Crimzon
®
ZLR64400
8-Bit ROM Microcontroller Family
Universal Remote Control Database
ZiLOG's remote control code database covers the most
popular OEM remote control devices in Europe and North
America. Drawing on over 3,700 device brands, ZiLOG
covers a diverse range of device types including, but not
limited to, TVs, VCRs, DVDs, Cable and Satellite set-top
boxes, HDTV set-top boxes, TV combos, Digital Video
Recorders (DVR), DVD Combos, Receivers, Home-theatre
in-a-box systems, CD Players, Audio shelf systems. You get
the industry's most advanced and complete database from
the #1 leader in universal remote microcontroller technology.
ZDS II Integrated Development
Environment
The Crimzon
®
ICE includes ZiLOG's Developer Studio
(ZDS II) Integrated Development Environment, which reduces
design time, increases developer productivity, and brings
innovative designs to market faster. It also provides an
environment which streamlines code compilation and
development. Tools include a project manager, assembler,
linker, librarian, debugger, and a full ANSI C-compiler at no
extra charge! See for yourself why ZiLOG's development tools
provide an edge over the competition.
The Crimzon
®
ZLR64400 Family
The ZLR64400 ROM MCU is a member of the Crimzon
®
family of infrared-specific microcontrollers. With 1 KB of
general-purpose RAM and up to 64 KB ROM, ZiLOG's
CMOS microcontrollers offer fast executing, efficient use of
memory, UART, sophisticated interrupts, input/output bit
manupulation capabilities, flexible Stop-Mode Recovery
scheme, automated pulse generation/reception, and
internal key-scan pull-up transistors.
A Comprehensive Set of Development
Tools
ZiLOG brings you the finest development tools available to
put the Crimzon
®
ZLR64400 ROM microcontroller family to
work on your designs. Our tools reduce design time and
increase development productivity enabling you to bring
your innovative designs to market faster.
On-Chip Learning
The ZLR64400 ROM microcontroller family features an
"on-chip" ability to learn codes from other infrared remote
controls via a single infrared photodiode. The built-in
IR amplifier with well-tuned gain greatly improves the user
experience with a much wider range (typical 0−8 inches) of
capture distance between the original remote and the
learning remote. In addition, the ZLR64400 ROM MCU's
patented timers (T8/T16) support all infrared signals in the
market and captures an infrared signal with a carrier frequency
of 1 MHz and transmit an infrared signal with a
carrier frequency up to 4MHz.
Available in Multiple Memory Sizes
The ZLR64400 ROM microcontroller is available in 32 KB,
and 64 KB versions. You get the perfect ROM choices at the
best cost for your product designs.
Crimzon
®
ZLR64400 ROM 8-Bit ROM
Microcontroller Family
A Fully-Integrated Development
Environment (IDE) for Complete Design
Control
ZDS II is a complete suite of software tools which supports
development for Z8 microcontroller architecture software.
Combining an easy-to-use Windows-based GUI with
multi-threading capability, ZDS II provides an environment
which streamlines code compilation and development. You
will have all the tools required to develop your innovative IR
solutions, including a language sensitive editor, project
manager, assembler, linker, librarian, debugger, and a full
ANSI C-compiler! Combined with the Crimzon
®
RC In-circuit
Emulator, the Crimzon RC Express
TM
Reference Design,
Crimzon RC Bullet
®
, and Crimzon
®
RC Development
Platform, ZiLOG development tools give you the edge over
your competition.
Power-On
Reset
High-Battery
Voltage Detection
Low-Battery
Voltage Detection
Two
Comparators
Port 0-8 1/O
1 KB
RAM
32/64K
ROM
T8 Timer
Capture and
Transmit
T16 Timer
Capture and
Transmit
8-Bit Timer
with UART
IR Learning
Amplifier
Port 3-8 1/O
Z8 LXM
Core
Watchdog
Timer
Port 2-8 1/O
Crimzon
®
ZLR64400 Block Diagram
Crimzon OTP Microcontroller Features
• 8 MHz Z8 LXM core
• Up to 64 KB of Read only (ROM) memory
• 1 KB of general-purpose RAM
• Infrared learning amplification comparator
• Two comparators
• Infrared dedicated 8-bit and 16-bit capture and
transmit timers
• 8-bit timer with full-duplex UART
• Up to 24 GPlO
• High and Low Voltage Detection flag with IRQ support
• Programmable Watchdog Timer
• Power-On Reset circuits
• Low power consumption
• Three standby modes
- STOP-2
μA
(typical)
- HALT-0.8 mA (typical)
- Low voltage-2.0 V to 3.6 V
• Twenty priority interrupt sources
• Flexible Stop-Mode Recovery (SMR)
• Compatible with ZiLOG Z86L98, ZLP12840, ZLP32300,
ZLR32300, and ZLR16300 products
Development Tools Ordering lnformation
Product Number: ZLP128ICE01ZEMG
Crimzon In-Circuit Emulator
Part Ordering Information
Device
ZLR64400H2864GRXXX
ZLR64400S2864GRXXX
ZLR64400P2864GRXXX
ZLR64400H2064GRXXX
ZLR64400S2064GRXXX
ZLR64400P2064GRXXX
ZLR64400H2832GRXXX
ZLR64400S2832GRXXX
ZLR64400P2832GRXXX
ZLR64400H2032GRXXX
ZLR64400S2032GRXXX
ZLR64400P2032GRXXX
Memory Size
64 KB
64 KB
64 KB
64 KB
64 KB
64 KB
32 KB
32 KB
32 KB
32 KB
32 KB
32 KB
Package Type
(lead-Free)
SSOP
SOIC
PDIP
SSOP
SOIC
PDIP
SSOP
SOIC
PDIP
SSOP
SOIC
PDIP
Order your ZiLOG Development Kits at
http://www.zilog.com
to get your applications
to market in record time.
Crimzon
®
is a tradmark of ZilOG, Irc. in the United States and in other countries. FL012001-0906
