3549H-1BB-503A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 3549H-1BB-503A

3549H-1BB-503A: DescriptionRESISTOR, POTENTIOMETER, HYBRID, 10 TURN(S), 2 W, 1000 ohm; CategoryPassive components The resistor; File Size538KB，5 Pages; ManufacturerBourns; Websitehttp://www.bourns.com; Environmental Compliance; Related ProductsFound18parts with similar functions to 3549H-1BB-503A

Download Datasheet Parametric View All

3549H-1BB-503A Overview

RESISTOR, POTENTIOMETER, HYBRID, 10 TURN(S), 2 W, 1000 ohm

3549H-1BB-503A Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Bourns
package instruction	Panel Mount,
Reach Compliance Code	_compli
ECCN code	EAR99
Actuator direction	HORIZONTAL
Actuator type	SHAFT
structure	Round
gang number	1
JESD-609 code	e4
Installation features	PANEL MOUNT
Number of terminals	3
number of turns	10
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package diameter	22.479 mm
Package length	19.812 mm
Package shape	CIRCULAR PACKAGE
Package form	Panel Mou
method of packing	TRAY
Rated power dissipation(P)	2 W
Rated temperature	70 °C
resistance	50000 Ω
resistance law	LINEAR
Resistor type	POTENTIOMETER
rotation angle	3600 deg
surface mount	NO
technology	HYBRID
Temperature Coefficient	-100,100 ppm/°C
Terminal surface	Gold (Au) - with Nickel (Ni) barrie
Terminal shape	LUG
Tolerance	10%

Preview

Download Datasheet

View All

Features

■

Wirewound and Hybritron

elements

■

High rotational life

■

Optional 0.1 % linearity

■

Optional A/R lug

■

RoHS compliant*

■

Suitable for use under some side load

■

Designed for HMI and MMI applications

■

Dual gang option

■

Servo mount option

■

Dual ball bearing option

conditions

3549 - 10-Turn Precision Potentiometer

Electrical Characteristics

Wirewound Element

Hybritron

Element

Standard Resistance Range..................................................................100 to 100K ohms ..................................................1K to 100K ohms

Total Resistance Tolerance....................................................................±3 % .......................................................................±10 %

Independent Linearity ............................................................................±0.2 % ....................................................................±0.2 %

Independent Linearity (Maximum Practical) ..........................................±0.1 % ....................................................................±0.1 %

Effective Electrical Angle .......................................................................3600 ° +10 °, -0 °....................................................3600 ° +10 °, -0 °

Absolute Minimum Resistance/End Voltage ..........................................1 ohm or 0.1 % maximum ......................................0.2 % maximum

(whichever is greater)

Noise/Output Smoothness ....................................................................100 ohms maximum ...............................................0.10 % maximum

Max. Wiper Current @ 5K ohms ...........................................................20 mA ..................................................................... 10 mA

Dielectric Withstanding Voltage (MIL-STD-202, Method 301)

Sea Level ...........................................................................................1,000 VAC minimum .............................................. 1,000 VAC minimum

Insulation Resistance (500 VDC) ..........................................................1,000 megohms minimum ...................................... 1,000 megohms minimum

Resolution..............................................................................................See How to Order chart ........................................ Essentially inﬁnite

Power Rating (Voltage Limited By Power Dissipation)

+70 °C................................................................................................2 watts .................................................................... 2 watts

+125 °C..............................................................................................0 watt...................................................................... 0 watt

Environmental Characteristics

Operating Temperature Range

Dynamic .............................................................................................-40 °C to +125 °C ................................................... -40 °C to +125 °C

Static ..................................................................................................-55 °C to +125 °C ................................................... -55 °C to +125 °C

Temperature Coefﬁcient (Over Static Temperature Range) ..................±50 ppm/°C ............................................................ ±100 ppm/°C

Temperature Cycling (5 Cycles Over Static Temperature Range) .........±2 % TR shift max. ................................................. ±4 % TR shift max.

