Surface Mount PIN Diode Limiter

LM102202-Q-C-301 Series Datasheet

Features

•

Surface Mount Limiter in Compact Outline:

8mm L x 5mm W x 2.5 mm H

Incorporates PIN Limiter & Schottky Diodes, D.C. Blocks & D.C. Return

Higher Average Power Handling than Plastic ( 100 W C.W. Power )

Lower Insertion Loss ( 0.35 dB ) & Lower Flat Leakage Power ( 17 dBm )

RoHS Compliant

Description

The LM102202-Q-C-301 Surface Mount Silicon PIN Diode Limiter is manufactured using Aeroflex / Metelics

proven hybrid manufacturing process incorporating PIN Diodes and passive devices integrated within a

ceramic substrate. This low profile, compact , surface mount component, ( 8mm L x 5mm W x 2.5 mm H )

offers superior low and high signal performance to comparable MMIC devices in QFN packages. The Limiter

Modules are designed to optimize small signal insertion loss, (N.F.) and high signal flat leakage performance

in a compact, surface mount package.

Using PIN Diodes with lower thermal resistance ( < 15 ºC/W ), and a de-coupled Schottky detector network

as a current source, RF C.W. incident power levels of +50 dBm and RF peak incident power levels of

+60 dBm @ 25 μS RF pulse width, 5% duty cycle are very achievable. In addition, this design concept

provides lower flat leakage power ( < +17 dBm ) and lower spike leakage energy ( < 0.5 Ergs ) for superior

LNA protection. The LM102202-Q-C-301 limiter can be configured without a D.C. block on the output to

obtain lower flat leakage power, (< +10 dBm) with an external ZBD schottky diode. This Limiter Part Number

is LM102202-Q-B-301. Schottky diode P/N in surface mount, 3 terminal plastic package is MZB601-2012.

Applications

These LM102202-Q-C-301 and LM102202-Q-B-301 Limiters are ideal for octave band Radar applications,

from 1-2 GHz, requiring high volume, surface mount, solder re-flow manufacturing. These products are

durable, reliable, and capable of meeting all military, commercial, and industrial environments. The devices

are fully RoHS compliant and are available in tube or tape-reel.

Environmental Capabilities

The LM102202-Q-C-301 and LM102202-Q-B-301 Limiters are capable of meeting the environmental

requirements of MIL-STD-750 and MIL-STD-202.

ESD and Moisture Sensitivity Level Rating

PIN Diode Limiters are susceptible to ESD conditions as with all semiconductors. The ESD rating for this

device is Class 0, HBM. The moisture sensitivity level rating for this device is MSL 2.

Document No. DS13814, Rev. A

Revision Date: 1/14/2011
