BR206
POL Converter Module for 5 V System Intermediate Bus
Features and Benefits
• Industry standard footprint
• Improved soldering: gold-plated pads and side notches
• Synchronized rectifying type stepdown chopper
• High power
• High efficiency: 94.6% at V
IN
= 5 V, V
O
= 3.3 V, I
O
= 14 A
• Operating temperature range: –40°C to 85°C
• Input voltage range: 4.5 to 7.0 VDC
• Output voltage: 0.75 to 3.63 V
• Output current range: 0 to 20 A
• Operating frequency: 400 kHz
• Overcurrent protection function
Description
The BR206 is a thin type POL converter modules with an industry
standard exterior shape and footprint, responsive to very high
speed loads and compatible with ceramic capacitors.
It can be used as design-free POL converters for a 5 V system
intermediate bus. It can be configured easily, reducing overall
design time, and allowing reuse of designs.
Miniaturization was achieved by high frequency switching
technology, allowing saving space on the application PCB.
Soldering capability has been significantly improved by
adoption of end face through holes.
Package: Module
Applications:
• Communication devices
• Computer server
• Other low power conversion
33.0× 13.5
×
4.2 mm
Typical Application Circuit
V
PG
(5 V)
BR206
ON/OFF
VS+
VOUT
RTRIM
GND
R
TRIM
C
OUT
V
OUT
Power Good
V
IN
ON/OFF
GND
C
IN
PG
VIN
BR206-DS, Rev. 0.04E
February 6, 2013
SANKEN ELECTRIC CO., LTD.
http://www.sanken-ele.co.jp/en/
BR206
POL Converter Module for 5 V System Intermediate Bus
Selection Guide
Part Number
BR206
Output Voltage, V
OUT
(V)
0.75 to 3.63
Operating Frequency, f
OP
(kHz)
400
The polarity value for current specifies a sink as "+," and a source as “−,” referencing the IC.
Absolute Maximum Ratings
, valid at T
A
= 25°C
Characteristic
¯¯¯
ON/¯ ¯ ¯ Pin Voltage
OFF
PG Pin Voltage
Operating Temperature Range
Storage Temperature Range
Operating Humidity Range
Storage Humidity Range
Symbol
V
ONOFF
V
PG
T
A
T
stg
H
OP
H
stg
No condensation
No condensation
Sink current 7 mA
Notes
Pins
1
9
–
–
–
–
Rating
7
7
–40 to 85
–40 to 85
20 to 85
10 to 95
Unit
V
V
°C
°C
%
%
BR206-DS, Rev. 0.04E
SANKEN ELECTRIC CO., LTD.
2
BR206
POL Converter Module for 5 V System Intermediate Bus
Electrical Characteristics
Unless specifically noted, T
A
is 25°C
Characteristic
Input Voltage Range
Output Voltage
Output Current
Symbol
V
IN
V
OUT
I
OUT
Adjust with R
TRIM
With temperature derating
1.5 V
≥
V
OUT
≥
0.75 V, V
IN
= 4.5 to 5.5 V,
I
OUT
= 0 to I
OUT
(max), Operating Temperature
Range, R
TRIM
=1% accuracy
3.63 V
≥
V
OUT
≥
1.5 V, V
IN
= 4.5 to 5.5 V,
I
OUT
= 0 to I
OUT
(max), Operating Temperature
Range, R
TRIM
=1% accuracy
1.5 V
≥
V
OUT
≥
0.75 V, V
IN
= 4.5 to 7 V,
I
OUT
= 0 to I
OUT
(max), Operating Temperature
Range, R
TRIM
=1% accuracy
3.63 V
≥
V
OUT
≥
1.5 V, V
IN
= 4.5 to 7 V,
I
OUT
= 0 to I
OUT
(max), Operating Temperature
Range, R
TRIM
=1% accuracy
Ripple Voltage
1
V
rip
BW = 20 MHz, V
OUT
= 1.5 V,
I
OUT
= 0 to 20 A, C
OUT
= 400
μF
V
IN
= 5 V, I
OUT
= 20 A, V
OUT
= 1.2 V
Efficiency
Operating Frequency
Overcurrent Protection Threshold
Input Capacitor
2
Output Capacitor
2
Startup Time
Start Delay Time
η
f
OP
I
OUT(OCP)
C
IN
C
OUT
t
r
t
d
Hiccup
When input voltage is an ideal voltage source
When input voltage is an ideal voltage source
V
OUT
from 10% to 90% points
¯¯¯
With the ON/¯ ¯ ¯ pin high, measured from the
OFF
VIN pin switching high, to V
OUT
reaching 10% of
operating level (see figure 1)
With the VIN pin high, measured from the
¯¯¯
ON/¯ ¯ ¯ pin switching high, to V
OUT
reaching
OFF
10% of operating level (see figure 2)
Lower limit of Power Good
Upper limit of Power Good
¯¯¯
When the ON/¯ ¯ ¯ pin is set open, the
OFF
BR206 converter is turned on
¯¯¯
When the ON/¯ ¯ ¯ pin is pulled down to GND,
OFF
the BR206 converter is turned off
V
IN
= 5 V, I
OUT
= 20 A, V
OUT
= 3.3 V
V
IN
= 7 V, I
OUT
= 20 A, V
OUT
= 3.3 V
Test Conditions
Min.
