LTC6702ITS8#PBF datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> LTC6702ITS8#PBF

LTC6702ITS8#PBF: DescriptionLTC6702 - Tiny Micropower, Low Voltage Dual Comparators; Package: SOT; Pins: 8; Temperature Range: -40°C to 85°C; CategoryAnalog mixed-signal IC Amplifier circuit; File Size344KB，12 Pages; ManufacturerLinear ( ADI ); Websitehttp://www.analog.com/cn/index.html; Environmental Compliance

Download Datasheet Parametric Compare View All

LTC6702ITS8#PBF Overview

LTC6702 - Tiny Micropower, Low Voltage Dual Comparators; Package: SOT; Pins: 8; Temperature Range: -40°C to 85°C

LTC6702ITS8#PBF Parametric

Parameter Name	Attribute value
Brand Name	Linear Technology
Is it Rohs certified?	conform to
Maker	Linear ( ADI )
Parts packaging code	SOT
package instruction	VSSOP, TSSOP8,.1
Contacts	8
Manufacturer packaging code	TS8
Reach Compliance Code	compliant
ECCN code	EAR99
Amplifier type	COMPARATOR
Maximum input offset voltage	5000 µV
JESD-30 code	R-PDSO-G8
JESD-609 code	e3
length	2.9 mm
Humidity sensitivity level	1
Number of functions	2
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output type	PUSH-PULL
Package body material	PLASTIC/EPOXY
encapsulated code	VSSOP
Encapsulate equivalent code	TSSOP8,.1
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
power supply	1.8/5 V
Certification status	Not Qualified
Nominal response time	500 ns
Maximum seat height	1 mm
Supply voltage upper limit	6 V
Nominal supply voltage (Vsup)	3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
width	1.625 mm

Preview

Download Datasheet

View All

LTC6702

Tiny Micropower,

Low Voltage

Dual Comparators

FEATURES

DESCRIPTION

The LTC

6702 is an extremely small dual comparator

designed to maximize battery life while providing both

speed and low voltage operation in applications where

board space is a premium.

These comparators operate on supplies between 1.7V and

5.5V, and have a maximum guaranteed propagation delay

of 500ns while drawing only 30μA maximum quiescent

current. Internal hysteresis desensitizes the LTC6702 to

input noise and makes it easy to use, even with slow mov-

ing signals. CMOS inputs allow the use of large source

impedances.

The LTC6702 is available in the 8-pin SOT-23 and the tiny

2mm

2mm DFN package.

LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear

Technology Corporation. ThinSOT is a trademark of Linear Technology Corporation. All other

trademarks are the property of their respective owners.

Low Supply Operation: 1.7V Minimum

Low Supply Current: 30μA/Comparator Maximum

Propagation Delay: 500ns Maximum (–40°C to

125°C)

3.2MHz Toggle Frequency

Input Voltage Range Extends 100mV Below Ground

Internal Hysteresis: 4mV

High Output Drive: TTL and CMOS Compatible

Speciﬁed at ±15mA (–40°C to 125°C),

Capacitive Load Handling to 10,000pF

Speciﬁed for –40°C to 125°C Temperature Range

Available in Low Proﬁle (1mm) ThinSOT™ and

2mm

2mm DFN Packages

APPLICATIONS

Battery Powered Systems

Window Comparators

Threshold Detectors/Discriminators

Clock Regeneration

Automotive Sensing and Controls

TYPICAL APPLICATION

Clock Regeneration Circuit

= 3V

600

= 400mV

REFERENCE

LT6650

1/2 LTC6702

PROPAGATION DELAY (ns)

LOAD

= 10pF

= 5V

STEP

= 100mV T

= 25°C

FALLING

400

RISING

300

Propagation Delay vs Input Overdrive

500

–

OUT

0.1μF

–

0.1μF

6702 TA01

RECOVERED

CLOCK

(UP TO 3.2MHz)

200

CLOCK INPUT > 100mV

P-P

100

50 60

20 30 40

INPUT OVERDRIVE (mV)

