Part Number

Search

TE-2Q3TD33.2MH1%

Description
General Purpose Inductor, 33200uH, 1%, 1 Element
CategoryPassive components    inductor
File Size96KB,5 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

TE-2Q3TD33.2MH1% Overview

General Purpose Inductor, 33200uH, 1%, 1 Element

TE-2Q3TD33.2MH1% Parametric

Parameter NameAttribute value
MakerVishay
Reach Compliance Codeunknown
ECCN codeEAR99
DC Resistance118 Ω
Nominal inductance(L)33200 µH
Inductor ApplicationsFILTER CHOKE
Inductor typeGENERAL PURPOSE INDUCTOR
Number of functions1
Number of terminals2
Maximum operating temperature55 °C
Minimum operating temperature
self resonant frequency0.18 MHz
Shape/Size DescriptionCYLINDRICAL PACKAGE
shieldNO
surface mountNO
Terminal locationRADIAL
Terminal shapePRINTED WIRING PIN
Tolerance1%
Models TE and TD
Vishay Dale
Filter Inductors
Toroid
FEATURES
Choice of encapsulated (TE) or dipped (TD) styles.
TD style combines low cost with excellent performance in commercial
applications.
High Q and wide selection of Q versus frequency ranges in one small package.
Large number of standard inductance values.
STANDARD ELECTRICAL SPECIFICATIONS
(Applies to Core Only)
MODEL
TE-2
TD-2
X
X
TE-3
TD-3
X
X
X
X
X
X
X
X
X
TE-4
TD-4
X
X
X
X
X
X
X
X
TE-5
TD-5
X
X
X
X
X
X
X
X
TC
CODE
TA
TB
TD
TE
TL*
TM
TR
TW
TEMPERATURE
COEFFICIENT
0
±
1%
0
±
0.1%
0
±
0.1%
0
±
0.15%
+ 40 to + 110PPM/°C
+ 85 to + 185PPM/°C
0
±
0.25%
50PPM/°C (Typical)
0
±
0.25%
TEMPERATURE
RANGE
- 55°C to + 125°C
+ 13°C to + 35°C
0°C to + 55°C
0°C to + 55°C
- 55°C to + 25°C
+ 25°C to + 85°C
- 65°C to + 125°C
- 65°C to + 125°C
- 55°C to + 85°C
X
X
X
X
Q0
TC
AVAILABILITY
Q3
X
X
X
Q4
X
X
X
X
X
X
*Inverse of typical Temperature Coefficient of polystyrene capacitor.
INDUCTANCE RANGES
TC
CODE
Q0
Q3
Q4
TE-2
TD-2
40µH to 15mH
475µH to 120mH
1mH to 250mH
TE-3
TD-3
50µH to 15mH
500µH to 1H
1mH to 4H
TE-4
TD-4
150µH to 20mH
1mH to 2H
2mH to 5H
TE-5
TD-5
1mH to 100mH
5mH to 2H
10mH to 5H
ELECTRICAL SPECIFICATIONS
Tolerance:
TE-2, TD-2 =
±
1% > 2mH,
±
2% = .05mH to 2mH.
TE-3, TD-3 =
±
1% > 2mH,
±
2% 154µH to 2mH,
±
5% < 150µH.
TE-4, TD-4 =
±
1% > 2mH,
±
2% < 2mH.
TE-5, TD-5 =
±
1% > 2mH,
±
2% < 2mH.
Insulation Resistance:
1000 Megohm minimum.
Dielectric Strength:
1000V minimum (TE).
500V minimum (TD).
MECHANICAL SPECIFICATIONS
DIMENSIONAL CONFIGURATIONS
TE
A Dia.
Max.
D
.375
±
.125
[9.53
±
3.18]
TD
B
Max.
F
Dia.
C
Min.
A Dia.
Max.
G
C Min.
E
B Max.
F Min.
Dia.
[Numbers in brackets indicate millimeters]
MODEL
TE-2
TD-2
TE-3
TD-3
TE-4
TD-4
TE-5
TD-5
A
.437
[11.10]
.437
[11.10]
.685
[17.40]
.685
[17.40]
1.06
[26.92]
1.06
[26.92]
1.32
[33.53]
1.32
[33.53]
B
.270
[6.86]
.250
[6.35]
.385
[9.78]
.320
[8.13]
.500
[12.70]
.437
[11.10]
.725
[18.42]
.688
[17.48]
C
1.0
[25.40]
2.0
[50.80]
1.0
[25.40]
3.0
[76.20]
1.0
[25.40]
4.0
[101.60]
1.0
[25.40]
6.0
[152.40]
D
.020
[.508]
.025
[.635]
.032
[.813]
.032
[.813]
E
.300
[7.62]
.500
[12.70]
.900
[22.86]
1.0
[25.40]
F
.093
[2.36]
.125
[3.18]
.120
[3.05]
.220
[5.59]
.144
[3.66]
.220
[5.59]
G
.250
[6.35]
.450
[11.43]
.500
[12.70]
Terminal Strength:
2 pounds pull test (TE).
Vibration:
Per MIL-T-27 (TE).
Shock:
Per MIL-T-27 (TE).
Weight:
TE-2 = 2 grams, TD-2 = 1.6 grams typical.
TE-3 = 5.1 grams, TD-3 = 4.9 grams typical.
TE-4 = 20 grams, TD-4 = 17 grams typical.
TE-5 = 53 grams, TD-5 = 52 grams typical.
MATERIAL SPECIFICATIONS
Coating:
Vinyl (TD), non-flammable, abrasion and
moisture resistant. Resists most cleaning agents.
(Consult factory for chemicals which may be used.)
Standard Terminals:
Tinned copper (TE).
Stranded, tinned copper, Teflon insulated (TD).
Encapsulant:
Epoxy (TE).
Gauge:
TE-2 = 24 AWG, TD-2 = 30 AWG.
TE-3 = 22 AWG, TD-3 = 26 AWG.
TE-4 = 20 AWG, TD-4 = 24 AWG.
TE-5 = 20 AWG, TD-5 = 24 AWG.
Document Number 34078
Revision 13-Jul-00
www.vishay.com
140
