Multilayer Ceramic Capacitors(High Capacitance)
Multilayer Ceramic Capacitors
(High Capacitance)
Series:
ECJ
■
Features
●
Small size and high capacitance
●
Low ESR/ESL and excellent high-frequency characteristics
●
Ideal alternative to TANTALUM CHIP CAPACITORS
and ALUMINUM ELECTROLYTIC CAPACITORS
●
RoHS compliant
■
Recommended Applications
●
Class 2 (Hi-K Type)
· Power supply circuitry decoupling applications
DC-DC converter power supply circuitry of the
high-speed LSI smoothing circuit
■
Handling Precautions
See Page 48 to 53
■
Packaging Specifications
See Page 45, 46, 56
■
Discontinued / Revised Part Numbers,
Alternative Part Numbers
See Page 54, 55
■
Explanation of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
C
J
1
V
B
0
J
4
7
5
M
(Example)
Product Code
(ECJ:Multilayer Ceramic
Chip Capacitors)
Packaging
Rated Voltage Code
Style Code
Size Code
Temperature
Characteristic Code
Capacitance
Tolerance Code
Nominal Capacitance
■
Construction
No
1
3
4
2
1
5
Name
Ceramic dielectric
Internal electrode
Terminal
electrode
Substrate electrode
Intermediate electrode
External electrode
2
3
4
5
■
Dimensions in mm (not to scale)
Size Code Size (EIA)
0
L
0402
0603
1
L
1.00±0.05
1.00
+0.15
–0.05
1.6±0.1
1.60±0.15
2.0±0.1
W
0.50±0.05
0.50
+0.15
–0.05
0.8±0.1
0.80±0.15
1.25±0.10
1.25±0.15
1.25±0.20
1.25±0.15
1.60±0.15
1.6±0.2
W
2
G
L
1
L
2
0805
T
2.00±0.15
2.0±0.2
2.00±0.15
3.20±0.15
3
1206
D
M
3.2±0.2
T
0.50±0.05
0.50
+0.15
–0.05
0.8±0.1
0.80±0.15
0.85±0.10
1.25±0.10
1.25±0.15
1.25±0.20
0.85±0.10
0.85±0.10
1.15±0.10
1.6±0.2
0.85±0.10
1.15±0.10
L
1
, L
2
0.2±0.1
0.3±0.2
0.50±0.25
0.6±0.3
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Dec. 2008
– EC2 –
Multilayer Ceramic Capacitors(High Capacitance)
■
Packaging Styles and Standard Packaging Quantities
Packaging
Size
Style
Thickness
Code Packaging Styles
Paper taping
E
(Pitch : 2 mm)
Paper taping
V
(Pitch : 4 mm)
φ180
reel
F
Embossed taping
(Pitch : 4 mm)
Y
φ330
reel and Bulk case Type : Please contact us.
Quantity : pcs./reel
0402
T=0.5
10,000
—
—
—
0603
T=0.8
—
4,000
—
—
0805
T=0.85
—
4,000
—
—
T=1.25
—
—
3,000
—
T=0.85
—
4,000
—
—
1206
T=1.15
—
—
3,000
—
T=1.6
—
—
—
2,000
■
Temperature Characteristics
●
Class 2
Temperature
Characteristic Code
B, X
Temperature
Characteristics
B
X7R
X5R
F
Y5V
Capacitance Change
±10 %
±15 %
±15 %
+30, –80 %
+22, –82 %
Measurement
Temperature Range
–25 to 85 °C
–55 to 125 °C
–55 to 85 °C
–25 to 85 °C
–30 to 85 °C
Reference
Temperature
20 °C
25 °C
25 °C
20 °C
25 °C
F
For applicable “Temperature Characteristics”, see the lists of standard products on page 6 to 7.
■
Rated Voltage
Code
Rated Voltage
1H
DC 50 V
1E
DC 25 V
1C
DC 16 V
1A
DC 10 V
0J
DC 6.3 V
■
Nominal Capacitance
Ex.
Nominal Capacitance
105
1,000,000 pF
(1 µF)
225
2,200,000 pF
(2.2 µF)
106
10,000,000 pF
(10 µF)
226
22,000,000 pF
(22 µF)
■
Capacitance Tolerance
Class
2
Temperature Characteristics
B, X7R, X5R
F, Y5V
Capacitance Tolerance Code
K
M
Z
Capacitance Tolerance
±10 %
±20 %
+80, –20 %
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Dec. 2008
– EC3 –
Multilayer Ceramic Capacitors(High Capacitance)
■
Specifications and Testing Methods
Item
Operating
Temperature
Range
Dielectric
Withstanding
Voltage
Insulation
Resistance
(I.R.)
