T101-LYZGE datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Mechanical and electronic products> switch> T101-LYZGE

Preview

T101-LYZGE: DescriptionToggle Switch, SPST, On-on, Maintained, 3A, 28VDC, Solder Lug Terminal, Toggle Actuator, Panel Mount; CategoryMechanical and electronic products switch; File Size345KB，1 Pages; ManufacturerLamb Industries

Download Datasheet Parametric View All

T101-LYZGE Overview

Toggle Switch, SPST, On-on, Maintained, 3A, 28VDC, Solder Lug Terminal, Toggle Actuator, Panel Mount

T101-LYZGE Parametric

Parameter Name	Attribute value
Maker	Lamb Industries
Reach Compliance Code	unknown
Executor completed	CHROME
Actuator length	0.299 inch
Actuator material	BRASS
Actuator type	TOGGLE
body width	5.1054 mm
body height	8.6106 mm
Body length or diameter	8.1026 mm
Nozzle length	0.217 inch
Casing type	10-48
center contact material	COPPER
Center contact plating	GOLD OVER SILVER
Contact (AC) maximum rated R load	1.5A@250VAC
Maximum contact current (AC)	1.5 A
Maximum contact current (DC)	3 A
Contact (DC) maximum rated R load	3A@28VDC
Contact function	ON-ON
Contact resistance	0.02 mΩ
Maximum contact voltage (AC)	250 V
Maximum contact voltage (DC)	28 V
Dielectric withstand voltage	1500VAC V
Electrical life	30000 Cycle(s)
End contact material	COPPER
End contact plating	GOLD OVER SILVER
Shell material	STAINLESS STEEL
Insulation resistance	1000000000 Ω
insulator material	DIALLYL PHTHALATE
Manufacturer's serial number	T101
Installation features	PANEL MOUNT
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
seal	EPOXY
surface mount	NO
Switch action	MAINTAINED
switch function	SPST
Switch type	TOGGLE SWITCH
Terminal length	0.118 inch
Terminal material	COPPER ALLOY
Termination type	SOLDER LUG

Preview

Download Datasheet

View All

T000-Series

Tiny

Switch

Rear

Panel Mount

Standard

PCB Mount

Right Angle

PCB Mount

The

T000-Series

toggle switch is a com-

pact version of the 5000-Series. With

various actuator, bushing, and terminal

styles, this switch is both versatile and

reliable.

SPECIFICATIONS:

R

ATING

:

Q, G,

AND

M T

ERMINAL

P

LATING

:

3A 125VAC

1.5A 250VAC

3A 28VDC

B

AND

K T

ERMINAL

P

LATING

:

0.4VA Max. at 20V Max.

T

EMPERATURE

:

-30°C to 85°C

E

LECTRICAL

L

IFE

:

30,000 Cycles

W

ITHSTAND

V

OLTAGE

:

1,500VAC for 1 Minute

I

NSULATION

R

ESISTANCE

:

1,000MΩ

C

ONTACT

R

ESISTANCE

:

20mΩ at 100mA 4VDC

MATERIALS:

B

ODY

:

Diallyl Phthalate (DAP), UL 94V-0

A

CTUATOR

:

Chrome Plated Brass

B

USHING

:

Nickel Plated Brass

H

OUSING

:

Stainless Steel

S

UPPORT

:

Tin Plated Brass

C

ONTACTS

:

See Options

T

ERMINALS

:

See Options

EXAMPLE PART NUMBERS:

T101-MY9V3BE:

Photo A

1 Pole, On-On, 0.4VA 20V, 5.5mm non-

threaded bushing, 5.3mm bat actuator,

gold over nickel plated, epoxy sealed,

narrow supported PCB terminals.

T103-SHZQE:

Photo B

1 Pole, On-Off-On, 3A 125VAC, 5.5mm 10-

48UNS bushing, 9.1mm bat actuator, silver

plated, epoxy sealed, solder terminals.

T101-STABE:

Photo C

1 Pole, On-On, 0.4VA 20V, 7.9mm 1/4-

40UNS bushing, 9.1mm bat actuator, gold

over nickel plated, epoxy sealed, horizon-

tal right angle PCB terminals.

Actuator

Options

Bushing

Options

Terminal

Options

Plating

Option

Epoxy

Sealing

Series

T203-MYAV2BE:

Photo D

2 Poles, On-Off-On, 0.4VA 20V, 5.5mm 10-

48UNS bushing, 5.3mm bat actuator, gold

over nickel plated, epoxy sealed, vertical

right angle PCB terminals.

1 Pole:

T101

- On-On

T102

- Off-On

T103

- On-Off-On

T105

- (On)-Off-(On)

T107

- On-Off-(On)

T108

- On-(On) End-End

2 Pole:

T201

- On-On

T203

- On-Off-On

T205

- (On)-Off-(On)

T207

- On-Off-(On)

T208

- On-(On) End-End

L

M

S

S1

1/4 - 40 UNS:

TD

D9

T

T9

10-48 UNS:

H

H9

Y

Y9

Standard:

C

Z

PC Board:

A

AV1

AV2

V3

V4

Snap-In:

A3

AV3

AV4

V31

V41

Standard:

Q

G

B

None

E

- Sealed

Tin Coated:

(*)

M

K

B

Notes:

* = Not available for Z terminal option.

A

C

D

LAMB

INDUSTRIES

Portland, OR USA
