Power Splitter/Combiner
2 Way-90°
Operating Temperature
Storage Temperature
Power Input (as a splitter)
SMA Connectorized
ZX10Q-2-34+
ZX10Q-2-34
50Ω
-40°C to 85°C
-55°C to 100°C
20W* max.
2500 to 3400 MHz
Features
• low insertion loss, 0.4 dB typ.
• excellent amplitude unbalance
• very good phase unbalance
• small size
• low cost
• protected by U.S Patent 6,790,049
Maximum Ratings
* Derate linearly to 7W at 100°C ambient.
Permanent damage may occur if any of these limits are exceeded.
CASE STYLE: GW1052
Connectors Model
SMA
ZX10Q-2-34-S(+)
Price
$29.95
Qty.
(1-24)
Coaxial Connections
INPUT PORT
PORT 1 (+90°)
PORT 2 (0°)
50 OHM TERM EXTERNAL**
1
2
3
4
Applications
• balanced amplifiers
• modulators
• MMDS
• defense communications
FREQ.
RANGE
(MHz)
f
L
-f
U
2500-3400
2500-2800
2800-3400
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Electrical Specifications (T
AMB
=25°C)
ISOLATION
(dB)
Typ.
32
26
Min.
20
20
INSERTION LOSS (dB)
Avg. of Coupled Outputs
ABOVE 3 dB
Typ.
0.4
0.5
Max.
0.6
0.7
PHASE
UNBALANCE
(Degrees)
Typ.
1.0
1.0
Max.
3.0
4.0
AMPLITUDE
UNBALANCE
(dB)
Typ.
0.4
0.5
Max.
0.9
1.2
Typical Performance Data
** Recommended external termination
Mini-Circuits Part. No. ANNE-50L
Frequency
(MHz)
Total Loss
1
(dB)
S-1
2500.00
2525.00
2600.00
2650.00
2700.00
2825.00
2850.00
2950.00
3000.00
3075.00
3100.00
3175.00
3275.00
3375.00
3400.00
2.98
2.99
3.03
3.05
3.07
3.11
3.11
3.12
3.12
3.12
3.11
3.10
3.07
3.03
3.02
QCN-34
TOTAL LOSS
4.5
S-1
TOTAL LOSS (dB)
4.0
3.5
3.0
2.5
2.0
2500 2600 2700 2800 2900 3000 3100 3200 3300 3400
FREQUENCY (MHz)
S-2
ISOLATION (dB)
S-2
3.74
3.72
3.68
3.67
3.65
3.63
3.63
3.64
3.65
3.68
3.68
3.72
3.79
3.87
3.90
Amplitude
Unbalance
(dB)
0.76
0.73
0.65
0.61
0.58
0.52
0.52
0.52
0.53
0.56
0.57
0.62
0.72
0.84
0.88
Isolation
(dB)
Phase
Unbalance
(deg.)
89.55
89.57
89.61
89.64
89.66
89.71
89.72
89.72
89.76
89.78
89.78
89.80
89.82
89.87
89.87
VSWR
S
VSWR
1
VSWR
2
Outline Drawing
28.30
28.62
29.72
30.42
31.14
32.59
32.87
33.11
33.20
32.83
32.62
32.01
31.16
30.26
29.99
1.07
1.07
1.06
1.05
1.04
1.03
1.03
1.02
1.02
1.02
1.02
1.03
1.04
1.05
1.05
QCN-34
ISOLATION
1.08
1.08
1.07
1.06
1.06
1.05
1.05
1.04
1.04
1.03
1.03
1.02
1.02
1.01
1.01
1.07
1.07
1.05
1.04
1.03
1.02
1.02
1.03
1.03
1.04
1.05
1.05
1.06
1.07
1.08
1. Total Loss = Insertion Loss + 3dB splitter loss.
60
50
40
30
20
10
Outline Dimensions (
inch
)
mm
A
1.04
26.42
H
.25
6.35
B
.60
15.24
J
.50
12.70
C
.75
19.05
K
.11
2.79
D
.50
12.70
L
.820
20.83
E
.10
2.54
M
.106
2.69
F
.17
4.32
G
.25
6.35
0
2500 2600 2700 2800 2900 3000 3100 3200 3300 3400
FREQUENCY (MHz)
N
wt.
.12 grams
3.05
21.0
PHASE UNBALANCE
(deg.)
QCN-34
PHASE UNBALANCE
95
93
91
89
87
85
2500 2600 2700 2800 2900 3000 3100 3200 3300 3400
electrical schematic
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
FREQUENCY (MHz)
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. D
M127604
ZX10Q-2-34
AD/CP/AM
120130
