VISHAY
ZTE Series
Vishay Semiconductors
Voltage Stabilizers
Features
• Silicon Stabilizer Diodes
• Monolithic integrated analog circuits designed for
small power stabilizer and limitation circuits, pro-
viding low dynamic resistance and high-quality
stabilization performance as well as low noise. In
the reverse direction, these devices show the
behavior of forward-biased silicon diodes.
94 9367
• The end of the ZTE device marked with the cath-
ode ring is to be connected: ZTE1.5 and ZTE2 to
the negative pole of the supply voltage; ZTE2.4
thru ZTE5.1 to the positive pole of the supply volt-
age.
Mechanical Data
Case:
DO-35 Glass Case
Weight:
approx. 0.13 g
Packaging codes/options:
TR / 10k per 13 " reel (52 mm tape), 30k/box
TAP / 10k per Ammo tape, (52 mm tape), 30k/box
Absolute Maximum Ratings
T
amb
= 25 °C, unless otherwise specified
Parameter
Operating Current (see Table
"Characteristics")
Inverse Current
Power dissipation
Junction temperature
Storage temperature range
I
F
P
tot
T
J
T
S
100
300
1)
150
- 55 to + 150
mA
W
°C
°C
Test condition
Symbol
Value
Unit
(1) Valid provided that electrodes are kept at ambient temperature at a distance of 8 mm from case
Thermal Characteristics
T
amb
= 25 °C, unless otherwise specified
Parameter
Temperature Coefficient of the
stabilized voltage
Test condition
I
Z
= 5 mA
Part
ZTE1.5
ZTE2
ZTE2.4
ZTE5.1
Thermal resistance junction to
ambient air
(1) Valid provided that electrodes are kept at ambient temperature at a distance of 8 mm from case
Symbol
α
VZ
α
VZ
α
VZ
α
VZ
R
θJA
Min
Typ.
- 26
- 26
- 34
- 34
Value
Unit
10
-4
/°C
10
-4
/°C
10
-4
/°C
10
-4
/°C
400
1)
°C/W
Document Number 85813
Rev. 1.4, 27-Nov-03
www.vishay.com
1
ZTE Series
Vishay Semiconductors
Electrical Characteristics
T
amb
= 25 °C, unless otherwise specified
Parameter
Forward Voltage
Test condition
I
F
= 10 mA
Symbol
V
F
Min
Typ.
Max
1.1
VISHAY
Unit
V
Electrical Characteristics
Partnumber
Operating Voltage
(2)
V
Z
@ I
Z
= 5 mA
Ω
ZTE1.5
ZTE2
ZTE2.4
ZTE2.7
ZTE3
ZTE3.3
ZTE3.6
ZTE3.9
ZTE4.3
ZTE4.7
ZTE5.1
(2) Tested with pulses t = 5 ms
Dynamic Resistance
r
zj
@ I
Z
= 5 mA
V
13(<20)
18(<30)
14(<20)
15(<20)
15(<20)
16(<20)
16(<25)
17(<25)
17(<25)
18(<25)
18(<25)
Permissable operating current
(1)
I
z
@ T
amb
= 25 °C
mA
max
120
120
120
105
95
90
80
75
65
60
55
1.35 to 1.55
2.0 to 2.3
2.2 to 2.56
2.5 to 2.9
2.8 to 3.2
3.1 to 3.5
3.4 to 3.8
3.7 to 4.1
4.0 to 4.6
4.4 to 5.0
4.8 to 5.4
(1) Valid provided that electrodes are kept at ambient temperature at a distance of 8 mm from case
p
Typical Characteristics
(T
amb
= 25
°C
unless otherwise specified)
ZTE
5.1
4.3
3.6
3
18231
18232
Figure 1. Admissible Power Dissipation vs. Ambient Temperature
Figure 2. Dynamic resistance vs. operating current, normalized
www.vishay.com
2
Document Number 85813
Rev. 1.4, 27-Nov-03
VISHAY
