Power Splitter/Combiner
2 Way-0° Resistive 50Ω
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
0.75W max.
0.375W max.
Coaxial
ZFRSC-42+
ZFRSC-42
DC to 4200 MHz
Features
• very wideband, DC to 4200 MHz
• low insertion loss, 0.1 dB typ.
• excellent amplitude unbalance, 0.02 dB typ.
• rugged shielded case
CASE STYLE: K18
Connectors Model
Price
SMA
ZFRSC-42-S(+)
$59.95
BRACKET (OPTION "B")
$2.50
Qty.
(1-9)
(1+)
Applications
• laboratory
• test set-ups
Coaxial Connections
SUM PORT
PORT 1
PORT 2
3
1
2
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Splitter Electrical Specifications
FREQ.
RANGE
(MHz)
L
f
L
-f
U
DC-4200
Typ.
6.2
ISOLATION
(dB)
M
Typ.
6.5
U
Typ.
7.0
INSERTION LOSS (dB)
ABOVE 6.0 dB
L
M
U
PHASE
UNBALANCE
(Degrees)
L
Max.
1
M
Max.
3
U
Max.
5
AMPLITUDE
UNBALANCE
(dB)
L
Max.
0.1
M
Max.
0.2
U
Max.
0.5
Outline Drawing
Typ. Max. Typ. Max. Typ. Max.
0.1
0.2
0.1
0.5
0.4
1.4
L = low range [f
L
to 10 f
L
]
M = mid range [10 f
L
to f
U
/2]
U= upper range [f
U
/2 to f
U
]
This is a resistive power divider to enable frequency coverage from dc to the highest rated frequency. Since resistive power divider do not
provide a high degree of isolation (basically isolation equals the insertion loss between ports), an amplifier such as Mini-Circuits' ZFL
series is recommended when high isolation is required. Matched power rating 0.75W, internal load dissipation 0.375W.
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
0.05
0.50
1.00
10.00
50.00
100.00
400.00
1000.00
1400.00
2000.00
2400.00
3000.00
3400.00
3800.00
4200.00
6.01
6.03
6.00
6.01
6.00
6.03
5.99
5.99
5.97
5.95
6.03
6.12
6.16
6.07
6.12
Amplitude
Unbalance
(dB)
0.03
0.01
0.02
0.00
0.01
0.01
0.02
0.03
0.02
0.01
0.02
0.01
0.04
0.08
0.03
Isolation
(dB)
Phase
Unbalance
(deg.)
0.48
0.03
0.00
0.05
0.01
0.09
0.06
0.63
1.04
1.69
1.96
2.77
3.24
2.70
3.18
VSWR
S
VSWR
1
VSWR
2
S-2
6.04
6.02
6.02
6.01
6.01
6.02
6.01
6.02
5.99
5.96
6.01
6.13
6.12
5.99
6.08
6.05
6.03
6.01
6.05
6.01
6.03
6.02
5.94
5.94
5.93
5.95
6.06
6.13
6.20
6.18
1.00
1.00
1.00
1.00
1.00
1.00
1.01
1.02
1.01
1.03
1.03
1.03
1.02
1.02
1.04
ZFRSC-42
ISOLATION
1.00
1.00
1.00
1.00
1.00
1.01
1.02
1.03
1.03
1.02
1.04
1.07
1.09
1.12
1.14
1.00
1.00
1.00
1.00
1.00
1.01
1.02
1.03
1.03
1.03
1.04
1.07
1.08
1.10
1.12
Outline Dimensions (
inch
)
mm
A
1.25
31.75
J
--
--
B
1.25
31.75
K
--
--
C
.75
19.05
L
.125
3.18
D
.63
16.00
M
1.688
42.88
E
.38
9.65
N
2.18
55.37
F
1.00
25.40
P
.75
19.05
G
.125
3.18
H
1.000
25.40
Q
wt
.07 grams
1.78
70.0
ZFRSC-42
INSERTION LOSS
8.0
INSERTION LOSS (dB)
S-1(dB)
S-2(dB)
7.0
ISOLATION (dB)
6.5
6.0
5.5
5.0
7.0
6.0
5.0
4.0
3.0
0
700
1400
2100
2800
3500
4200
FREQUENCY (MHz)
0
700
1400
2100
2800
3500
4200
FREQUENCY (MHz)
ZFRSC-42
VSWR
1.40
#S-VSWR
electrical schematic
#2-VSWR
#1-VSWR
1.30
VSWR
1.20
1.10
1.00
0
700
1400
2100
2800
3500
4200
FREQUENCY (MHz)
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
REV. A
M98898
ZFRSC-42
HY/TD/CP
060928
Mini-Circuits
ISO 9001 & ISO 14001
Certified
