RF Coax Connectors
Introduction
Product Facts
■
Listed under the Component
Program of Underwriters
Laboratories Inc.,
File No. E-81956
as indicated by Product
Family
R
■
Recognized under the
Component Program of
Underwriters
Laboratories Inc.,
File No. E-81956 as
indicated by Product Family
R
The Tyco Electronics
RF Coaxial catalog
combines the best products
from industry leading brand
names like M/A-COM and
AMP. We have integrated
these into one cohesive set
of RF products focused
specifically on wireless,
wireline carrier, and enter-
prise networking sectors of
the world telecom equip-
ment market.
Tyco Electronic’s broadest
selection of RF connectors
and coaxial cable assem-
blies provides you with a
solution for every intercon-
nection requirement.
Type N and 7/16 connec-
tors are used where high
power and rugged reliability
are required, typically as
antenna feeds, filter/
combiner I/O’s, and power
amplifier outputs. SMA,
SMB, and TNC connectors
are the primary cable inter-
face for inner cabinet rout-
ing and are available in
panel mount, board mount,
and cable terminations.
Subminiature connectors
such as MCX, SMP, DIN,
and BlindMate provide
panel to board and back-
plane connections. Finally,
our micro miniature SSMT,
and MMCX series provide
excellent board to board
and card edge to board
solutions.
All of these interfaces are
supported with cable termi-
nating tools and between
series adapters to meet all
your requirements for trou-
ble free terminations at the
lowest applied cost. The
appendices hold a wealth
of information including a
Theory and Application
tutorial, RG/U cable specifi-
cation tables, Application
notes on White Bronze plat-
ing and intermodulation
distortion.
Whether you need rugged
external RF power cables,
panel mount, board to
board, blindmate, or DIN,
Tyco Electronics has the
connection.
