DR1050 Series
Low Profile Power Inductors
Description
RoHS
2002/95/EC
• 125°C maximum total temperature operation
• Low profile surface mount inductor
• 10.3mm x 10.5mm x 5.0mm shielded drum core
• Ferrite core material
• Inductance range from 0.7µH to 1000µH
• Current range from 13.5 Amps to 0.43 Amps
• Frequency range up to 1MHz
Applications
• Computer, DVD players, and portable power devices
• Notebook power, LCD panels
• DC-DC converters
• Buck, boost, forward, and resonant converters
• Noise filtering and filter chokes
Environmental Data
• Storage temperature range: -40°C to +125°C
• Operating temperature range: -40°C to +125°C
(range is application specific)
• Solder reflow temperature: +260°C max. for 10 seconds
maximum
Part Number
Rated
Inductance
(µH)
0.8
1.5
2.2
3.3
4.7
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
OCL (1)
µH±30%
0.70
1.37
2.27
3.21
4.43
6.30
8.09
10.1
11.6
14.8
17.5
23.5
26.9
34.3
38.3
47.1
56.7
67.2
84.4
97.5
118.3
149.2
183.7
221.8
263.5
320.6
396.5
480.5
572.6
707.9
818.7
1000.2
Irms(2)
Amperes
9.70
8.60
7.52
6.50
6.13
5.45
5.24
4.80
3.94
3.80
3.39
3.12
2.82
2.56
2.35
2.06
1.96
1.84
1.60
1.52
1.30
1.26
1.18
1.00
0.96
0.83
0.76
0.64
0.62
0.56
0.54
0.43
Packaging
• Supplied in tape and reel packaging, 500 per reel
Isat (3)
Amperes
13.50
10.50
9.25
8.20
6.70
5.80
5.00
4.58
4.10
3.70
3.30
3.00
2.80
2.50
2.35
2.10
1.94
1.70
1.58
1.45
1.30
1.15
1.08
0.98
0.90
0.80
0.72
0.62
0.60
0.55
0.50
0.48
DR1050-R80-R
DR1050-1R5-R
DR1050-2R2-R
DR1050-3R3-R
DR1050-4R7-R
DR1050-6R8-R
DR1050-8R2-R
DR1050-100-R
DR1050-120-R
DR1050-150-R
DR1050-180-R
DR1050-220-R
DR1050-270-R
DR1050-330-R
DR1050-390-R
DR1050-470-R
DR1050-560-R
DR1050-680-R
DR1050-820-R
DR1050-101-R
DR1050-121-R
DR1050-151-R
DR1050-181-R
DR1050-221-R
DR1050-271-R
DR1050-331-R
DR1050-391-R
DR1050-471-R
DR1050-561-R
DR1050-681-R
DR1050-821-R
DR1050-102-R
DCR (Ω)
mΩ @20°C
(Typical)
3.2
4.0
5.6
8.0
9.5
13.0
15.1
18.0
24.3
26.0
32.8
38.7
42.6
57.5
60.7
89.0
98.0
111
147
164
223
238
273
377
410
554
648
855
970
1095
1185
1528
DCR (Ω)
mΩ @20°C
(Maximum)
4.0
5.0
6.8
10.0
11.9
16.5
19.0
22.5
30.4
32.5
41.0
48.4
53.3
71.9
75.9
111
123
139
184
205
279
298
341
472
513
693
810
1069
1213
1369
1481
1950
K-factor
(4)
20.47
14.62
11.37
9.30
7.87
6.82
6.02
5.39
4.87
4.45
4.09
3.53
3.30
2.92
2.77
2.50
2.27
2.09
1.86
1.73
1.57
1.40
1.26
1.15
1.06
0.96
0.86
0.78
0.72
0.64
0.60
0.54
(1) Open Circuit Inductance Test Parameters: 100kHz, 0.1V, 0.0Adc.
(2) Irms: DC current for an approximate
∆T
of 40°C without core loss. Derating is
necessary for AC currents. PCB layout, trace thickness and width, air-flow, and
proximity of other heat generating components will affect the temperature rise. It
is recommended that the temperature of the part not exceed 125°C under worst
case operating conditions verified in the end application.
(3) Isat Amperes peak for approximately 35% rolloff (@25°C)
(4) K-factor: Used to determine B p-p for core loss (see graph).
B p-p = K*L*∆I, B p-p(mT), K: (K factor from table), L: (Inductance in µH),
∆I
(Peak to peak ripple current in Amps).
(5) Part Number Definition: DR1050-xxx-R
DR1050 = Product code and size; -xxx = Inductance value in uH;
R = decimal point; If no R is present, third character = # of zeros.
-R suffix = RoHS compliant
DR1050 Series
Low Profile Power Inductors
Temperature Rise vs. Loss
Temperature Rise vs. Total Loss
160.00
140.00
120.00
100.00
80.00
60.00
40.00
20.00
0.00
0.00
Temperature Rise (°C)
0.20
0.40
0.60
Total Loss (W)
0.80
1.00
1.20
Inductance Characteristics
120.0%
OCL vs. I
SAT
100.0%
80.0%
% of OCL
60.0%
40.0%
20.0%
-40 Deg. C
+25 Deg. C
+85 Deg. C
0.0%
0%
20%
40%
60%
80%
100%
120%
140%
% of I
SAT
PM-4139 3/07
© Cooper Electronic
Technologies 2007
Visit us on the Web at www.cooperbussmann.com
1225 Broken Sound Pkwy. Suite F Boca Raton, FL 33487
Tel: +1-561-998-4100 Toll Free: +1-888-414-2645 Fax: +1-561-241-6640
This bulletin is intended to present product design solutions and technical information that will help the end user with design applications. Cooper Electronic
Technologies reserves the right, without notice, to change design or construction of any products and to discontinue or limit distribution of any products. Cooper
Electronic Technologies also reserves the right to change or update, without notice, any technical information contained in this bulletin. Once a product has been
selected, it should be tested by the user in all possible applications.
Life Support Policy: Cooper Electronic Technologies does not authorize the use of any of its products for use in life support devices or systems without the
express written approval of an officer of the Company. Life support systems are devices which support or sustain life, and whose failure to perform, when
properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in significant injury to the user.
