ZX95-2210-S+ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> oscillator> ZX95-2210-S+

ZX95-2210-S+: DescriptionVoltage Controlled Oscillator, 2200MHz Min, 2240MHz Max, ROHS COMPLIANT, CASE GB956; CategoryPassive components oscillator; File Size341KB，2 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com; Environmental Compliance

Download Datasheet Parametric Compare View All

ZX95-2210-S+ Overview

Voltage Controlled Oscillator, 2200MHz Min, 2240MHz Max, ROHS COMPLIANT, CASE GB956

ZX95-2210-S+ Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Mini-Circuits
Objectid	2094847778
package instruction	ROHS COMPLIANT, CASE GB956
Reach Compliance Code	not_compliant
ECCN code	EAR99
compound_id	67725731
Other features	SMA-F CONNECTOR
Maximum control voltage	4.5 V
Minimum control voltage	0.5 V
Modulation sensitivity	25 MHz/V
Installation features	CHASSIS MOUNT
offset frequency	1 kHz
Maximum operating frequency	2240 MHz
Minimum operating frequency	2200 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Oscillator type	VOLTAGE CONTROLLED OSCILLATOR
Output Power	0.4 dBm
phase noise	-83 dBc/Hz
physical size	30.48mm x 19.05mm x 11.68mm
Maximum slew rate	35 mA
Nominal supply voltage	5 V
surface mount	NO

Preview
