Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
1W max.
0.125W max.
Coaxial
ZFSC-2-10G+
ZFSC-2-10G
50Ω
2000 to 10000 MHz
Features
• very wideband, 2000 to 10000 MHz
• low insertion loss, 0.5 dB typ.
• excellent amplitude unbalance, 0.1 dB typ.
• rugged shielded case
CASE STYLE: JJJ142
Connectors Model
SMA
ZFSC-2-10G-S(+)
Price
$69.95
Qty.
(1-9)
Coaxial Connections
SUMPORT
PORT 1
PORT 2
S
1
2
Applications
• instrumenation
• satellite communications
• defense communiations
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Splitter Electrical Specifications
FREQ.
RANGE
(MHz)
f
L
-f
U
2000-10000
L = f
L
to 6 GHz
Outline Drawing
ISOLATION
(dB)
L
U
INSERTION LOSS (dB)
ABOVE 3.0 dB
L
U
PHASE
UNBALANCE
(Degrees)
L
U
Max. Max.
7
12
AMPLITUDE
UNBALANCE
(dB)
L
U
Max. Max.
0.6
0.5
Typ. Min. Typ. Min.
15
9
20
12
Typ. Max. Typ. Max.
0.5
1.5
0.6
1.6
U = 6 GHz to f
U
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
2000
2100
2500
3000
4000
4800
5000
5500
6000
7000
3.56
3.58
3.28
3.50
3.28
3.23
3.31
3.69
3.60
3.79
3.60
3.60
3.91
4.02
3.99
Amplitude
Unbalance
(dB)
0.04
0.02
0.02
0.04
0.08
0.06
0.05
0.06
0.01
0.03
0.03
0.05
0.04
0.04
0.04
Isolation
(dB)
Phase
Unbalance
(deg.)
0.17
0.26
0.59
0.45
0.77
0.92
0.78
1.04
0.66
1.11
0.90
1.30
1.69
1.30
1.70
VSWR
S
VSWR
1
VSWR
2
S-2
3.60
3.61
3.29
3.54
3.36
3.29
3.37
3.75
3.61
3.77
3.57
3.55
3.87
3.98
3.95
11.59
12.13
14.31
17.98
26.34
24.52
23.24
19.67
18.65
20.54
19.11
18.60
14.90
14.21
13.68
1.75
1.74
1.67
1.52
1.13
1.04
1.06
1.17
1.31
1.35
1.30
1.49
1.87
1.93
2.00
ZFSC-2-10G
ISOLATION
30
S-2(dB)
1.41
1.38
1.32
1.28
1.24
1.16
1.13
1.07
1.11
1.18
1.31
1.46
1.45
1.44
1.43
1.39
1.37
1.30
1.28
1.27
1.19
1.16
1.08
1.12
1.17
1.28
1.42
1.40
1.39
1.38
Outline Dimensions (
inch
)
mm
A
B
C
D
1.25
1.25
.75
.63
31.75 31.75 19.05 16.00
G
H
J
.23
.800
.800
5.84 20.32 20.32
K
.23
5.84
E
.38
9.65
F
.32
8.13
wt
grams
70.0
5.0
INSERTION LOSS (dB)
8000
9000
9800
9900
10000
ZFSC-2-10G
INSERTION LOSS
S-1(dB)
ISOLATION (dB)
4000
6000
FREQUENCY (MHz)
4.5
4.0
3.5
3.0
2000
25
20
15
10
2000
8000
10000
4000
6000
FREQUENCY (MHz)
8000
10000
2.50
ZFSC-2-10G
VSWR
#S-VSWR
electrical schematic
#2-VSWR
#1-VSWR
2.00
VSWR
1.50
1.00
2000
4000
6000
FREQUENCY (MHz)
8000
10000
REV. A
M107161
ZFSC-2-10G
HY/TD/CP
060901
