Frequency Mixers
print this page
Notes:
•
+10 dBm LO, up to +5 dBm RF
•
Absolute maximum power, voltage and current
ratings:
a. RF power, 50mW
b. Peak IF current, 40mA
ZP-2LH
LO Power Level 10 dBm
Pin Configuration
Port LO RF IF Gnd Ext. Case Gnd Not Used
ag
L R X
-
-
-
•
L = 50-100 MHz; M = 100-500 MHz
•
General Quality Control Procedures and
Environmental Specifications are given in
Mini-
Circuits Guarantees Quality.
Hi-Rel, MIL description are given in
Hi-Rel and
MIL
without notice.
•
Prices and Specifications subjects to change
Electrical Specifications
Outline Drawing
ZP-2LH
Frequency
MHz
LO/RF
IF
LO Power Level 10 dBm
Max. Conversion
Loss dB
Min. LO-RF Min. LO-IF
Isolation dB Isolation dB
M
U
L
M
U
Mid-Band Total Range L
50-1000 DC-1000
7.0
8.5
40 30 25 35 25 20
L=low range(f
L
to 10f
L
) M=mid range(10f
L
to f
U
/2) U=upper range(f
U
/2 to f
U
)
Typical Performance Data
ZP-2LH
RF
MHz
5.000
10.000
20.000
50.000
95.450
100.000
185.910
200.000
276.360
366.820
457.270
487.420
500.000
547.730
638.180
728.640
819.090
909.550
969.850
LO
MHz
Conversion Loss
(dB)
LO
LO
LO
+7
+10 +13
dBm dBm dBm
6.35
6.27
6.25
6.35
6.45
6.47
6.23
6.06
5.99
6.00
6.15
6.12
6.15
6.24
6.79
7.42
7.81
8.19
8.82
8.86
5.97
5.89
5.90
5.96
6.01
6.04
5.82
5.77
5.75
5.81
5.88
5.91
5.94
6.07
6.63
7.20
7.24
7.27
7.69
7.81
5.79
5.71
5.72
5.78
5.81
5.81
5.71
5.70
5.69
5.75
5.79
5.82
5.88
6.00
6.52
6.92
6.94
6.94
7.15
7.32
ISO
LO
(MHz)
5.000
10.000
20.000
50.000
95.450
100.000
185.910
200.000
276.360
366.820
457.270
487.420
500.000
547.730
638.180
728.640
819.090
909.550
969.850
1000.000
Isolation L-R (dB)
LO
+7
dBm
50.42
50.26
50.09
50.26
50.20
49.96
49.37
48.99
48.39
48.15
45.89
43.82
45.19
54.75
49.32
42.97
39.80
39.91
41.20
42.93
LO
+10
dBm
52.74
52.59
52.51
52.73
52.59
52.35
52.03
52.24
51.93
52.59
47.42
45.90
48.30
57.22
48.69
42.92
41.04
41.87
44.77
50.08
LO
+13
dBm
55.33
55.18
55.01
55.34
55.11
55.06
55.00
55.94
56.47
58.42
48.34
47.93
51.48
57.14
47.24
42.20
42.19
45.54
52.60
45.94
Isolation L-I (dB)
LO
+7
dBm
92.39
88.15
82.91
75.29
76.31
76.24
64.85
56.89
53.30
50.00
53.50
48.88
45.61
39.24
37.98
37.56
32.89
30.39
29.06
28.12
LO
+10
dBm
87.33
81.78
76.47
68.83
68.37
67.59
63.99
62.23
58.87
53.25
55.40
49.79
46.54
40.10
37.95
36.76
32.27
29.47
28.21
26.90
LO
+13
dBm
84.57
79.01
73.93
65.98
65.72
63.42
60.35
57.60
57.65
55.12
52.82
48.91
46.57
40.86
38.10
35.98
31.54
28.88
27.71
26.19
Case Style - GG60
(inch,mm ) weight: 75 grams.