Capacitance
Dissipation
Factor
(tan
δ)
Specification
Temp. Char. B, X7R : –55 to 125 °C
Temp. Char. B, X5R : –55 to 85 °C
Temp. Char. F, Y5V : –30 to 85 °C
No dielectric breakdown and/or damage
Test voltage : Rated voltage 250 %
Duration:1 to 5 s.
Charge / Discharge current: 50 mA max.
Measuring voltage : Rated voltage
Duration : 60±5 s
Charge / Discharge current: 50 mA max.
Measuring temperature: 20±2 °C
Preconditioning: The capacitors shall be
kept in temperature of 150 +0/–10 °C
for 1 hour and subject to standard
condition
½
48±4 hours before initial
measurement.
Nominal capacitance C
<10
µF
C>10 µF
Measuring frequency 1 kHz±10 % 120 Hz±20 %
Measuring voltage 1.0±0.2 Vrms 0.5±0.2 Vrms
Temperature
Temperature Characteristics
Characteristics
B
: ±10 %
X7R : ±15 %
X5R : ±15 %
F
: +30, –80 %
Y5V : +22, –82 %
Maximum capacitance change at stages 1 to 5
Temp. Char.
Stage 1
Stage 2
Stage 3
(Ref. Temp.)
Stage 4
Stage 5
B, F X7R X5R Y5V
20 °C 25 °C 25 °C 25 °C
–25 °C –55 °C –55 °C –30 °C
20 °C
25 °C
25 °C
25 °C
85 °C
25 °C
Test Method
500/C (M ) min.
Note : 100/C(M )min. for DC 10 V max.
C : Nominal Cap. in µF
Within the specified tolerance
0.2 max.
Please see the technical specifications for details.
85 °C 125 °C 85 °C
20 °C 25 °C 25 °C
See the technical specifications for
details such as measuring voltage.
Adhesion
Terminal electrodes shall be free from peeling or signs of
peeling.
Applied force : 5 N
Duration : 10 s
Size : 0402
1.0
R0.5
0.5
Sample
PC boad
Size : 0603 to 1206
1.0
Sample
Unit : mm
Bending
Strength
20
R340
45±2
45±2
Unit : mm
Vibration
Proof
Appearance : No mechanical damage.
Capacitance : Within the specified tolerance
tanδ : Initial standard value
Total amplitude : 1.5 mm
Vibration frequency : 10 to 55 to 10 Hz
for 1 min
3 perpendicular directions for 2 hours
each, a total of 6 hours
½Standard
condition : Temperature 15 to 35 °C, Relative humidity 45 to 75 %
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Dec. 2008
– EC4 –
Bending Value
Appearance: No mechanical damage
Capacitance change:
Temp. Char. B, X7R, X5R: within ±12.5 %
F, Y5V: within ±30 %
Bending value :1 mm
Bending speed : 1 mm/s
Multilayer Ceramic Capacitors(High Capacitance)
Item
Resistance
to Soldering
Heat
Specification
Appearance : No mechanical damage
Capacitance change :
Temp. Char. B, X7R, X5R : within ±7.5 %
F, Y5V : within ±20 %
tanδ : Initial standard value
IR : Initial standard value
Withstand voltage : No dielectric breakdown or damage
Test Method
Soldering bath method
Preconditioning : Heat treatment
(½1)
Solder temperature : 270±5 °C
Dipping period : 3.0±0.5 s
Preheat condition :
Order Temp. (°C) Size 0805 max. Size 1206
80 to 100 120 to 180s 300 to 360s
1
2
150 to 200 120 to 180s 300 to 360s
Recovery (Standard condition) : 48±4 h
Soldering bath method
Solder temperature : 230±5 °C
Dipping period : 4±1 s
Solder : H63A (JIS–Z–3282)
Solderability
More than 95 % of the soldered area of both terminal
electrodes shall be covered with fresh solder.
Temperature
Cycle
Appearance : No mechanical damage
Preconditioning : Heat treatment
(½1)
Step 1: Minimum operating temp. 30±3 min
Capacitance change :
Step 2: Room temp. 3 min max.
Temp. Char. B, X7R, X5R : within ±7.5 %
Step 3: Maximum operating temp. 30±3 min
F, Y5V : within ±20 %
Step 4: Room temp. 3 min max.
tanδ : Initial standard value
Number of cycles : 5 cycles
IR : Initial standard value
Recovery(Standard condition) : 48±4 h
Withstand voltage : No dielectric breakdown and/or damage
Preconditioning : Heat treatment
(½1)
Temperature : 40±2 °C
Relative humidity : 90 to 95 %
Test period : 500+24/0 h
Recovery(Standard condition) : 48±4 h
Damp Heat
Appearance : No mechanical damage
(steady state) Capacitance change :
Temp. Char. B, X7R, X5R : within ±20 %
F, Y5V : within ±30 %
tanδ : Temp. Char. B, X7R, X5R : 0.25 max.
