85759-9202: DescriptionBoard Connector, 96 Contact(s), 4 Row(s), Female, Straight, Press Fit Terminal, Receptacle; CategoryThe connector The connector; File Size163KB，2 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/

Download Datasheet Parametric Compare View All

85759-9202 Overview

Board Connector, 96 Contact(s), 4 Row(s), Female, Straight, Press Fit Terminal, Receptacle

85759-9202 Parametric

Parameter Name	Attribute value
Maker	Amphenol
Objectid	1536718794
Reach Compliance Code	compliant
compound_id	54686435
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact completed and terminated	TIN LEAD
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e0
MIL compliance	NO
Manufacturer's serial number	85759
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	4
Options	GENERAL PURPOSE
Terminal pitch	2 mm
Termination type	PRESS FIT
Total number of contacts	96
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

85759-9202 Related Products

	85759-9202	85759-9201	85759-9302	85759-9101	85759-9102	85759-9301
Description	Board Connector, 96 Contact(s), 4 Row(s), Female, Straight, Press Fit Terminal, Receptacle	Board Connector, 96 Contact(s), 4 Row(s), Female, Straight, Press Fit Terminal, Receptacle	Board Connector, 96 Contact(s), 4 Row(s), Female, Straight, Press Fit Terminal, Receptacle	Board Connector, 96 Contact(s), 4 Row(s), Female, Straight, Press Fit Terminal, Receptacle	Board Connector, 96 Contact(s), 4 Row(s), Female, Straight, Press Fit Terminal, Receptacle	Board Connector, 96 Contact(s), 4 Row(s), Female, Straight, Press Fit Terminal, Receptacle
Maker	Amphenol	Amphenol	Amphenol	Amphenol	Amphenol	Amphenol
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant
Body/casing type	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE
Connector type	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR
Contact point gender	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
DIN compliance	NO	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO
MIL compliance	NO	NO	NO	NO	NO	NO
Mixed contacts	NO	NO	NO	NO	NO	NO
Installation method	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of rows loaded	4	4	4	4	4	4
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Terminal pitch	2 mm	2 mm	2 mm	2 mm	2 mm	2 mm
Termination type	PRESS FIT	PRESS FIT	PRESS FIT	PRESS FIT	PRESS FIT	PRESS FIT
Total number of contacts	96	96	96	96	96	96
UL Flammability Code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
Contact completed and terminated	TIN LEAD	TIN LEAD	TIN LEAD	-	TIN LEAD	TIN LEAD
JESD-609 code	e0	e0	e0	-	e0	e0
Manufacturer's serial number	85759	85759	85759	-	85759	85759
