Coaxial
Power Splitter/Combiner
10 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
10W max.
1.5W max.
ZC10PD-900
50Ω
800 to 900 MHz
Features
• good isolation, 25dB typ.
• up to 10W power input as splitter
• rugged, shielded case
Applications
•
•
•
•
cellular
UHF
signal processing
communication systems
CASE STYLE: AB204
Connectors
SMA
Model
ZC10PD-900-S
Price
$178.95
Qty.
(1-9)
Coaxial Connections
SUM PORT
PORT 1,2,3......,10
S
......,10
1,2,3
Splitter Electrical Specifications
FREQ.
RANGE
(MHz)
f
L
-f
U
800-900
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 10 dB
Outline Drawing
AMPLITUDE
UNBALANCE
(dB)
Max.
0.8
Typ. Min.
25 20
Typ. Max.
1.5
2.0
Typical Performance Data
Frequency
(MHz)
750.00
767.50
785.50
800.00
814.50
826.50
844.00
862.00
875.00
891.00
903.00
920.50
938.00
944.00
950.00
Insertion Loss
(dB)
11.41
11.45
11.43
11.43
11.48
11.43
11.46
11.45
11.44
11.42
11.43
11.40
11.43
11.42
11.43
Amplitude
Unbalance
(dB)
0.37
0.31
0.29
0.27
0.28
0.30
0.25
0.25
0.27
0.32
0.33
0.41
0.40
0.40
0.39
Isolation
(dB)
1-2
27.37
29.27
31.56
33.26
34.67
35.21
34.99
33.76
32.81
32.01
31.41
30.62
30.15
29.95
29.85
1-5
35.92
36.54
34.08
31.85
29.97
28.75
27.33
26.17
25.49
24.85
24.52
24.07
23.81
23.70
23.63
VSWR
S
1.11
1.09
1.06
1.03
1.01
1.02
1.04
1.07
1.09
1.11
1.13
1.16
1.19
1.20
1.21
VSWR
1
1.17
1.17
1.16
1.15
1.15
1.14
1.13
1.12
1.11
1.10
1.09
1.08
1.06
1.06
1.06
ZC10PD-900
INSERTION LOSS
12.0
INSERTION LOSS (dB)
40
35
30
25
20
10.0
800
820
840
860
880
900
15
800
ZC10PD-900
ISOLATION
A
6.13
155.70
G
.116
2.95
B
3.00
76.20
H
.50
12.70
C
.53
13.46
J
.25
6.35
D
E
.162 5.962
4.11 151.43
K
1.13
28.70
L
.500
12.70
F
1.500
38.10
wt
gram s
215
11.0
10.5
ISOLATION (dB)
Outline Dimensions (
inch
)
mm
11.5
ADJACENT
OPPOSITE
820
840
860
FREQUENCY (MHz)
880
900
FREQUENCY (MHz)
ZC10PD-900
VSWR
1.4
#S-VSWR
1.3
VSWR
1.2
1.1
1.0
800
#1-VSWR
electrical schematic
820
840
860
880
900
FREQUENCY (MHz)
REV. OR
M95083
ZC10PD-900
HY/TD/CP
060119
