DVGF+283R315TF

Description
DC-DC Regulated Power Supply Module, 3 Output, 12.5W, Hybrid,
CategoryPower/power management    The power supply circuit
File Size308KB,15 Pages
ManufacturerVPT Inc
Download Datasheet Parametric View All

DVGF+283R315TF Overview

DC-DC Regulated Power Supply Module, 3 Output, 12.5W, Hybrid,

DVGF+283R315TF Parametric

Parameter NameAttribute value
MakerVPT Inc
package instruction,
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresIT CAN ALSO OPERATE WITH -15V/3.3V OUTPUT
Analog Integrated Circuits - Other TypesDC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage50 V
Minimum input voltage15 V
Nominal input voltage28 V
JESD-30 codeR-XDMA-P9
Number of functions1
Output times3
Number of terminals9
Maximum output voltage15.45 V
Minimum output voltage14.55 V
Nominal output voltage15 V
Package body materialUNSPECIFIED
Package shapeRECTANGULAR
Package formMICROELECTRONIC ASSEMBLY
Certification statusNot Qualified
Filter levelMIL-PRF-38534
surface mountNO
technologyHYBRID
Terminal formPIN/PEG
Terminal locationDUAL
Maximum total power output12.5 W
Fine-tuning/adjustable outputNO
DVGF+2800T Series
HIGH RELIABILITY HYBRID
DC-DC CONVERTERS
DESCRIPTION
The DVGF series of high reliability DC-DC
converters is operable over the full military (-55 °C to
+125 °C) temperature range with no power derating.
Unique to the DVGF series are robust and effective
input and output filters which provide dramatically
reduced input and output noise performance when
compared to other manufacturers competing
devices. Operating at a nominal fixed frequency of
325 kHz, per stage, these regulated, isolated units
utilize a high speed magnetic feedback design and
well controlled undervoltage lockout circuitry to
eliminate slow start-up problems.
These converters are designed and manufactured in
a facility qualified to ISO9001 and certified to MIL-
PRF-38534 and MIL-STD-883.
This product may incorporate one or more of the
following U.S. patents:
5,784,266
5,790,389
5,963,438
5,999,433
6,005,780
6,084,792
6,118,673
FEATURES
High Reliability
Very Low Output Noise
Wide Input Voltage Range: 15 to 50 Volts per
MIL-STD-704
Up to 12.5 Watts Output Power
Fault Tolerant Magnetic Feedback Circuit
NO Use of Optoisolators
Undervoltage Lockout
Indefinite Short Circuit Protection
Current Limit Protection
Industry Standard Pinout
High Input Transient Voltage: 80 Volts for 1 sec
per MIL-STD-704A
Precision Projection Welded Hermetic Package
High Power Density: > 23 W/in
3
Custom Versions Available
Additional Environmental Screening Available
Meets MIL-STD-461 Revisions C, D, E and F
EMC Requirements When Used With VPT’s
EMI Filters
Flanged and Non-flanged Versions Available.
MIL-PRF-38534 Element Evaluated
Components
Figure 1
– DVGF+2800T / DVGF+2800TF DC-DC Converter
(Exact
marking may differ from that shown)
Sales Information:
Phone: (425) 353-3010
Fax: (425) 353-4030
E-mail: vptsales@vpt-inc.com
DVGF+2800T-4.0
http://www.vpt-inc.com
1
