Coaxial
Power Splitter/Combiner
16 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
1W max.
0.87W max.
ZFSC-16-3
50Ω
1 to 30 MHz
Features
• high isolation, 45 dB typ.
• rugged shielded case
BNC version shown
Applications
• HF/VHF
• test set-ups
• instrumentation
Connectors
BNC
SMA
CASE STYLE: R30
Model
ZFSC-16-3
ZFSC-16-3-S
Price
$172.95
$217.95
Qty.
(1-9)
(1-9)
Coaxial Connections
SUM PORT
PORT 1,2,3......,16
S(COM)
1,2,3......,16
Splitter Electrical Specifications
FREQ.
RANGE
(MHz)
f
L
-f
U
1-30
L = low range [f
L
to 10 f
L
]
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 12 dB
Outline Drawing
PHASE
UNBALANCE
(Degrees)
L
Max.
1
M
Max.
2
U
Max.
3
AMPLITUDE
UNBALANCE
(dB)
Max.
0.1
Typ. Min.
45
28
Typ. Max.
0.5
0.9
M = mid range [10 f
L
to f
U
/2]
U = upper range [f
U
/2 to f
U
]
Typical Performance Data
Frequency
(MHz)
1.00
1.80
2.60
3.80
5.00
6.50
8.00
9.50
12.00
15.00
18.00
22.00
25.00
28.00
30.00
Insertion Loss
(dB)
S-1
12.72
12.66
12.58
12.49
12.45
12.43
12.42
12.41
12.42
12.43
12.46
12.48
12.50
12.52
12.51
Amplitude
Unbalance
(dB)
0.02
0.03
0.02
0.02
0.02
0.03
0.02
0.02
0.03
0.02
0.02
0.02
0.02
0.02
0.03
Isolation
(dB)
Adjacent
44.33
45.35
46.07
46.75
47.14
47.08
46.77
46.29
45.60
44.71
43.88
42.62
41.86
41.12
40.65
Opposite
42.15
43.71
44.65
45.42
45.67
45.58
45.36
45.01
44.29
43.52
42.76
41.74
40.92
40.19
39.65
Phase
Unbalance
(deg.)
0.40
0.24
0.15
0.14
0.13
0.16
0.16
0.21
0.18
0.20
0.23
0.29
0.35
0.32
0.35
VSWR
S
1.24
1.21
1.19
1.16
1.14
1.13
1.12
1.12
1.12
1.12
1.12
1.13
1.14
1.14
1.15
VSWR
OUTPUT
1.23
1.20
1.17
1.15
1.13
1.11
1.10
1.10
1.09
1.09
1.09
1.08
1.08
1.08
1.08
ZFSC-16-3
INSERTION LOSS
15
INSERTION LOSS (dB)
70
ZFSC-16-3
ISOLATION
ADJACENT(dB)
ISOLATION (dB)
OPPOSITE(dB)
Outline Dimensions (
A
B
C
D
6.69 1.60 1.50 6.22
169.93 40.64 38.10 157.99
E
F
.24
.88
6.10 22.35
inch
mm
G
H
.36 .160
9.14 4.06
)
14
13
12
11
10
0
6
12
18
24
30
FREQUENCY (MHz)
ZFSC-16-3
VSWR
60
50
40
30
20
0
6
12
18
24
30
FREQUENCY (MHz)
J
K
L
M
N
P
.40
.69
.55
.66 5.72
.81
10.16 17.53 13.97 16.76 145.29 20.57
Q
wt.
.06 grams
1.52
500
1.5
#S-VSWR
1.4
VSWR
1.3
1.2
1.1
1.0
0
6
12
18
24
30
FREQUENCY (MHz)
#OUTPUT-VSWR
electrical schematic
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
REV. OR
M95084
ZFSC-16-1-75
HY/TD/CP
060310
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
ISO 9001 & ISO 14001
Certified
