Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
10W max.
0.125W max.
Coaxial
ZN2PD-1900W+
ZN2PD-1900W
50Ω
1500 to 2000 MHz
Features
• low insertion loss, 0.2 dB typ.
• good isolation, 24 dB typ.
• up to 10W power input as a splitter
• excellent amplitude unbalance, 0.1 dB typ.
• excellent phase unbalance, 0.2 deg. typ.
• excellent VSWR, 1.1:1 typ.
• rugged shielded case
CASE STYLE: VVV180
Connectors Model
Price
SMA
ZN2PD-1900W-S(+) $64.95
Qty.
(1-9)
Coaxial Connections
SUMPORT
PORT 1
PORT 2
S
1
2
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Applications
• PCS/DCS
• GPS
• communications systems
• instrumentations
FREQ.
RANGE
(MHz)
f
L
-f
U
1500-2000
Splitter Electrical Specifications
INSERTION LOSS (dB)
PHASE
AMPLITUDE
ABOVE 3.0 dB
UNBALANCE UNBALANCE
(Degrees)
(dB)
S
Typ. Max.
0.2
0.5
Max.
3
Max.
0.3
Outline Drawing
ISOLATION
(dB)
VSWR
(:1)
OUT
Typ. Max.
1.04 1.20
Typ. Min.
24
15
Typ. Max.
1.20 1.50
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
1500.00
1525.00
1550.00
1575.00
1612.50
3.04
3.08
3.15
3.09
3.06
3.09
3.05
3.07
3.06
3.08
3.05
3.09
3.07
3.10
3.10
Amplitude
Unbalance
(dB)
0.00
0.00
0.01
0.00
0.00
0.00
0.01
0.01
0.01
0.00
0.01
0.00
0.00
0.02
0.02
Isolation
(dB)
Phase
Unbalance
(deg.)
0.09
0.16
0.13
0.09
0.16
0.11
0.18
0.12
0.13
0.18
0.11
0.22
0.23
0.23
0.19
VSWR
S
VSWR
1
VSWR
2
S-2
3.04
3.09
3.14
3.09
3.06
3.09
3.05
3.08
3.07
3.09
3.06
3.09
3.07
3.12
3.12
22.90
23.96
25.18
26.64
29.24
32.93
38.23
39.45
35.77
32.58
28.01
25.05
22.78
21.05
20.25
1.13
1.11
1.09
1.08
1.05
1.03
1.00
1.02
1.04
1.06
1.09
1.13
1.17
1.20
1.23
1.12
1.12
1.12
1.12
1.11
1.11
1.11
1.11
1.11
1.11
1.12
1.12
1.13
1.15
1.16
1.12
1.12
1.12
1.12
1.12
1.12
1.12
1.12
1.12
1.12
1.13
1.13
1.14
1.16
1.16
Outline Dimensions (
A
B
C
1.80
1.75
.66
45.72 44.45 16.76
H
1.625
41.28
D
E
.125 1.675
3.18 42.55
inch
mm
)
G
.125
3.18
wt
grams
34
F
.125
3.18
1650.00
1687.50
1725.00
1750.00
1775.00
1825.00
1875.00
1925.00
1975.00
2000.00
J
K
L
M
.31
.63
1.13
.88
7.87 16.00 28.70 22.35
ZN2PD-1900W
INSERTION LOSS
3.25
INSERTION LOSS (dB)
S-1(dB)
S-2(dB)
ZN2PD-1900W
ISOLATION
45
40
ISOLATION (dB)
35
30
25
20
3.20
3.15
3.10
3.05
3.00
1500
1600
1700
1800
1900
2000
15
1500
1600
1700
1800
1900
2000
FREQUENCY (MHz)
FREQUENCY (MHz)
ZN2PD-1900W
VSWR
1.3
1.3
1.2
VSWR
1.2
1.1
1.1
1.0
1500
1600
1700
1800
1900
2000
#S-VSWR
#1-VSWR
#2-VSWR
electrical schematic
FREQUENCY (MHz)
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
minicircuits.com
REV. A
M106921
ZN2PD-1900W
HY/TD/CP/AM
070424
EW
ALL N
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
