ZX95-2170-S+: DescriptionVoltage Controlled Oscillator, 1730MHz Min, 2170MHz Max, ROHS COMPLIANT, CASE GB956; CategoryPassive components oscillator; File Size350KB，2 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com; Environmental Compliance

Download Datasheet Parametric Compare View All

ZX95-2170-S+ Overview

Voltage Controlled Oscillator, 1730MHz Min, 2170MHz Max, ROHS COMPLIANT, CASE GB956

ZX95-2170-S+ Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Mini-Circuits
package instruction	ROHS COMPLIANT, CASE GB956
Reach Compliance Code	not_compliant
ECCN code	EAR99
Other features	SMA FEMALE
Maximum control voltage	12 V
Minimum control voltage	0.5 V
Modulation sensitivity	59 MHz/V
Installation features	CHASSIS MOUNT
offset frequency	1 kHz
Maximum operating frequency	2170 MHz
Minimum operating frequency	1730 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Oscillator type	VOLTAGE CONTROLLED OSCILLATOR
Output Power	7.2 dBm
phase noise	-76 dBc/Hz
physical size	30.48mm x 19.05mm x 11.68mm
Maximum slew rate	34 mA
Nominal supply voltage	12 V
surface mount	NO
