CRCW12064020FKEC

Description
Fixed Resistor, Metal Glaze/thick Film, 0.25W, 402ohm, 200V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 1206, CHIP, ROHS COMPLIANT
CategoryPassive components    The resistor
File Size154KB,8 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Environmental Compliance
Download Datasheet Parametric View All

CRCW12064020FKEC Overview

Fixed Resistor, Metal Glaze/thick Film, 0.25W, 402ohm, 200V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 1206, CHIP, ROHS COMPLIANT

CRCW12064020FKEC Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerVishay
package instructionCHIP, ROHS COMPLIANT
Reach Compliance Codecompliant
ECCN codeEAR99
JESD-609 codee3
Manufacturer's serial numberCRCW1206
Installation featuresSURFACE MOUNT
Number of terminals2
Maximum operating temperature155 °C
Minimum operating temperature-55 °C
Package shapeRECTANGULAR PACKAGE
method of packingTR, PAPER, 13 INCH
Rated power dissipation(P)0.25 W
Rated temperature70 °C
resistance402 Ω
Resistor typeFIXED RESISTOR
size code1206
surface mountYES
technologyMETAL GLAZE/THICK FILM
Temperature Coefficient100 ppm/°C
Terminal surfaceMatte Tin (Sn)
Terminal shapeWRAPAROUND
Tolerance1%
Operating Voltage200 V
D../CRCW.... e3
Vishay
Lead (Pb)-free Thick Film, Rectangular Chip Resistors
FEATURES
High volume product suitable for commercial and
special applications
Excellent stability (ΔR/R
1 % for 1000 h at 70 °C)
Compliant with “Restriction of the use of Hazardous
Substances” (RoHS) directive 2002/95/EC (issue 2004)
Lead (Pb)-free solder contacts on Ni barrier layer
Pure tin plating provides compatibility with lead (Pb)-free
and lead containing soldering processes
Metal glaze on high quality ceramic
Protective overglaze
STANDARD ELECTRICAL SPECIFICATIONS
SIZE
MODEL
INCH METRIC
POWER RATING
P
70 °C
W
0.05
LIMITING
ELEMENT
VOLTAGE
MAX. V≅
30
RESISTANCE
TEMPERATURE
TOLERANCE
RANGE
E-SERIES
COEFFICIENT
%
Ω
ppm/K
± 100
± 200
±1
± 1; ± 5
47R - 1M0
10R - 1M0
24 + 96
24
CRCW0201
0201
0525
Zero-Ohm-Resistor:
R
max..
= 50 mΩ,
I
max.
at 70 °C = 1.0 A
D10/CRCW0402
0402
1005
0.063
50
± 100
± 200
±1
±5
1R0 - 10M
24 + 96
24
Zero-Ohm-Resistor:
R
max.
= 20 mΩ,
I
max.
at 70 °C = 1.5 A
D11/CRCW0603
0603
1608
0.10
75
± 100
± 200
± 100
± 200
±1
±5
±1
±5
1R0 - 10M
24 + 96
24
24 + 96
24
Zero-Ohm-Resistor:
R
max.
= 20 mΩ,
I
max.
at 70 °C = 2.0 A
D12/CRCW0805
0805
2012
0.125
150
1R0 - 10M
Zero-Ohm-Resistor:
R
max.
= 20 mΩ,
I
max.
at 70 °C = 2.5 A
D25/CRCW1206
1206
3216
0.25
200
± 100
± 200
±1
±5
1R0 - 10M
24 + 96
24
Zero-Ohm-Resistor:
R
max.
= 20 mΩ,
I
max.
at 70 °C = 3.5 A
CRCW1210
1210
3225
0.33
200
± 100
± 200
± 100
± 200
±1
±5
±1
±5
1R0 - 10M
24 + 96
24
24 + 96
24
Zero-Ohm-Resistor:
R
max.
= 20 mΩ,
I
max.
at 70 °C = 4.0 A
CRCW1218
1218
3246
1.0
200
1R0 - 2M2
Zero-Ohm-Resistor:
R
max.
= 20 mΩ,
I
max.
at 70 °C = 7.0 A
CRCW2010
2010
5025
0.50
400
± 100
± 200
± 100
± 200
±1
±5
±1
±5
1R0 - 10M
24 + 96
24
24 + 96
24
Zero-Ohm-Resistor:
R
max.
= 20 mΩ,
I
max.
at 70 °C = 5.0 A
CRCW2512
2512
6332
1.0
500
1R0 - 10M
Zero-Ohm-Resistor:
R
max.
= 20 mΩ,
I
max.
at 70 °C = 7.0 A
Notes:
These resistors do not feature a limited lifetime when operated within the permissible limits. However, resistance value drift increasing over
operating time may result in exceeding a limit acceptable to the specific application, thereby establishing a functional lifetime
Marking and packaging: see appropriate catalog or web pages
Power rating depends on the max. temperature at the solder point, the component placement density and the substrate material
Document Number: 20035
Revision: 14-Feb-08
For technical questions in Europe, contact: ff3cresistors@vishay.com
For technical questions in Americas/Asia, contact: ff2bresistors@vishay.com
www.vishay.com
107
