1. To be high saturation for surface mounting type
inductors.
2. Low cost feature.
APPLICATIONS
VTR , QA equipment , LCD television set , nootbook
PC , portable communication equipments , DC to DC
converters , etc.
ORDERING CODE
(1) PRODUCT TYPE CODE AND SIZE CODE
(2) INDUCTANCE
(3) INDUCTANCE TOLERANCE ( K : ±10%, M : ±20% )
(4) REEL TAPING
SHAPE & DIMENSIONS
SIZE CODE
BS0302CDSU
BS0403CDSU
BS0502CDSU
BS0503CDSU
BS0504CDSU
BS0703CDSU
BS0705CDSU
BS1004CDSU
BS1005CDSU
A
±0.3
3.0
4.0
5.2
5.2
5.2
7.0
7.0
9.0
9.0
2.3(max)
3.2±0.3
2.5±0.3
3.0±0.3
4.5±0.3
3.5±0.3
5.0±0.3
4.0±0.3
5.4±0.3
B
C
±0.3
3.5
4.5
5.8
5.8
5.8
7.8
7.8
10.0
10.0
D
Typ.
1.2
1.5
2.0
2.0
2.0
2.5
2.5
2.9
2.9
3.5
4.5
5.5
5.5
5.5
7.5
7.5
9.5
9.5
1.60
2.10
2.25
2.25
2.25
3.05
3.05
3.65
3.65
E
F
UNIT:mm
G
0.8
0.8
1.5
1.5
1.5
1.9
1.9
2.5
2.5
※All
the data listed in this catalogue are for reference only, King Core reserves the right to alter or revise the specifications without prior notification.
KING CORE ELECTRONICS INC.
Tel:886-3-4698855
Fax:886-3-4691395
No.269,Nanfong Rd.,Pingjhen City,Taoyuan County, Taiwan
the data listed in this catalogue are for reference only, King Core reserves the right to alter or revise the specifications without prior notification.
KING CORE ELECTRONICS INC.
Tel:886-3-4698855
Fax:886-3-4691395
No.269,Nanfong Rd.,Pingjhen City,Taoyuan County, Taiwan
E-mail:kc@mail.kingcore.com.tw
Web Site:http://www.kingcore.com.tw
2
BS0502CDSU.A01
SMD POWER INDUCTORS
→
BS0502CDSU SERIES
ELECTRICAL CHARACTERISTIC
ORDERING CODE
BS0502CDSU1R2MT
BS0502CDSU1R5MT
BS0502CDSU1R8MT
BS0502CDSU2R2MT
BS0502CDSU2R7MT
BS0502CDSU3R3MT
BS0502CDSU3R9MT
BS0502CDSU4R7MT
BS0502CDSU5R6MT
BS0502CDSU6R8MT
BS0502CDSU8R2MT
BS0502CDSU100KT
BS0502CDSU120KT
BS0502CDSU150KT
BS0502CDSU180KT
BS0502CDSU220KT
BS0502CDSU270KT
BS0502CDSU330KT
BS0502CDSU390KT
BS0502CDSU470KT
BS0502CDSU560KT
BS0502CDSU680KT
BS0502CDSU820KT
BS0502CDSU101KT
BS0502CDSU121KT
BS0502CDSU151KT
BS0502CDSU181KT
BS0502CDSU221KT
BS0502CDSU271KT
BS0502CDSU331KT
BS0502CDSU391KT
BS0502CDSU471KT
Test Freq.:100KHz/0.1V
Tolerance: K±10%,M±20%
Inductance
(μH)
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
120.0
150.0
180.0
220.0
270.0
330.0
390.0
470.0
Test Frequency
(Hz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DC Resistance
(Ω)max
0.050
0.060
0.065
0.070
0.080
0.100
0.120
0.140
0.150
0.160
0.170
0.200
0.230
0.250
0.300
0.350
0.400
0.500
0.550
0.650
0.750
0.950
1.200
1.400
1.750
2.000
2.600
3.000
3.700
4.300
6.000
6.700
IDC
(A)max
4.20
4.00
3.70
3.50
3.20
2.70
2.40
2.00
1.80
1.50
1.40
1.30
1.10
1.05
1.00
0.90
0.85
0.75
0.70
0.60
0.55
0.50
0.45
0.40
0.35
0.25
0.22
0.20
0.18
0.17
0.16
0.15
