OA109 Series
AC Fan - 115V, 230V, Dual Voltage
120x38mm (4.7”x 1.5”)
Frame
Impeller
Connection
Motor
Bearing System
Insulation Resistance
Dielectric Strength
Diecast Aluminum
PBT, UL94V-O plastic
2x 300mm Lead wires or
terminals
AC shaded pole, impedance
and thermally protected
Dual ball or Sleeve
Operating Temperature
Ball Bearing
-20C ~ +80C
Sleeve Bearing
-10C ~ +50C
Life Expectancy
Ball Bearing
60,000 hours (L10 at 40C)
Sleeve Bearing
30,000 hours (L10 at 40C)
Dual Voltage
Fans can be configured to
run on 115V or 230V.
Connection via 4x leads
10M ohm between leadwire
and frame (500VDC)
1 min at 1500 VAC, 50/60Hz
Model Number
OA109AP-11-1*
OA109AP-11-2*
OA109AP-11-3*
OA109AP-22-1*
OA109AP-22-2*
OA109AP-22-3*
OA109AP-11/22-1W**
OA109AP-11/22-2W**
OA109AP-11/22-3W**
Speed (RPM) Airflow (CFM)
3000
2300
1600
3000
2300
1600
3000
2300
1600
110
71
51
71
51
110
71
51
110
Noise (dB)
37
30
25
37
30
25
37
30
25
Volts AC
115
115
115
230
230
230
115/230
115/230
115/230
Voltage Range
80~130
80~130
160~260
160~260
160~260
80~260
80~260
80~260
80~130
Watts
15
11
15
11
8
15
11
8
8
Max. Static
Pressure (“H2O)
.28
.24
.15
.28
.24
.15
.28
.24
.15
* Indicate “TB” (Terminal Ball Bearing), “WB” (12” Wire Leads, Ball Bearing), “TS” (Terminal, Sleeve Bearing), “WS” (12” Wire Leads, Sleeve Bearing)
** Indicate “B” (Ball Bearing) or “S” (Sleeve Bearing)
10557 Metric Drive
Dallas, Texas 75243
214-340-0265
RoHS Compliant
Information and data is subject to
change without prior notification.
OrionFans.com
