (.005)
D±0.13 (.005)
2.84 (.112)
E±0.05 (.002)
POSITION #1
7.9
±0.13
(.311±.005)
B±0.13 (.005)
4.7 (.185)
17.48 (.688)
5.9
(.232)
6.1
(.240)
17.68 (.696)
6.0
(.236")
10°
Diagrams are typical and specifications may vary
ASF-D/AMTA
2.84 (.112)
Footprint
8.08 (.32)
FRONT SHELL FINISH
0: Zinc chromate
1: Tin/Lead over Nickel
2: Nickel
Flange Mount
#4-40 screwlock
0: None
1:
∅3.05mm
clear hole
2: #4-40 threaded hole
3: Arrowhead board-lock
4: 4 Claw board-lock (G17C only)
6.3 (.25)
3.2 (.126)
Diagrams are typical and specifications may vary
For ‘G’ Part Numbers
Suffix
may added.
This
Suffix
is for.
internal use mainly
Additional
Suffix
‘EU’
or ‘LF’ will be added for
RoHS compliant product.
For other Part Numbers
Add
Prefix
‘L’ for RoHS
Compliant product.
D
16.24
24.56
38.38
54.76
16.24
24.56
38.38
54.76
STRAIN RELIEF
E
11.09
19.39
33.24
49.86
11.09
19.39
33.24
49.86
F-1
