L180-XPW-110D-LL
White
4.8mm, Shallow-Domed Cylindrical, 4.7mm Height
95° viewing angle
DWG BY:
LL / GP
08-20-07
CHK BY:
PL
09-11-07
QA:
__
__-__-__
MFG:
__
__-__-__
REVISION: -
09-10-07
Part No.
L180-XPW-110D-LL
DWG NO.
DSDC0604
Page
1 of 4
23105 Kashiwa Court, Torrance, CA 90505
Phone: (800) 579-4875 or (310) 534-1505 Fax: (310) 534-1424
E-mail: webmaster@ledtronics.com
Website: http://www.ledtronics.com
Features:
♦
♦
♦
♦
High intensity
4.8mm diameter package
Tin plated copper leads
Pb-free
Package Dimensions:
Part NO.
L180-XPW-110D-LL
OE
AN D
Chip Material
InGaN
Lens Color
Water Clear
Emission Color
White
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ±0.25mm (.010”) unless otherwise noted.
3. Protruded resin under flange is 1.0mm (.04”) max.
4. Lead spacing is measured where the leads emerge from the package.
5. Specifications are subject to change without notice.
6. Precautions for ESD: Static electricity and surge can damages the LED. It is recommended
to use a wrist band or anti-electrostatic glove when handling the LED. All devices,
equipment and machinery must be properly grounded.
Part No.
L180-XPW-110D-LL
DWG NO.
DSDC0604
Page
2 of 4
23105 Kashiwa Court, Torrance, CA 90505
Phone: (800) 579-4875 or (310) 534-1505 Fax: (310) 534-1424
E-mail: webmaster@ledtronics.com
Website: http://www.ledtronics.com
Absolute Maximum Ratings at Ta=25ºC
Parameter
Power Dissipation
Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width)
Continuous Forward Current
Derating Linear From 50°C
Reverse Voltage
Electrostatic Discharge (ESD)
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature [4mm (.157”) From Body]
MAX.
80
100
20
0.4
5
600
Unit
mW
mA
mA
mA/°C
V
V
-30°C to +80°C
-40°C to +100°C
280°C for 5 Seconds
Electrical Optical Characteristics at Ta=25
°C
Parameter
Luminous Intensity
Viewing Angle
Forward Voltage
Reverse Current
SCP
Lumens
Radiant Intensity
Color Rendering Index
Color Rank
X
Y
Symbol
I
V
2
θ
1/2
V
F
I
R
---
---
Min.
690
---
---
---
---
---
---
---
Typ
1700
95
3.1
---
---
---
---
---
BIN PWT
Max.
---
---
3.8
10
---
---
---
---
Unit
mcd
Deg
V
µA
---
lm
mW/sr
---
Test Condition
I
F
=20mA
(Note 1)
(Note 2)
I
F
=20mA
V
R
=5V
---
---
---
---
I
e
CRI
0.338
0.339
0.386
0.387
0.400
0.373
0.352
0.324
Notes:
1. Luminous intensity is measured with a light sensor and filter combination that approximates the
CIE eye-response curve.
2.
θ
1/2
is the off-axis angle at which the luminous intensity is half the axial luminous intensity.
3. Forward voltage measurement allowance is ±0.1V
4. Luminous Intensity Measurement Allowance is ± 10%.
Part No.
L180-XPW-110D-LL
DWG NO.
DSDC0604
Page
3 of 4
23105 Kashiwa Court, Torrance, CA 90505
Phone: (800) 579-4875 or (310) 534-1505 Fax: (310) 534-1424
E-mail: webmaster@ledtronics.com
Website: http://www.ledtronics.com
Typical Electrical / Optical Characteristics Curves
(25ºC Ambient Temperature Unless Otherwise Noted)
CIE 1931 Chromaticity Diagram
0.40
0.38
1.0
Normalized
Response
0.34
0.36
0.36
0.8
y
0.34
0.6
0.4
0.32
0.2
0.30
0.32
x
0.38
0.40
0.42
0.0
38 40 42
0
0
0
44 46 48 50 52
0
0
0
0
0
54 56 58 60 62
0
0
0
0
0
64 66 68 70 72
0
0
0
0
0
74 76 78
0
0
0
Wave Length(nm )
Forward Current
vs Forward Voltage
3
30
Relative Luminous Intensity
vs Forward Current
Forward Current
IF(mA)
25
20
Relative Intensity
(LOP@20mA=1)
2.5
2.75
3
3.25
3.5
3.75
2.5
2
15
1.5
10
1
5
0.5
0
0
0
5
10
15
20
25
30
35
Forward Voltage VF(V)
Forward Current IF(mA)
Forward Current VS.
Chr omaticity coordinate
Forward Cureent
Derating Curve
60
Ta=25℃
0.48
0.47
1mA
Forward Current
IF(mA)
50
40
30
20
10
0
0.46
5mA
10mA
y
0.45
20mA
0.44
40mA
30mA
0.43
0.45
0.46
0.47
0.48
0.49
0
10
20
30
40
50
60
70
80
90
Ta(ºC)
x
Beam Pattetn
0°
-30°
30°
-60°
60°
-90°
1.0
0.8
0.6
0.4
0.2
0.2
0.4
0.6
0.8
1.0
90°
Relative Intensity (LOP@MAX=1)
Part No.
L180-XPW-110D-LL
DWG NO.
DSDC0604
Page
4 of 4
