3.2x2.5mm C-Sine TCXO/VCTCXO
Analog Temperature Compensation
T3AN/T3AV
(former FOX923_A Series)
DATASHEET
ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (MHz)
Temperature Range
Operating (T
OPR
)
Storage
(T
STG
)
Supply Voltage
(V
DD
)
MAX
(unless otherwise noted)
8 ~ 52.000
See table below
-40°C ~ +90°C
1.8V; 2.5V; 2.7V; 2.8V; 3.0V;
3.3V
2.0mA
±2.0 PPM
See table below
±0.2 PPM
±0.2 PPM
0.8Vp-p min
[10kΩ//10pF]+-10%
1
Input Current
(I
DD
)
Initial Frequency Tolerance @ 25°C (after reflow)
(T3AV: Vc = V
DD
/2)
1
Frequency Stability
Over Temperature Range
Over Supply Voltage Change (V
DD
±5%)
Over Load Change [10kΩ//10pF]+-10%
Output Voltage Level
(V
OL
)
Output Load
Pullability (T3AV: Vc = V
DD
±1.0V; T3AVK 0.9V±0.9V)
Aging per year
Startup Time
(T
S
)
Phase Noise
@ 1kHz offset
Reflow Soldering Temp
Moisture Sensitivity Level (MSL)
Termination Finish
Lead-Free
RoHS/REACH Compliant
±3 ~ ±15 PPM
±1.0 PPM
3.0mS
-130 dBc/Hz Typical
260ºC / 10 Seconds x 2
1
Au over Ni
Yes
Yes
Operating Temperature
±1 PPM
±1.5 PPM
±2 PPM
±2.5 PPM
±15 PPM
O
-30 ~+85ºC
-40 ~+85ºC
X
-40 ~+105ºC
Key: O=Available, X=Not Available, NA=Not
1
O
O
O
NA
O
O
O
NA
X
X
X
O
Applicable,
= Consult Fox Engineering
For proper operation, a control voltage (Vc) must be applied to pin 1 of VCTCXO’s.
All specifications subject to change without notice.
Page 1 of 2
Title / Description:
T3AN/T3AV SERIES STANDARD SPECIFICATIONS
Drawing Number: T3AN-T3AV-DOC-2
Size: A
Part Number:
Cage:
61429
Draftsperson: MAJ
Approved: BEC
Revision Date: 05/02/2019
© Copyright 2019 Fox Electronics. All rights reserved
3.2x2.5mm C-Sine TCXO/VCTCXO
Tape Specifications (millimeters)
C
D
E
F
Reel Qty
4.0
3.5
8.0
1.4
-T3 = 3,000 default
-T2 = 2,000
-T1 = 1,000
T3AN/T3AV
(former FOX923_A Series)
DATASHEET
A
Ø1.5
B
4.0
G
2.0
Reel Specifications (millimeters)
H
I
J
K
L
Ø13
Ø21 Ø60 Ø180 9.0
M
1.5
Available Options & Part Identification for TCXO Model T3AN/T3AV
1
F T3AN B P K 25.0
F
FOX
T3AN
Model
Number
B
Voltage
B = +3.3V±5%
D = +3.0V±5%
Q = +2.8V±5%
S = +2.7V±5%
H = +2.5V±5%
K = +1.8V±5%
P
Stability
T = ±1.0 PPM
S = ±1.5 PPM
R = ±2.0 PPM
P = ±2.5 PPM
F = ±15 PPM
K
Operating
Temperature
K = -30 to +85°C
M = -40 to +85°C
P = -40 to +105°C
25.0
Frequency (MHz)
1
Not all frequencies in the frequency range, or every combination of stability, temp range, and voltage available. See stabilities/operating temp table.
Corporate
Headquarters
Sales
Tech Support
5570 Enterprise Parkway
Fort Myers, FL 33905
http://www.FOXONLINE.com
1-888-GET-2-FOX (1-888-438-2369) or
1-239-693-0099
http://www.FOXONLINE.com/repdisty
http://www.FOXONLINE.com/email
PRODUCT USE: Fox Electronics reserves the right to modify the products and/or specifications described herein at any time and at Fox Electronics' sole
discretion. All information in this document, including descriptions of product features and performance, is subject to change without notice. Performance
specifications and the operating parameters of the described products are determined in the independent state and are not guaranteed to perform the same
way when installed in customer products. The information contained herein is provided without representation or warranty of any kind, whether express or
implied, including, but not limited to, the suitability of Fox Electronics' products for any particular purpose, an implied warranty of merchantability, or non-
infringement of the intellectual property rights of others. This document is presented only as a guide and does not convey any license under intellectual
property rights of Fox Electronics or any third parties.
Fox Electronics' products are not intended for use in applications involving extreme environmental conditions or in life support systems or similar devices
where the failure or malfunction of a Fox Electronics product can be reasonably expected to significantly affect the health or safety of users. Anyone using
a Fox Electronics product in such a manner does so at their own risk, absent an express, written agreement by Fox Electronics.
Fox Electronics and the Fox logo are registered trademarks of Fox Electronics. Product specification is subject to change without notice. Other
trademarks and service marks used herein, including protected names, logos and designs, are the property of Fox Electronics or their respective third-
party owners.
Page 2 of 2
Title / Description:
T3AN/T3AV SERIES STANDARD SPECIFICATIONS
Drawing Number: T3AN-T3AV-DOC-2
Size: A
Part Number:
Cage:
61429
Draftsperson: MAJ
Approved: BEC
Revision Date: 05/02/2019
© Copyright 2019 Fox Electronics. All rights reserved