F, Y5V : 0.3 max.
IR : 50/C (M ) min.
Note : 10/C (M ) min. for rated vol. DC 10 V max.
C:Nominal cap. in µF
Please see the technical specifications for details.
Damp Heat
Load
Appearance : No mechanical damage
Capacitance change :
Temp. Char. B, X7R, X5R : within ±20 %
F, Y5V : within ±30 %
tanδ : Temp. Char. B, X7R, X5R : 0.25 max.
F, Y5V : 0.3 max.
IR : 25/C (M ) min.
Note : 5/C (M ) min. for rated vol. DC 10 V max.
C:Nominal cap. in µF
Please see the technical specifications for details.
Appearance : no mechanical damage
Capacitance change :
Temp. Char. B, X7R, X5R : within ±20 %
F, Y5V : within ±30 %
tanδ : Temp. Char. B, X7R, X5R : 0.25 max.
F, Y5V : 0.3 max.
IR : 50/C (M ) min.
Note : 10/C (M ) min. for rated vol. DC 10 V max.
C:Nominal cap. in µF
Please see the technical specifications for details.
Preconditioning : Voltage treatment
(½2)
Temperature : 40±2 °C
Relative humidity : 90 to 95 %
Applied voltage : Rated voltage
Charge/discharge current : 50 mA max.
Test period : 500+24/0 h
Recovery(Standard condition) : 48±4 h
High
Temperature
Load
Preconditioning : Voltage treatment
(½2)
Temperature : Maximum operation temp. ±3 °C
Applied voltage : (1)Rated voltage 200 %
(2)Rated voltage 150 %
(3)Rated voltage 100 %
Please see the technical specifications
for details.
Charge/discharge current : 50 mA max.
Test period : 1000+48/0 h
Recovery (Standard condition) : 48±4 h
(½1) Heat treatment : 1 h of heat treatment at 150+0/–10 °C followed by 48±4 h recovery under standard conditions.
(½2) Voltage treatment : 1 h of voltage treatment under the specified temperature and voltage for testing followed by 48±4 h of recovery under
standard conditions.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Dec. 2008
– EC5 –
Multilayer Ceramic Capacitors(High Capacitance)
■
Standard Products for EIA Size “0402”, Taped Version
Rated Voltage
DC 16 V
Capaci- Capacitance
Dim. Temp.
Char.
tance
Part No.
T
Tolerance
(µF)
(mm) X5R
ECJ0EB1C105M
0.5
½
1
±10 %(K)
2.2
or ±20 %(M)
4.7
●
Class 2
◆
Temperature Characteristic Code : B (Temperature Characteristics : X5R)
DC 10 V
Dim. Temp.
Char.
T
Part No.
(mm) X5R
ECJ0EB1A105
0.5
DC 6.3 V
Dim. Temp.
Char.
T
Part No.
(mm) X5R
ECJ0EB0J105
0.5
ECJ0EB0J225M
0.5
ECJ0EB0J475M
0.5
½
: Capacitance tolerance code : “ ” for “K” or “M”
Dimensional tolerance of L, W, T : ±0.05 mm for no mark,
+0.15
mm for “½” mark.
–0.05
Standard packaging quantity of Packaging Style Code “E” (T = 0.5 mm) : 10,000 pcs./reel.
Avoid flow soldering.
◆
Temperature Characteristic Code : F (Temperature Characteristics : F, Y5V)
Rated Voltage
DC 6.3 V
Capaci- Capacitance
Dim. Temp.
Char.
tance
Part No.
T
(µF) Tolerance
(mm) F Y5V
1 +80, –20 % (Z)
ECJ0EF0J105Z
0.5
Standard packaging quantity of Packaging Style Code “E” (T = 0.5 mm): 10,000 pcs./reel.
Recommend soldering method : Reflow soldering.
■
Standard Products for EIA Size “0603”, Taped Version
Rated Voltage
DC 25 V
Capaci- Capacitance
Dim. Temp.
Char.
tance
Part No.
T
(µF) Tolerance
(mm) X5R
ECJ1VB1E105
0.8
1
±10 %(K)
2.2
or
4.7
±20 %(M)
10
●
Class 2
◆
Temperature Characteristic Code : B (Temperature Characteristics : X5R)
DC 16 V
Dim. Temp.
Char.
Part No.
T
(mm) X5R
ECJ1VB1C105
0.8
½
ECJ1VB1C225
0.8
ECJ1VB1C475
½
0.8
½½
DC 10 V
Dim. Temp.
Char.
Part No.
T
(mm) X5R
ECJ1VB1A105
0.8
½
ECJ1VB1A225
0.8
ECJ1VB1A475
½
0.8
ECJ1VB1A106M
½
0.8
½½
DC 6.3 V
Dim. Temp.