4.5
0.75
0
–2.0
Typ.
5.0
–
–
–
Max.
7.0
3.63
20
2.0
Unit
V
V
A
%V
OUT
–4.0
–
4.0
%V
OUT
Output Voltage Accuracy
Err
VOUT
–3.0
–
3.0
%V
OUT
–5.0
–
–
–
–
–
–
240
400
–
–
–
–
84.8
93.1
93.2
400
30
–
–
2
2
5.0
50
–
–
–
–
–
5000
4000
–
–
%V
OUT
mV
p-p
%
%
%
kHz
A
μF
μF
ms
ms
¯¯¯
ON/¯ ¯ ¯ Start Delay Time
OFF
Interface Characteristics
Power Good
¯¯¯
ON/¯ ¯ ¯ Pin High Voltage
OFF
¯¯¯
ON/¯ ¯ ¯ Pin Low Voltage
OFF
1
See
2
Place
t
rcd
–
2
–
ms
P
WGL
P
WGH
V
IH
V
IL
92.5
108.0
1.8
–
96.0
111.0
–
–
98.5
114.0
–
0.5
%V
OUT
%V
OUT
V
V
the Ripple Voltage Measuring Method section.
bypass capacitors between the VIN and VOUT terminals and GND (see C
IN
and C
OUT
in the Typical Application Circuit diagram). Locate the
capacitor as close as possible to the terminal.
BR206-DS, Rev. 0.04E
SANKEN ELECTRIC CO., LTD.
3
BR206
POL Converter Module for 5 V System Intermediate Bus
Characteristic Definitions
ON/OFF
0
VIN
0
90%
0
t
d
Figure 1. Start Delay Time, t
d
, definition
V
OUT
10%
t
r
VIN
0
ON/OFF
0
90%
0
t
rcd
10%
t
r
V
OUT
¯¯¯
Figure 2. ON/¯ ¯ ¯ Start Delay Time, t
rcd
, definition
OFF
BR206-DS, Rev. 0.04E
SANKEN ELECTRIC CO., LTD.
4
BR206
POL Converter Module for 5 V System Intermediate Bus
Performance Characteristics
T
A
= 25°C
Efficiency versus Output Current
E
Efficiency v.s Output current
v
100
V
OUT
= 1.2 V
V
OUT
= 3.3 V
Effi
E ciency v.s Output current
v
100
E
Efficiency (%)
80
E
Efficiency(%)
80
60
40
20
0
0
10
Vin=4.5V
Vin=5.0V
Vin=5.5V
Vin=7V
60
40
20
0
0
10
Vin=4.5V
Vin=5.0V
Vin=5.5V
Vin=7V
I
OUT
(A)
20
I
OUT
(A)
20
Temperature Derating
Measuring condition:
Product soldered directly to 101.6 ×101.6 mm, 1.6 mm thick, 6-layer PCB
PCB is mounted vertically during measurement
Measuring locations
(Centers of top surface
of major components)
Airflow
BR206 Vout=1.2V Vin=12.0V
V
OUT
V
1.2 V, V
IN
= 12.0 V
=
Airflow=0m/s
/
24
24
20
20
16
16
12
12
8
8
In Still Air
24
24
20
20
16
16
12
12
8
8
BR206 Vout=1.2V Vin=12.0V
V
OUT
V
= 1.2 V, V
IN
= 12.0 V
Airflow=1.5m/s
/
1.5 m/s Airflow
Iout[A]
I
O
(A)
4
4
0
0
Iout[A]
I
O
(A)
40.0
40.0
50.0
50.0
60.0
60.0
T
A
[
(°C)
Ta ]
T
70.0
70.0
80.0
80.0
4
4
0
0
30.0
30.0
30.0
30.0
40.0
40.0
50.0
50.0
60.0
60.0
T
A
[
(°C)
T
Ta ]
70.0
70.0
80.0
80.0
BR206 Vout=1.2V
IN
= 12.0 V
V
V
OUT
= 3.3 V, V
Vin=12.0V
Airflow=0m/s
/
In Still Air
24
20
BR206 Vout=1.2V Vin=12.0V
V
V
OUT
= 3.3 V, V
IN
= 12.0 V
Airflow=1.5m/s
1.5 m/s Airfl
/
ow
24
20
24
20
16
12
8
4
0
40.0
40.0
50.0
50.0
24
20
16
12
8
4
0
40.0
40.0
50.0
50.0
12
Iout[A]
I
O
(A)
Iout[A]
I
O
(A)
16
16
12
8
8
4
0
4
0
30.0
30.0
T
A
]
Ta[
(°C)
T
60.0
60.0
70.0
70.0
80.0
80.0
30.0
30.0
T
A
]
Ta[
(°C)
T
60.0
60.0
70.0
70.0
80.0
80.0
BR206-DS, Rev. 0.04E
SANKEN ELECTRIC CO., LTD.
5