Vibration (15 Gs, 10 Hz to 2 kHz)

Wiper Bounce ....................................................................................0.1 ms max............................................................. 0.1 ms max.

Shock (100 Gs, 6 ms sawtooth)

Wiper Bounce ....................................................................................0.1 ms max............................................................. 0.1 ms max.

Load Life (1,000 hours @ 70 °C)...........................................................±2 % TR shift .......................................................... ±5 % TR shift max.

Rotational Life

No Load or Powered ..........................................................................2,000,000 shaft revolutions .................................... 5,000,000 shaft revolutions

No Load or Powered (Dual Ball Bearing) ..........................................N/A ......................................................................... 10,000,000 shaft revolutions

Moisture Resistance (Mil-Std-202, Method 103) ...................................±2 % TR shift max. ................................................. ±5 % TR shift max.

IP Rating ................................................................................................IP 50 ....................................................................... IP 50

Mechanical Characteristics

Mechanical Angle ...........................................................................................................................................................................................3600 ° +10 °, -0 °

Backlash .................................................................................................................................................................................................................... 1.0 ° max.

Stop Strength.......................................................................................................................................................................................53 N-cm (75 oz-in.) min.

Torque

Starting ........................................................................................................................................................................................0.5 N-cm (0.7 oz.-in.) max.

Running .......................................................................................................................................................................................0.5 N-cm (0.7 oz.-in.) max.

Clutch................................................................................................................................................................................1.0 to 4.2 N-cm (1.5 to 6.0 oz.-in.)

Mounting .......................................................................................................................................................................... 170-200 N-cm (15-18 in.-lb.) max.

Shaft Runout T.I.R. ..................................................................................................................................................................................... 0.08 mm (0.003 in.)

Lateral Runout T.I.R.................................................................................................................................................................................... 0.13 mm (0.005 in.)

Shaft End Play T.I.R. .................................................................................................................................................................................. 0.15 mm (0.006 in.)

Shaft Radial Play T.I.R................................................................................................................................................................................ 0.08 mm (0.003 in.)

Pilot Diameter Runout T.I.R. ....................................................................................................................................................................... 0.08 mm (0.003 in.)

Weight

Single ...................................................................................................................................................................................................... 20 gm (0.7 oz.) typ.

Dual ....................................................................................................................................................................................................... 36 gm (1.27 oz) typ.

Shaft Side Load (Max. Allowable)

Nickel Plated Brass Shaft w/Brass Bushing ................................................................................................................................................. 50 gmf (1.7 ozf)

Stainless Steel Shaft w/Bronze Bushing .................................................................................................................................................... 250 gmf (8.8 ozf)

Terminals .............................................................................................................................................................................................. Gold-plated solder lugs

Soldering Condition

Manual Soldering ........................................................... 96.5Sn/3.0Ag/0.5Cu solid wire or no-clean rosin cored wire, 370 °C (700 °F) max. for 3 seconds

Wave Soldering ...................................................................................96.5Sn/3.0Ag/0.5Cu solder with no-clean ﬂux, 260 °C (500 °F) max. for 5 seconds

Wash processes .......................................................................................................................................................................................Not recommended

Mounting Hardware ............................................................................................. One lockwasher and one mounting nut is shipped with each potentiometer

Recommended Panel Thickness (Bushing Mount) ..................................................................................................................2.46-3.81 mm (0.097-0.150 in.)

Marking ...........................................................................................................................Manufacturer’s symbol, model number, product code and date code

Standard Packaging ........................................................................................................................................................................... Plastic trays (5 pcs./tray)

At room ambient: +25 °C nominal and 50 % relative humidity nominal, except as noted.

For other options, please consult factory.

*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.

Speciﬁcations are subject to change without notice.

The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.

Users should verify actual device performance in their speciﬁc applications.
