Engineering Development Model
Frequency Mixer
Level 10 (LO Power +10 dBm)
Important Note
LOUE-ED3653A/2
This model has been designed, built and tested in our engineering
department. Performance data represents model capability.
At present it is a non-catalog model. On request, we can supply a
final specification sheet, part number and price/delivery information.
Please click "Back", and then click "Contact Us" for Applications support.
CASE STYLE : A01
ELECTRICAL SPECIFICATIONS 50Ω @ +25°C
Parameter
Frequency
LO
(f
L
to f
U
)
RF
(f
L
to f
U
)
IF
mid band
Total Range
Low Range
Mid Range
Upper Range
Low Range
Mid Range
Upper Range
Min.
40
40
10
Typ.
Max.
2500
2500
900
Units
MHz
MHz
MHz
dB
dB
dB
dB
dB
dB
dB
dB
Conversion Loss
LO-RF Isolation
LO-IF Isolation
6.1
6.1
36
33
31
43
33
28
Upper Range = [f
U
/2 to f
U
]
Note:
Low Range = [f
L
to 10f
L
]
mid band = [2f
L
to f
U
/2]
Mid Range = [10f
L
to f
U
/2]
MAXIMUM RATINGS
Operating Temperature
Storage Temperature
-40°C to 85°C
-55°C to 100°C
PIN CONNECTIONS
8
LO
1
RF
3, 4 ^
IF
2, 5, 6, 7
GROUND
^ - pins must be connected together externally
REV. X1
LOUE-ED3653A/2
060620
Page 1 of 1
