Coaxial
Frequency Mixer
Level 17 (LO Power +17 dBm)
Maximum Ratings
Operating Temperature
Storage Temperature
RF Power
IF Current
-55°C to 100°C
-55°C to 100°C
200mW
40mA
ZAD-3H+
ZAD-3H
0.05 to 200 MHz
Features
• low conversion loss, 4.89 dB typ.
• good L-R isolation, 45 dB typ., L-I, 40 dB typ.
• rugged shielded case
CASE STYLE: M22
Connectors Model
BNC
ZAD-3H(+)
BRACKET (OPTION “B”)
BRACKET (OPTION “BR”)
Price
$50.95 ea.
$5.00
$1.50
Qty.
(1-9)
(1+)
(1+)
Permanent damage may occur if any of these limits are exceeded.
Applications
• VHF
• FM radio
• instrumentation
Coaxial Connections
LO
RF
IF
1
3
2
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Electrical Specifications
Outline Drawing
FREQUENCY
(MHz)
LO/RF
f
L
-f
U
0.05-200
DC-200
1 dB COMP.: +10 dBm typ.
IF
—
X
4.89
CONVERSION LOSS
(dB)
Mid-Band
m
σ
0.09
Total
Range
Max. Max.
7.0
7.5
L
Typ.
55
LO-RF ISOLATION
(dB)
M
Min.
45
Typ.
45
Min.
30
Typ.
35
U
Min.
25
Typ.
45
L
LO-IF ISOLATION
(dB)
M
Min.
35
Typ.
40
Min.
30
Typ.
30
U
Min.
20
L = low range [f
L
to 10 f
L
]
m= mid band [2f
L
to f
U
/2]
M = mid range [10 f
L
to f
U
/2]
U = upper range [f
U
/2 to f
U
]
Typical Performance Data
Frequency
(MHz)
Conversion
Loss
(dB)
LO
30.05
30.20
31.00
35.00
40.00
50.00
71.42
80.00
99.00
59.68
73.37
80.37
87.26
101.05
107.95
121.74
135.53
149.31
163.10
170.00
LO
+17dBm
5.79
5.33
5.25
5.18
5.36
5.40
5.37
5.37
5.34
5.33
5.34
5.37
5.38
5.40
5.42
5.50
5.66
5.76
5.77
5.75
Isolation
L-R
(dB)
LO
+17dBm
61.52
61.30
61.00
58.85
54.85
48.89
41.07
39.79
39.34
38.45
36.25
35.73
35.17
34.48
33.95
32.91
31.97
31.41
31.62
32.02
Isolation
L-I
(dB)
LO
+17dBm
58.47
55.83
55.41
54.15
51.92
47.33
40.89
39.78
38.19
35.45
36.39
35.84
35.59
35.04
34.10
31.97
30.09
28.67
28.17
28.21
VSWR
RF Port
(:1)
LO
+17dBm
1.22
1.23
1.22
1.21
1.20
1.20
1.19
1.18
1.15
1.15
1.13
1.13
1.11
1.10
1.10
1.11
1.12
1.14
1.17
1.19
VSWR
LO Port
(:1)
LO
+17dBm
2.35
2.27
2.14
2.17
2.19
2.19
2.18
2.27
2.20
2.21
2.14
2.07
2.12
2.15
2.24
2.21
2.17
2.13
2.20
2.23
RF
0.05
0.20
1.00
5.00
10.00
Outline Dimensions (
inch
)
mm
A
2.25
57.15
J
3.25
82.55
B
1.38
35.05
K
.10
2.54
C
1.24
31.50
L
.40
10.16
D
.50
12.70
M
1.15
29.21
E
.150
3.81
N
1.86
47.24
F
3.100
78.74
P
.64
16.26
G
.138
3.51
H
1.238
31.45
20.00
41.42
50.00
69.00
89.68
103.47
110.37
117.26
131.05
137.95
151.74
165.53
179.31
193.10
200.00
S
wt
.150 grams
3.81
74.0
Electrical Schematic
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. A
M98898
ZAD-3H+
DJ/TD/CP/AM
091006
Page 1 of 2
Performance Charts
6.5
CONVERSION LOSS (dB)
at IF Freq of 30 MHz
ZAD-3H+
ZAD-3H
LO=+20 dBm
ZAD-3H
CONVERSION LOSS
LO=+17 dBm
LO=+14 dBm
80
70
ISOLATION (dB)
60
50
40
30
20
10
LO=+14 dBm
ZAD-3H
L-R ISOLATION
LO=+17 dBm
LO=+20 dBm
6.0
5.5
5.0
0
40
80
120
FREQUENCY (MHz)
160
200
0
40
80
120
FREQUENCY (MHz)
160
200
80
70
ISOLATION (dB)
60
50
40
30
20
0
ZAD-3H
L-I ISOLATION
LO=+14 dBm
LO=+17 dBm
LO=+20 dBm
1.5
1.4
VSWR
1.3
1.2
1.1
1.0
ZAD-3H
RF VSWR
LO=+14 dBm
LO=+17 dBm
LO=+20 dBm
40
80
120
FREQUENCY (MHz)
ZAD-3H
LO VSWR
160
200
0
40
80
120
FREQUENCY (MHz)
ZAD-3H
IF VSWR
160
200
4.0
3.5
3.0
VSWR
2.5
2.0
1.5
1.0
0
40
LO=+14 dBm
LO=+17 dBm
LO=+20 dBm
3.0
LO=+14 dBm
2.5
VSWR
2.0
1.5
1.0
LO=+17 dBm
LO=+20 dBm
80
120
FREQUENCY (MHz)
160
200
0
40
80
120
FREQUENCY (MHz)
160
200
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
Page 2 of 2