A
B
C
D
E
F
G
H
J
2.31
1.20
.60 .125 2.062
.30
.53
.63
58.674 30.480 15.240 3.175 52.375 7.620 13.462 16.002
K
L
M
N
P
Q
R
S
T
Tolerance: .x ± .1 .xx ± .03 .xxx ± .015 inch.
Material and Finish:
Case material: aluminum alloy. Finish: grey paint or yellow
iridite.
Connectors:
Connectors: BNC standard. SMA on request, consult factory.
35.000
40.000
50.000
80.000
65.454
70.000
155.909
170.000
246.364
336.818
427.273
457.424
470.000
517.727
608.182
698.636
789.091
879.546
939.849
1000.000 970.000
RF/LO VSWR RF port VSWR LO port
FREQ.
(MHz)
5.000
IF
VSWR IF port
Ø detection
LO LO LO LO LO LO
LO LO LO
max.DC DC
FREQ.
,FREQ.
+7 +10 +13 +7 +10 +13
+7 +10 +13
output offset
(MHz)
MHz
dBm dBm dBm dBm dBm dBm
dBm dBm dBm
mV
mV
1.19 1.25 1.36 2.01 2.82 3.90
5.000
1.73 1.46 1.19
5.00
-332.70 -2.03
-332.60 -1.99
-329.00 -1.95
-343.00 -2.00
10.000 1.74 1.47 1.19 10.00
20.000 1.73 1.46 1.19 20.00
50.000 1.76 1.48 1.21 50.00
10.000 1.10 1.18 1.30 1.82 2.63 3.70
20.000 1.06 1.16 1.28 1.85 2.68 3.75
50.000 1.08 1.18 1.30 1.81 2.62 3.65
100.000 1.10 1.19 1.31 1.74 2.50 3.48
165.130 1.12 1.21 1.32 1.73 2.50 3.48
200.000 1.13 1.22 1.33 1.68 2.40 3.31
265.220 1.13 1.23 1.33 1.72 2.48 3.42
345.280 1.14 1.23 1.32 1.68 2.38 3.24
425.350 1.13 1.22 1.30 1.72 2.39 3.21
500.000 1.12 1.21 1.28 1.77 2.42 3.21
525.430 1.12 1.20 1.26 1.77 2.42 3.20
552.120 1.12 1.19 1.25 1.80 2.43 3.18
605.500 1.11 1.18 1.23 1.84 2.44 3.16
685.570 1.10 1.15 1.17 1.90 2.49 3.19
765.640 1.08 1.11 1.14 1.93 2.47 3.13
845.700 1.02 1.05 1.12 1.99 2.47 3.05
919.100 1.13 1.15 1.24 2.10 2.57 3.11
972.470 1.28 1.30 1.39 2.13 2.60 3.12
100.000 1.82 1.54 1.25 95.45 -338.30 -0.06
165.130 1.91 1.63 1.35 100.00 -331.90 -2.02
200.000 1.97 1.69 1.42 185.91 -357.00 -1.98
265.220 2.12 1.84 1.56 200.00 -356.20 -1.92
345.280 2.38 2.08 1.78 276.36 -342.60 -1.81
425.350 2.62 2.33 2.02 366.82 -332.00 -1.45
500.000 2.86 2.55 2.23 457.27 -287.51 -1.36
525.430 2.92 2.61 2.30 487.42 -273.52 -1.14
552.120 3.01 2.68 2.36 500.00 -271.37 -1.18
605.500 3.12 2.79 2.46 547.73 -272.60 -1.49
685.570 3.15 2.80 2.48 638.18 -282.98 -1.28
765.640 3.13 2.76 2.44 728.64 -235.17 -0.97
845.700 3.06 2.67 2.31 819.09 -205.55 -0.81
919.100 2.95 2.53 2.15 909.55 -207.63 -0.31
972.470 2.88 2.45 2.04 969.85 -209.87 -0.06
1000.000 1.35 1.38 1.47 2.12 2.59 3.12 1000.000 2.86 2.42 1.99 1000.00 -204.55 0.27