Char.
Part No.
T
(mm) X5R
ECJ1VB0J105
0.8
ECJ1VB0J225
0.8
ECJ1VB0J475
½
0.8
ECJ1VB0J106M
½
0.8
½½
: Capacitance tolerance code : “ ” for “K” or “M”
Standard packaging quantity of Packaging Style Code “V” (T = 0.8 mm): 4,000 pcs./reel.
“½” : Avoid flow soldering.
“½½” : “L”, “W”, “T” Dimension Tolerance ±0.15 mm
◆
Temperature Characteristic Code : F (Temperature Characteristics : F, Y5V)
Rated Voltage
DC 25 V
Capaci- Capacitance
Dim. Temp.
Char.
tance
Part No.
T
F
(µF) Tolerance
(mm)
+80,
ECJ1VF1E105Z
0.8
1
2.2 –20 %(Z)
DC 16 V
Dim. Temp.
Char.
T
Part No.
F
(mm)
ECJ1VF1C105Z
0.8
DC 10 V
DC 6.3 V
Temp.
Dim.
Dim. Temp.
Char.
Char.
T
T
Part No.
Part No.
(mm) F Y5V
(mm) F Y5V
ECJ1VF1A105Z
0.8
ECJ1VF1A225Z
0.8
ECJ1VF0J225Z
0.8
Standard packaging quantity of Packaging Style Code “V” (T = 0.8 mm): 4,000 pcs./reel.
■
Standard Products for EIA Size “0805”, Taped Version
Rated Voltage
DC 25 V
Capaci- Capacitance
Dim. Temp.
Char.
tance
Part No.
T
(µF) Tolerance
(mm) X5R
ECJ2FB1E105
1.25
½
1
2.2 ±10 %(K)
ECJ2FB1E225
1.25
½
or
ECJ2FB1E475
1.25
½
4.7
10 ±20 %(M)
22
●
Class 2
◆
Temperature Characteristic Code : B (Temperature Characteristics : B, X5R)
DC 16 V
Dim. Temp.
Char.
Part No.
T
(mm) X5R
ECJ2FB1C105
1.25
½
ECJ2FB1C225
1.25
½
ECJ2FB1C475
1.25
½
ECJ2FB1C106
1.25
½½
DC 10 V
Dim.
Part No.
T
(mm)
ECJ2FB1A105
1.25
ECJ2FB1A225
1.25
½
ECJ2FB1A475
1.25
½
ECJ2FB1A106
1.25
½½
ECJ2FB1A226M
1.25
½½
Temp.
Char.
B X5R
—
—
—
—
DC 6.3 V
Dim. Temp.
Char.
Part No.
T
(mm) X5R
ECJ2FB0J225
ECJ2FB0J475
ECJ2FB0J106
ECJ2FB0J226M
1.25
1.25
½
1.25
½½
1.25
½½
: Capacitance tolerance code : “ ” for “K” or “M”
Dimensional tolerance of L, W, T : ±0.1 mm for no mark, ±0.15 mm for “½” mark, ±0.2 mm for “½½”mark.
Standard packaging quantity of Packaging Style Code “F” (T = 1.25 mm): 3,000 pcs./reel.
Avoid flow soldering.
◆
Temperature Characteristic Code : F (Temperature Characteristics : F, Y5V)
Rated Voltage
DC 50 V
Capaci- Capacitance
Dim. Temp.
Char.
tance
Part No.
T
Tolerance
F
(µF)
(mm)
½
ECJ2FF1H105Z
1.25
1
+80,
2.2
4.7 –20 %(Z)
10
DC 25 V
Dim. Temp.
Char.
Part No.
T
F
(mm)
½
ECJ2FF1E105Z
1.25
ECJ2FF1E225Z
1.25
½
DC 16 V
DC 10 V
Temp.
Dim.
Dim. Temp.
Char.
Char.
Part No.
T
Part No.
T
(mm) F Y5V
(mm) F Y5V
ECJ2VF1C105Z
0.85
ECJGVF1C225Z
0.85
ECJGVF1C475Z
0.85
ECJGVF1A475Z
0.85
ECJ2FF1A106Z
1.25
½
Dimensional tolerance of L, W, T : L, W: ±0.15 mm / T : ±0.1 mm for no mark, ±0.15 mm for “½”mark.
Standard packaging quantity of Packaging Style Code “V” (T = 0.85 mm): 4,000 pcs./reel, “F” (T = 1.25 mm): 3,000 pcs./reel.
Soldering method of dimension T > 1 mm: Avoid flow soldering.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Dec. 2008
– EC6 –
Industrial Control Electronics
京公网安备 11010802033920号
EEWORLD
