kHz Range Through-Hole & SMD Ceramic resonators
ZTB-Type Through Hole & ZTB Y Type SMD
Standard Specifications
Part Number
(xxx = Freq in kHz)
ZTB xxx D
ZTB xxx D
ZTB xxx P
ZTB xxx E
ZTB xxx P
ZTB xxx J
ZTB xxx J
ZTB xxx Y
ZTB xxx Y
ZTB xxx Y
ZTB xxx Y
ZTB xxx Y
Frequency Range
190-249 kHz
250-374 kHz
375-429 kHz
430-509 kHz
509-699 kHz
700-999 kHz
1000-1250 KHz
375-429 kHz
430-509 kHz
509-699 kHz
700-999 kHz
1000-1250 KHz
Frequency Tol.
at 25
o
C
±1kHz
±1kHz
±2kHz
±2kHz
±2kHz
±0.5kHz
±0.5kHz
±2kHz
±2kHz
±2kHz
±0.5kHz
±0.5kHz
Resonant
Impedance
≤20Ω
≤20Ω
≤20Ω
≤20Ω
≤30Ω
≤70Ω
≤100Ω
≤20Ω
≤20Ω
≤30Ω
≤70Ω
≤100Ω
Temp. Stability
Ageing
Load Cap.
(C1)
330pF
220pF
120pF
100pF
100pF
100pF
100pF
120pF
100pF
100pF
100pF
100pF
(C2)
470pF
470pF
470pF
100pF
100pF
100pF
100pF
470pF
100pF
100pF
100pF
100pF
(-20
o
C to +80
o
C) for 10 Years
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
Dimensions (mm)
Part Number
ZTB
ZTB
ZTB
ZTB
ZTB
ZTB Y
ZTB Y
ZTB Y
ZTB Y
190-249 kHz
250-374 kHz
375-429 kHz
430-699 kHz
700-1250 kHz
375-429 kHz
430-509 kHz
510-699 kHz
700-1250 kHz
W
13.5mm
11.0mm
7.9mm
7.0mm
5.1mm
8.0mm
7.5mm
7.0mm
5.0mm
T
3.6mm
3.6mm
3.6mm
3.5mm
2.2mm
3.5mm
3.3mm
3.0mm
2.2mm
H
14.7mm
12.2mm
9.3mm
9.0mm
6.3mm
9.0mm
8.5mm
8.5mm
6.0mm
S
10.0mm
7.7mm
5.0mm
5.0mm
2.5mm
5.0mm
5.0mm
5.0mm
2.5mm
L
8.0mm
7.0mm
6.0mm
4.0mm
4.0mm
1.1mm
1.1mm
1.1mm
0.8mm
©
