Low Power Consumption CMOS Regulators
In recent years, along with rising demand for low power consumption sets, demand has also been rising for low power
consumption regulators that supply power.
NEC Electronics has adopted CMOS process technology to develop low power consumption regulators.
*Under development (as of December 2006)
Features
•
High current power supply ICs in line with growing capacity requirements of LSIs:
μPD121A10
(2.0A),
μPD121WxxA
(1.5A),
μPD12115
(1.0A)
•
Equipped with on-chip on/off function and having a 1
μA
circuit current when off:
μPD121A10, μPD121WxxA, μPD12115
•
Dual power supply input system contributing to low power consumption:
μPD121A10
Applications
•
Core power supply for 90 nm process ASICs (e.g., NEC Electronics CB-90):
μPD121A10
•
General-purpose power supplies for low voltage LSIs:
μPD121WxxA, μPD12115
•
Suited for use with digital home appliances, such as printers and DVD recorders.
Package Drawing
TO-252 5pin
6.7 MAX.
10.4 MAX.
Details of dual power supply input system (μPD121A10)
Voltage difference between the INPUT and OUTPUT pins can be minimized by
dividing the power supply into two parts.
I
O
=2A
V
IN
1.8V
V
DD
5.0V
V
OUT
1.0V
6
12345
Divides the power
supply into an input
(V
IN
) for obtaining
output (V
OUT
), and
into a bias voltage
(V
DD
) for IC operation.
2.4 MAX.
GND
Standard
Start
GND
Product Specifications
Product
μPD121A10T1F
μPD121W33AT1F
μPD121W25AT1F
μPD121W18AT1F
μPD121W00AT1F
μPD12115T1F
Output
Current
(A)
2.0
1.5
1.5
1.5
1.5
1.0
Output
Voltage
(V)
0.95~1.15
Variable
3.3
Fixed
2.5
Fixed
1.8
Fixed
1.8~3.3
Variable
1.5
Fixed
Input
Stability
(mV)
MAX.
Load
Stability
(mV)
MAX.
On/Off
Function
provided
provided
provided
provided
provided
provided
Circuit Current Circuit Current I/O Voltage Ripple
(μA)
When Off Difference Rejection Package
@I
O
=0A
MAX.
(μA)
MAX.
(V)
TYP.
(dB)
@1KHz
15
33
25
18
1%
15
15
33
25
18
1%
15
500
300
300
300
300
300
1
1
1
1
1
1
0.4
@I
O
=1.0A
0.6
@I
O
=1.5A
0.6
@I
O
=1.5A
0.6
@I
O
=1.5A
0.6
@I
O
=1.5A
0.6
@I
O
=1.0A
60
56
58
60
56
60
TO-252
5pin
TO-252
5pin
TO-252
5pin
TO-252
5pin
TO-252
5pin
TO-252
5pin
