Coaxial
50
Ω
Features
Amplifier
High Power
2W
5 to 500 MHz
• wideband, 5 to 500 MHz
• high power output, +33 dBm min.
• high gain, +29 dB min.
• high IP3, +44 dBm typ.
• good matching VSWR, 1.5:1
ZHL-1-2W
BNC version shown
Applications
CASE
STYLE
T35
Connectors
BNC
SMA
N-TYPE
Model no.
ZHL-1-2W
ZHL-1-2W-S
ZHL-1-2W-N
Price
$ 525.00
$ 535.00
$ 535.00
Qty.
(1-9)
(1-9)
(1-9)
Model no.
ZHL-1-2WX
ZHL-1-2WX-S
ZHL-1-2WX-N
Price
$ 475.00
$ 485.00
$ 485.00
Qty.
(1-9)
(1-9)
(1-9)
• VHF/UHF
• instrumentation
• laboratory
Electrical Specifications
MODEL
NO.
FREQ.
(MHz)
GAIN
(dB)
MAXIMUM POWER
OUTPUT
(dBm)
DYNAMIC
RANGE
VSWR
(:1)
Typ.
DC
POWER
Flatness
f
L
ZHL-1-2W
ZHL-1-2WX*
5
5
f
U
500
500
Min.
29
29
Max.
±1.0
±1.0
(1 dB Compr.)
Min.
+33
+33
Input
(no damage)
+10
+10
NF
(dB)
Typ.
12
12
IP3
(dBm)
Typ.
+44
+44
In
1.5
1.5
Out
1.5
1.5
Volt
(V)
Nom.
24
24
Current
(A)
Max.
0.9
0.9
*Heat
sink not included
Open load is not recommended, potentially can cause damage
With no load derate max input power by 20 dB
Maximum Ratings
Operating Temperature
Storage Temperature
DC Voltage
-20°C to 65°C
-55°C to 100°C
+25V Max.
To order without heat sink, add suffix X to model number. Alternative heat sinking and heat
removal must be provided by the user to limit maximum temperature to 65°C, in order to
ensure proper performance. For reference, this requires thermal resistance of user’s external
heat sink to be 1.0°C/W Max.
Outline Drawing
MOUNTING INFORMATION FOR MODELS WITHOUT HEATSINK
Outline Dimensions (
inch
)
mm
A
B
C
4.75
2.00
2.37
120.65 50.80 60.20
D
E
.19 4.375
4.83 111.13
F
G
.23 1.540
5.84 39.12
H
J
.144
.58
3.66 14.73
K
L
M
N
.34
.50
1.50
1.00
8.64 12.70 38.10 25.40
P
.12
3.05
Q
R
S
T
wt
.38
4.00
1.50
5.0 grams*
9.65 101.60 38.10 127.00
700
*300 grams without heatsink
Mini-Circuits
TM
®
minicircuits.com
REV. A
M121392
ZHL-1-2W
090327
Page 1 of 2
ISO 9001 ISO 14001
AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
IF/RF MICROWAVE COMPONENTS
Typical Performance Data/Curves
ZHL-1-2W
FREQUENCY
(MHz)
GAIN
(dB)
DIRECTIVITY
(dB)
VSWR
(:1)
NOISE
FIGURE
(dB)
24V
POUT
at 1 dB
COMPR.
(dBm)
24V
34.98
35.08
35.42
35.07
34.36
34.34
35.54
34.85
34.71
33.90
23V
5.00
11.30
33.40
98.80
195.40
246.20
309.60
373.10
436.50
500.00
32.84
32.45
32.41
33.72
34.00
33.64
33.47
33.77
33.15
32.49
24V
32.87
32.47
32.42
33.78
34.10
33.73
33.57
33.89
33.35
32.80
24.5V
32.92
32.50
32.45
33.83
34.19
33.84
33.67
34.02
33.54
33.14
23V
25.30
25.90
25.80
24.90
21.90
20.00
17.10
15.90
17.60
22.50
24V
26.00
26.70
23.80
25.40
21.60
19.90
17.70
16.10
17.20
20.60
24.5V
26.10
26.00
24.30
22.60
22.50
19.50
18.00
17.60
17.60
20.80
IN
1.12
1.10
1.16
1.28
1.41
1.45
1.48
1.51
1.56
1.59
OUT
1.51
1.49
1.49
1.43
1.18
1.11
1.19
1.29
1.37
1.57
6.11
6.06
5.63
5.82
5.95
6.09
6.45
6.98
7.28
ZHL-1-2W
GAIN
36
DIRECTIVITY (dB)
ZHL-1-2W
DIRECTIVITY
30
ZHL-1-2W
VSWR
2.0
24.5V
35
GAIN (dB)
23V
24V
24.5V
23V
26
24V
IN
1.8
VSWR
OUT
34
33
32
31
30
0
100
200
300
FREQUENCY (MHz)
400
500
22
18
14
10
0
100
200
300
400
500
FREQUENCY (MHz)
1.6
1.4
1.2
1.0
0
100
200
300
400
500
FREQUENCY (MHz)
ZHL-1-2W
OUTPUT POWER AT 1-dB COMPRESSION
40
OUTPUT POWER (dBm)
NOISE FIGURE (dB)
ZHL-1-2W
NOISE FIGURE
10
9
8
7
6
5
38
36
34
32
30
0
100
200
300
FREQUENCY (MHz)
400
500
0
100
200
300
400
500
FREQUENCY (MHz)
Mini-Circuits
TM
®
minicircuits.com
ISO 9001 ISO 14001
AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
IF/RF MICROWAVE COMPONENTS
Page 2 of 2
