Power Splitter/Combiner
10 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
10W max.
1.5W max.
Coaxial
ZC10PD-900W
HT-Series
Tight Spot
SMA Wrench
50Ω
750 to 900 MHz
Features
• low insertion loss, 0.4 dB typ.
• high isolation, 30 dB typ.
• up to 10W power input as splitter
• rugged shielded case
Generic photo used for illustration purposes only
CASE STYLE: AB204
Connectors Model
SMA
ZC10PD-900W-S
Permanent damage may occur if any of these limits are exceeded.
Applications
S
Coaxial Connections
SUM PORT
PORT 1,2,3,.....,10
1,2,3,.....,10
• UHF
• cellular
• communication systems
Electrical Specifications
FREQ.
RANGE
(MHz)
f
L
-f
U
750-900
Outline Drawing
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 10 dB
PHASE
UNBALANCE
(Degrees)
Max.
—
AMPLITUDE
UNBALANCE
(dB)
Max.
0.6
Typ. Min.
30
20
Typ. Max.
0.4
1.0
VSWR, input 1.2:1 typ., 1.6:1 max; output 1.2:1 typ., 1.35:1 max.
Typical Performance Data
Freq.
(MHz)
Total Loss
1
(dB)
Amplitude
Unbalance
(dB)
1-2
750.00
770.00
790.00
802.00
810.00
10.52
10.36
10.38
10.40
10.38
10.35
10.36
10.38
10.41
10.44
10.46
10.47
10.46
10.44
10.40
ZC10PD-900W-S
TOTAL LOSS
11.5
TOTAL LOSS (dB)
ISOLATION (dB)
Isolation
(dB)
1-5
29.42
31.56
34.32
36.49
38.26
41.48
43.73
44.29
42.31
38.86
36.90
34.54
34.02
33.02
31.71
Phase
Unbalance
(deg.)
6.46
6.51
6.72
6.81
6.80
6.80
6.84
6.98
7.13
7.25
7.29
7.24
7.27
7.30
7.45
ZC10PD-900W-S
ISOLATION
VSWR
S
VSWR
1
0.19
0.13
0.14
0.12
0.13
0.13
0.13
0.11
0.13
0.15
0.15
0.15
0.16
0.14
0.17
28.33
30.23
32.67
34.49
35.91
38.68
41.08
45.39
46.80
43.33
40.54
37.25
36.56
35.31
33.71
1.29
1.24
1.19
1.16
1.15
1.13
1.12
1.13
1.14
1.18
1.21
1.26
1.27
1.30
1.35
1.12
1.12
1.12
1.12
1.12
1.12
1.12
1.12
1.13
1.13
1.13
1.14
1.14
1.14
1.14
Outline Dimensions (
inch
)
mm
A
6.13
155.70
G
.116
2.95
B
3.00
76.20
H
.50
12.70
C
.53
13.46
J
.25
6.35
D
E
.162 5.962
4.11 151.43
K
1.13
28.70
L
.50
12.70
F
1.500
38.10
wt
grams
207
822.00
830.00
842.00
850.00
862.00
870.00
882.00
885.00
891.00
900.00
1. Total Loss = Insertion Loss + 10dB splitter loss.
50
45
11.0
40
35
30
25
20
ADJACENT
OPPOSITE
10.5
10.0
750
775
800
825
850
875
900
15
750
775
FREQUENCY (MHz)
800
825
850
FREQUENCY (MHz)
875
900
1.4
1.3
VSWR
1.2
1.1
1.0
ZC10PD-900W-S
VSWR
#S-VSWR
#1-VSWR
electrical schematic
750
775
800
825
850
875
900
FREQUENCY (MHz)
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
www.minicircuits.com
P.O. Box 350166, Brooklyn, NY 11235-0003 (718) 934-4500 sales@minicircuits.com
Mini-Circuits
®
REV. B
M151107
ZC10PD-900W
HY/TD/CP
200406
