Bulletin I0118J rev. C 09/03
SC275.....5. Series
40 (157)
Wafer flat alligned with
side b of the die
a
c
0.35 ± 0.01
(14 ± 0.4)
D
b
d
C
A
Ø
NOTES:
1. ALL DIMENSIONS ARE SHOWN IN
MILLIMETERS (MILS)
2. CONTROLLING DIMENSION: (MILS)
3. LETTER DESIGNATION:
A = Anode (Top Metal)
C = Cathode (Back Metal)
D = Reject Ink Dot (only on non-conforming dies)
4. SAWING:
Recommended Blade
SEMITEC S1025 QS00 Blade
Sawing Street
0.05 ± 0.005
(2 ± 0.2)
Ø 125 (492)
NOT TO SCALE
5. DIMENSIONS AND TOLERANCES
Device
#
SC275
R
015x5x
SC275
S
020x5x
SC275
S
030x5x
SC275
S
045x5x
SC275
S
060x5x
SC275
H
045x5x
SC275
H
100x5x
SC275
H
150x5x
T
J
Max.
(°C)
125
150
150
150
150
175
175
175
V
R
(V)
15
20
30
45
60
45
100
150
A
B
C
n.a. contact factory
n.a. contact factory
D
diameter
6.98 +0, -0.01 6.98 +0, -0.01 6.48 +0, -0.01 6.48 +0, -0.01
(275 +0, -0.4) (275 +0, -0.4) (269 +0, -0.4) (269 +0, -0.4)
n.a. contact factory
n.a. contact factory
n.a. contact factory
6.98 +0, -0.01 6.98 +0, -0.01 6.48 +0, -0.01 6.48 +0, -0.01
(275 +0, -0.4) (275 +0, -0.4) (269 +0, -0.4) (269 +0, -0.4)
n.a. contact factory
1.5 ± 0.2
60 ± 8
1.5 ± 0.2
60 ± 8
Document Number: 93872
www.vishay.com
1
SC275.....5. Series
Bulletin I0118J rev. C 09/03
Electrical Characteristics
Device
#
SC275
R
015x5x
SC275
S
020x5x
SC275
S
030x5x
SC275
S
045x5x
SC275
S
060x5x
SC275
H
045x5x
SC275
H
100x5x
SC275
H
150x5x
T
J
Max.
(°C)
125
150
150
150
150
175
175
175
V
R
(V)
15
20
30
45
60
45
100
150
100
1350
Typ. I
R
@ 25°C
(µA)
Typ. I
R
@ 125°C Max. V
F
@ I
F
@ 25°C
(mA)
n.a. contact factory
n.a. contact factory
550
0.55 @ 150A
TO-249AA
(V)
Package
Style
n.a. contact factory
n.a. contact factory
n.a. contact factory
81
0.77 @ 60A
-
n.a. contact factory
Mechanical Data
Device
#
SC275xxxx
A
5x
SC275xxxx
S
5x
Bondable
Solderable
--
Ti 1 kÅ
Metal Thickness
Front Metal
Al/Si 30 kÅ
Ni 4 kÅ
--
Ag 35 kÅ
Cr 1 kÅ
Cr 1 kÅ
Metal Thickness
Back Metal
Ni 2 kÅ
Ni 2 kÅ
Ag 3 kÅ
Ag 3 kÅ
Recommended Storage Environment: Store in original container, in dessicated nitrogen, with no contamination.
Shelf life for parts stored in above condition is 2 years.
If the storage is done in normal atmosphere shelf life is reduced to six months.
Packaging
Device
#
SC275xxxxx5
B
SC275xxxxx5
R
SC275xxxxx5
P
SC275xxxxx5
F
Description
Minimum Order Quantity
Die in Sale Package
180
n.a.
366
180
Inked Probed Unawn Wafer (Wafer in Box)
Probed Die in Tape & Reel
Probed Die in Waffle Pack
Inked Probed Sawn Wafer on Film
Document Number: 93872
www.vishay.com
2
SC275.....5. Series
Bulletin I0118J rev. C 09/03
Ordering Information Table
Device Code
SC 275
1
1
2
3
4
5
6
7
-
-
-
-
-
-
-
Schottky Die
Die Size Code
2
S
3
030
4
S
5
5
6
B
7
H = 830 Process
R = OR'ing Process
S = Standard Process
Process (see Electrical Characteristics Table)
Voltage code: Code = V
RRM
Chip surface metallization (see Mechanical Data Table)
Wafer Diameter in inches
Packaging (see Packaging Table)
Wafer on Film
STEEL FRAME
Document Number: 93872
www.vishay.com
3
SC275.....5. Series
Bulletin I0118J rev. C 09/03
Wafer in Box
ROUND CONTAINER
TYVEK DISK
FOAM DISK
Die in Waffle Pack
CHIP TRAY POCKET
Document Number: 93872
www.vishay.com
4
SC275.....5. Series
Bulletin I0118J rev. C 09/03
Data and specifications subject to change without notice.
This product has been designed for Industrial Level.
Qualification Standards can be found on IR's Web site.
IR WORLD HEADQUARTERS:
233 Kansas St., El Segundo, California 90245, USA Tel: (310) 252-7105
TAC Fax: (310) 252-7309
09/03
Document Number: 93872
www.vishay.com
5
