Amplifier
50
Ω
Features
Coaxial
ZHL-2-8
10 to 1000 MHz
Medium High Power
• wideband, 10 to 1000 MHz
• high IP3, +38 dBm typ.
• medium high power, 29 dBm min.
ZHL-2-8X
SMA version shown
ZHL-2-8
Applications
• VHF/UHF
• test equipment
• cellular
• instrumentation
• laboratory
Connectors
BNC
BNC
SMA
SMA
CASE STYLE: T34
Model
Price
ZHL-2-8
$525.00 ea.
ZHL-2-8X
$515.00 ea.
ZHL-2-8-S
$535.00 ea.
ZHL-2-8X-S
$525.00 ea.
Qty.
(1-9)
(1-9)
(1-9)
(1-9)
Electrical Specifications
MODEL
NO.
FREQ.
(MHz)
GAIN
(dB)
MAXIMUM POWER
OUTPUT
(dBm)
DYNAMIC
RANGE
VSWR
(:1)
Max.
DC
POWER
Flatness
ZHL-2-8
ZHL-2-8X*
f
L
10
10
f
U
1000
1000
Min.
27
27
Max.
±1.0
±1.0
(1 dB Compr.)
Min.
+29
+29
Input
(no damage)
+5
+5
NF
(dB)
Typ.
10.0
10.0
IP3
(dBm)
Typ.
+38
+38
In
2.0
2.0
Out
2.0
2.0
Volt
(V)
Nom.
24
24
Current
(A)
Max.
0.6
0.6
* Heat sink not included
Open load is not recommended, potentially can cause damage.
With no load derate max input power by 20 dB
To order without heat sink, add suffix X to model number. Alternative heat sinking and heat
removal must be provided by the user to limit maximum temperature to 65°C, in order to ensure
proper performance. For reference, this requires thermal resistance of user’s external heat sink
to be 1.35°C/W Max.
Maximum Ratings
Operating Temperature
Storage Temperature
DC Voltage
-20°C to 65°C
-55°C to 100°C
+25V Max.
Permanent damage may occur if any of these limits are exceeded.
Outline Drawing
Outline Dimensions
M OUNT I NG I NF OR M A T I ON F OR M ODE L S W I T H OUT H E A T SI NK
Outline Dimensions (
inch
)
mm
A
B
C
4.75
2.00
2.12
120.65 50.80 53.85
D
E
.19 4.375
4.83 111.13
F
G
.23 1.540
5.84 39.12
H
J
.144
.58
3.66 14.73
K
L
M
N
.34
.50
1.50
1.00
8.64 12.70 38.10 25.40
P
.12
3.05
Q
R
S
T
wt
.38
4.00
.30
2.60 grams*
9.65 101.60
7.62 66.04
440.0
*325 grams without heatsink
®
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
For detailed performance specs
& shopping online see web site
TM
Provides ACTUAL Data Instantly at
minicircuits.com
REV. B
M124323
ZHL-2-8
091014
Page 1 of 2
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
Typical Performance Data/Curves
ZHL-2-8
FREQ.
(MHz)
GAIN
(dB)
DIRECTIVITY
(dB)
VSWR
(:1)
NOISE
FIGURE
(dB)
OUT
1.77
1.61
1.58
1.63
1.44
1.21
1.02
1.05
1.18
1.82
FREQ.
(MHz)
POUT
at 1 dB
COMPR.
(dBm)
24V
23V
10.00
22.60
66.80
197.60
390.80
492.30
619.20
746.20
873.10
1000.00
28.91
29.36
29.45
29.47
29.34
29.38
29.39
28.95
29.05
29.06
24V
28.90
29.36
29.44
29.46
29.33
29.37
29.38
28.94
29.03
29.05
24.5V
28.90
29.36
29.44
29.47
29.34
29.37
29.38
28.94
29.03
29.05
23V
32.50
35.40
34.90
31.20
36.40
30.50
28.50
27.60
26.30
21.70
24V
32.50
32.20
28.00
35.30
30.90
34.80
28.70
27.60
24.60
23.10
24.5V
33.90
31.70
34.70
33.00
32.60
32.50
30.80
27.90
25.90
22.20
IN
1.52
1.31
1.26
1.26
1.27
1.28
1.25
1.28
1.50
1.26
24V
6.17
5.73
5.26
5.22
5.27
5.32
5.38
5.51
5.74
6.09
10.00
100.00
200.00
300.00
400.00
500.00
600.00
700.00
800.00
1000.00
30.69
30.76
30.76
30.90
30.91
31.15
31.22
31.37
31.40
31.37
ZHL-2-8
GAIN
35
DIRECTIVITY (dB)
ZHL-2-8
DIRECTIVITY
44
24.5V
33
GAIN (dB)
23V
24V
40
36
32
28
24
20
0
200
23V
24V
24.5V
3.0
2.5
VSWR
ZHL-2-8
VSWR
IN
OUT
31
29
27
25
0
200
400
600
FREQUENCY (MHz)
800
1000
2.0
1.5
1.0
400
600
800
1000
0
200
400
600
800
1000
FREQUENCY (MHz)
FREQUENCY (MHz)
ZHL-2-8
OUTPUT POWER AT 1-dB COMPRESSION
35
OUTPUT POWER (dBm)
NOISE FIGURE (dB)
7.0
6.6
6.2
5.8
5.4
5.0
at 24V
ZHL-2-8
NOISE FIGURE
33
31
29
27
25
0
200
400
600
FREQUENCY (MHz)
800
1000
0
200
400
600
800
1000
FREQUENCY (MHz)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
TM
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
Page 2 of 2
