ZLP32300P4004G datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> ZLP32300P4004G

ZLP32300P4004G: DescriptionMicrocontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDIP40, LEAD FREE, PLASTIC, DIP-40; CategoryThe embedded processor and controller Microcontrollers and processors; File Size871KB，99 Pages; ManufacturerZilog, Inc.; Websitehttps://www.zilog.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

ZLP32300P4004G Overview

Microcontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDIP40, LEAD FREE, PLASTIC, DIP-40

ZLP32300P4004G Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Zilog, Inc.
Parts packaging code	DIP
package instruction	DIP, DIP40,.6
Contacts	40
Reach Compliance Code	compliant
Has ADC	NO
Address bus width
bit size	8
CPU series	Z8
maximum clock frequency	8 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	R-PDIP-T40
JESD-609 code	e3
length	52.325 mm
Number of I/O lines	32
Number of terminals	40
Maximum operating temperature	70 °C
Minimum operating temperature
PWM channel	NO
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP40,.6
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	2/3.6 V
Certification status	Not Qualified
RAM (bytes)	256
rom(word)	4096
ROM programmability	OTPROM
Maximum seat height	4.96 mm
speed	8 MHz
Maximum slew rate	10 mA
Maximum supply voltage	3.6 V
Minimum supply voltage	2 V
Nominal supply voltage	3 V
surface mount	NO
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	MATTE TIN
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	15.24 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

Crimzon

ZLP32300

OTP MCU with

Infrared Timers

Product Specification

PS020823-0208

www.zilog.com

Crimzon

ZLP32300

Product Specification

Table of Contents

Architectural Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Development Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Functional Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Pin Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Pin Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

XTAL1 Crystal 1 (Time-Based Input) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

XTAL2 Crystal 2 (Time-Based Output) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Input/Output Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

RESET (Input, Active Low) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Program Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Expanded Register File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Counter/Timer Functional Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Stop Mode Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Watchdog Timer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Low-Voltage Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Expanded Register File Control Registers (0D) . . . . . . . . . . . . . . . . . . . . . . . . 60

Expanded Register File Control Registers (0F) . . . . . . . . . . . . . . . . . . . . . . . . . 65

Standard Control Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Standard Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Capacitance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

DC Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

AC Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Part Number Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

PS020823-0208

Table of Contents

ZLP32300P4004G Related Products

	ZLP32300P4004G	ZLP32300P2004G	ZLP32300H2004G	ZLP32300P2804G	ZLP32300S2004G	ZLP32300H4804G	ZLP32300S2832C	ZLP32300H2804G	ZLP32300S2804G
Description	Microcontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDIP40, LEAD FREE, PLASTIC, DIP-40	Microcontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDIP20, LEAD FREE, PLASTIC, DIP-20	Microcontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDSO20, LEAD FREE, SSOP-20	Microcontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDIP28, LEAD FREE, PLASTIC, DIP-28	Microcontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDSO20, LEAD FREE, SOIC-20	Microcontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDSO48, LEAD FREE, SSOP-48	Microcontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDSO28, SOIC-28	Microcontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDSO28, LEAD FREE, SSOP-28	Microcontroller, 8-Bit, OTPROM, Z8 CPU, 8MHz, CMOS, PDSO28, LEAD FREE, SOIC-28
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	incompatible	conform to	conform to
Maker	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.
Parts packaging code	DIP	DIP	SSOP	DIP	SOIC	SSOP	SOIC	SSOP	SOIC
package instruction	DIP, DIP40,.6	DIP, DIP20,.3	SSOP, SSOP20,.3	DIP, DIP28,.6	SOP, SOP20,.4	SSOP, SSOP48,.4	SOP, SOP28,.4	SSOP, SSOP28,.3	SOP, SOP28,.4
Contacts	40	20	20	28	20	48	28	28	28
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
Has ADC	NO	NO	NO	NO	NO	NO	NO	NO	NO
bit size	8	8	8	8	8	8	8	8	8
CPU series	Z8	Z8	Z8	Z8	Z8	Z8	Z8	Z8	Z8
maximum clock frequency	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz
DAC channel	NO	NO	NO	NO	NO	NO	NO	NO	NO
DMA channel	NO	NO	NO	NO	NO	NO	NO	NO	NO
JESD-30 code	R-PDIP-T40	R-PDIP-T20	R-PDSO-G20	R-PDIP-T28	R-PDSO-G20	R-PDSO-G48	R-PDSO-G28	R-PDSO-G28	R-PDSO-G28
JESD-609 code	e3	e3	e3	e3	e3	e3	e0	e3	e3
length	52.325 mm	25.905 mm	7.2 mm	36.96 mm	12.775 mm	15.875 mm	17.89 mm	10.2 mm	17.89 mm
Number of I/O lines	32	16	16	24	16	32	24	24	24
Number of terminals	40	20	20	28	20	48	28	28	28
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C
PWM channel	NO	NO	NO	NO	NO	NO	NO	NO	NO
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	DIP	SSOP	DIP	SOP	SSOP	SOP	SSOP	SOP
Encapsulate equivalent code	DIP40,.6	DIP20,.3	SSOP20,.3	DIP28,.6	SOP20,.4	SSOP48,.4	SOP28,.4	SSOP28,.3	SOP28,.4
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	SMALL OUTLINE, SHRINK PITCH	IN-LINE	SMALL OUTLINE	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	260	NOT SPECIFIED	260	260	225	260	260
power supply	2/3.6 V	2/3.6 V	2/3.6 V	2/3.6 V	2/3.6 V	2/3.6 V	2/3.6 V	2/3.6 V	2/3.6 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
RAM (bytes)	256	256	256	256	256	256	237	256	256
rom(word)	4096	4096	4096	4096	4096	4096	32768	4096	4096
ROM programmability	OTPROM	OTPROM	OTPROM	OTPROM	OTPROM	OTPROM	OTPROM	OTPROM	OTPROM
Maximum seat height	4.96 mm	4.49 mm	1.98 mm	5.21 mm	2.65 mm	2.79 mm	2.64 mm	1.99 mm	2.64 mm
speed	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz
Maximum slew rate	10 mA	10 mA	10 mA	10 mA	10 mA	10 mA	15 mA	10 mA	10 mA
Maximum supply voltage	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V
Minimum supply voltage	2 V	2 V	2 V	2 V	2 V	2 V	2 V	2 V	2 V
surface mount	NO	NO	YES	NO	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal surface	MATTE TIN	MATTE TIN	MATTE TIN	MATTE TIN	MATTE TIN	MATTE TIN	Tin/Lead (Sn/Pb)	MATTE TIN	MATTE TIN
Terminal form	THROUGH-HOLE	THROUGH-HOLE	GULL WING	THROUGH-HOLE	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	2.54 mm	2.54 mm	0.65 mm	2.54 mm	1.27 mm	0.635 mm	1.27 mm	0.65 mm	1.27 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	40	NOT SPECIFIED	40	40	30	40	40
width	15.24 mm	7.62 mm	5.3 mm	15.24 mm	7.5 mm	7.49 mm	7.5 mm	5.3 mm	7.5 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER
Nominal supply voltage	3 V	3 V	3 V	3 V	3 V	3 V	-	3 V	3 V
