VX-509
Hi-Reliability Voltage Controlled Crystal Oscillator
VX-509
Features
•
•
•
•
•
•
9x14 J Leaded Surface Mount Package
4 Point Crystal Mount / Swept Quartz
3
Class S Screening IAW MIL-PRF-55310
100 krad Total Dose Radiation Tolerance
3
Frequency Range: 1 MHZ to 85 MHZ
Previous Model: 5116
Applications
• Mil/Space Applications
• Satellite Applications
• Rad Hard Environments
Performance Speci cations
Parameter
vs. operating temperature range
(absolute pull range)
Min
-30
-30
-30
-50
-50
-50
Typ
Max
+30
+30
+30
+50
+50
+50
Units
ppm
ppm
ppm
ppm
ppm
ppm
Condition
0… +70°C
-20… +70°C
-40… +85°C
0… +70°C
-20… +70°C
-40… +85°C
Frequency Stabilities
1
Supply Voltage (Vs)
Supply voltage
Current consumption (no load)
Supply voltage
3.135
3.3
4.75
5.0
5.25
15
20
40
3.465
6
8
12
16
RF Output
Signal
Load
Signal Level (Vol)
15
ACMOS
50
0.5
0.3
pF
VDC
VDC
Vs= 5.0V and 15pF load
Vs= 3.3V and 15pF load
VDC
mA
mA
mA
VDC
mA
mA
mA
mA
1.0 to 14.9 MHZ
15.0 TO 39.9 MHz
40.0 TO 59.9 MHz
60.0 TO 85.0 MHz
1.0 to 23.9 MHZ
24 to 49.9 MHz
50 to 85.0 MHz
Current consumption (no load)
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Performance Speci cations
Parameter
Signal Level (Voh
Rise and fall times for ACMOS
(measured 10% to 90%)
Duty cycle
45
40
Min
4.5
3.0
Typ
Max
Units
VDC
VDC
Condition
Vs= 5.0V and 15pF load
Vs= 3.3V and 15pF load
1.0 to 23.9 MHz
24.0 to 85.0 MHz
@ 50% Vs < 15 MHz
@ 50% Vs >= 15 MHz
10
5
55
60
ns
ns
%
%
Frequency Tuning (EFC)
Linearity
Tuning Slope
Control Voltage Range
0.5
0.3
2.5
1.65
10
15
Positive
4.5
3.0
VDC
VDC
with Vs=5.0VDC
with Vs=3.3VDC
%
Additional Parameters
-60
-90
-120
-140
-145
<2.0
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
g
10 Hz
100 Hz
1 KHz
10 KHz
100 KHz
Phase Noise
3
(@ 52 MHz)
Weight
Absolute Maximum Ratings
Supply voltage (Vs)
Operable temperature range
Storage temperature range
-55
-55
7.0
+85
+125
Screening Level
Class S Screening
Class B Screening
Engineering Model
IAW MIL-PRF-55310
IAW MIL-PRF-55310
No Screening
V
°C
°C
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Outline Drawing / Enclosure
Type B
Code
0
Height “H”
0.188”
Stand-o
0.043”
Pin Connections
1
2
3
4
VCXO input
Ground (Case)
RF Output
Supply
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Ordering Information
VX - 509 0 - D A J - K X S X - 10M0000000
Frequency
Product Family
VX: VCXO
Package
9 x 14 mm
Height
0: B0.188”
Supply Voltage
D: 5 Vdc
E: 3.3 Vdc
RF Output Code
A: ACMOS
Pullability Code
G: ±30ppm
K: ±50ppm
Option Code
X: No Option
Screening Option
S: “S” Level Screening
B: “B” Level Screening
X: No Screening
Enable:
X: No Enable
Temperature Range
E: -40… +85°C
J: -20… +70°C
T: 0… +70°C
Notes:
1. Contact factory for improved stabilities or additional product options. Not all options and codes are available at all
frequencies.
2. Unless other stated all values are valid after warm-up time and refer to typical conditions for supply voltage, frequency
control voltage, load, temperature (25°C).
3. Phase noise degrades with increasing output frequency.
4. Subject to technical modi cation.
5. Contact factory for availability.
For Additional Information, Please Contact
USA:
Vectron International
267 Lowell Road
Hudson, NH 03051
Tel: 1.888.328.7661
Fax: 1.888.329.8328
Europe:
Vectron International
Landstrasse, D-74924
Neckarbischofsheim, Germany
Tel: +49 (0) 3328.4784.17
Fax: +49 (0) 3328.4784.30
Asia:
Vectron International
1F-2F, No 8 Workshop, No 308 Fenju Road
WaiGaoQiao Free Trade Zone
Pudong, Shanghai, China 200131
Tel: 86.21.5048.0777
Fax: 86.21.5048.1881
Disclaimer
Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application.
No rights under any patent accompany the sale of any such product(s) or information.
Rev: 1/27/2009 daf
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