6702 TA01b

6702fa

LTC6702ITS8#PBF Related Products

	LTC6702ITS8#PBF	LTC6702HTS8#PBF	LTC6702CTS8#PBF	LTC6702HDC#PBF	LTC6702IDC#PBF	LTC6702CDC#PBF
Description	LTC6702 - Tiny Micropower, Low Voltage Dual Comparators; Package: SOT; Pins: 8; Temperature Range: -40°C to 85°C	LTC6702 - Tiny Micropower, Low Voltage Dual Comparators; Package: DFN; Pins: 8; Temperature Range: -40°C to 125°C	LTC6702 - Tiny Micropower, Low Voltage Dual Comparators; Package: SOT; Pins: 8; Temperature Range: 0°C to 70°C	LTC6702 - Tiny Micropower, Low Voltage Dual Comparators; Package: DFN; Pins: 8; Temperature Range: -40°C to 125°C	LTC6702 - Tiny Micropower, Low Voltage Dual Comparators; Package: DFN; Pins: 8; Temperature Range: -40°C to 85°C	LTC6702 - Tiny Micropower, Low Voltage Dual Comparators; Package: DFN; Pins: 8; Temperature Range: 0°C to 70°C
Brand Name	Linear Technology	Linear Technology	Linear Technology	Linear Technology	Linear Technology	Linear Technology
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to
Parts packaging code	SOT	DFN	SOT	DFN	DFN	DFN
package instruction	VSSOP, TSSOP8,.1	VSSOP, TSSOP8,.1	VSSOP, TSSOP8,.1	HVSON, SOLCC8,.08,18	HVSON, SOLCC8,.08,18	HVSON, SOLCC8,.08,18
Contacts	8	8	8	8	8	8
Manufacturer packaging code	TS8	DC8	TS8	DC8	DC8	DC8
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compli
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Amplifier type	COMPARATOR	COMPARATOR	COMPARATOR	COMPARATOR	COMPARATOR	COMPARATOR
Maximum input offset voltage	5000 µV	6000 µV	5000 µV	6000 µV	5000 µV	5000 µV
JESD-30 code	R-PDSO-G8	R-PDSO-G8	R-PDSO-G8	S-PDSO-N8	S-PDSO-N8	S-PDSO-N8
JESD-609 code	e3	e3	e3	e3	e3	e3
length	2.9 mm	2.9 mm	2.9 mm	2 mm	2 mm	2 mm
Humidity sensitivity level	1	1	1	1	1	1
Number of functions	2	2	2	2	2	2
Number of terminals	8	8	8	8	8	8
Maximum operating temperature	85 °C	125 °C	70 °C	125 °C	85 °C	70 °C
Minimum operating temperature	-40 °C	-40 °C	-	-40 °C	-40 °C	-
Output type	PUSH-PULL	PUSH-PULL	PUSH-PULL	PUSH-PULL	PUSH-PULL	PUSH-PULL
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	VSSOP	VSSOP	VSSOP	HVSON	HVSON	HVSON
Encapsulate equivalent code	TSSOP8,.1	TSSOP8,.1	TSSOP8,.1	SOLCC8,.08,18	SOLCC8,.08,18	SOLCC8,.08,18
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	SQUARE	SQUARE	SQUARE
Package form	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	260	260	260	260	260	260
power supply	1.8/5 V	1.8/5 V	1.8/5 V	1.8/5 V	1.8/5 V	1.8/5 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Nominal response time	500 ns	500 ns	500 ns	500 ns	500 ns	500 ns
Maximum seat height	1 mm	1 mm	1 mm	0.8 mm	0.8 mm	0.8 mm
Supply voltage upper limit	6 V	6 V	6 V	6 V	6 V	6 V
Nominal supply voltage (Vsup)	3 V	3 V	3 V	3 V	3 V	3 V
surface mount	YES	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	AUTOMOTIVE	COMMERCIAL	AUTOMOTIVE	INDUSTRIAL	COMMERCIAL
Terminal surface	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)
Terminal form	GULL WING	GULL WING	GULL WING	NO LEAD	NO LEAD	NO LEAD
Terminal pitch	0.65 mm	0.65 mm	0.65 mm	0.45 mm	0.45 mm	0.45 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	30	30	30	30	30	30
width	1.625 mm	1.625 mm	1.625 mm	2 mm	2 mm	2 mm
Maker	Linear ( ADI )	-	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )
