Technische Daten
Induktiver Näherungsschalter
Type:
KIB-N44PP/015 KLS
Art. Nr.:
650.2954.009
Anschlußschema
1
I
2/4
3
5
-
Hilfsausgang
+
Der Hilfsausgang ist aktiv, wenn die rote LED
(Einstellhilfe) blinkt.
Mittels eines eingebauten Umschalters kann
die Funktion PNP Schließer oder PNP Öffner
gewählt werden.
Kenndaten nach EN 60947-5-2
Elektrische Daten
Bemessungsbetriebsspannungsbereich
Bemessungsisolationsspannung
Bemessungsstoßspannungsfestigkeit
Spannungsfall
Gebrauchskategorie
Bemessungsbetriebsstrom
Reststrom
Leerlaufstrom
Schutzart
Art des Kurzschlußschutzes
Bemessungsschaltabstand
gesicherter Schaltabstand
Wiederholgenauigkeit
Hysterese
Schaltfrequenz
Schaltelementfunktion
Einbauart
Verpolschutz
Ausgang
Bereitschaftsverzug
Elektromagnetische Verträglichkeit (EMV)
Hochfrequenzbeeinflussungsfestigkeit
Elektrostatische Entladungsfestigkeit
Transientenfestigkeit
Störaussendung
Stoßspannungsfestigkeit
Mechanische Daten
Umgebungstemperatur
Gehäuse
Funktionsanzeige
Anschlußart
U
B
U
i
U
imp
U
d
I
e
I
r
I
0
s
n
s
a
R
H
f
10 60V DC
75V DC
500V
v
2,4V
DC-13 bei I
e
= 50mA und U
e
= 33V DC
v
400mA (Hilfsausgang: 50mA)
< 0,1mA
< 10mA
IP 65 (nur mit geschlossenem Deckel und montierter Kabelverschraubung)
taktend
15mm
0 ... 12,2mm
v
5%
[
10%
100Hz
DC, Programmierbar
bündig
ja
dauerkurzschluß- und überlastfest
v
50ms
IEC 61000-4-3
IEC 61000-4-2
IEC 61000-4-4
EN55011
IEC 255-5
-25°C bis +70°C
PA 6.6, rot / schwarz
LED, grün: Betriebsspannung
LED, gelb: Ausgang
LED, rot: Einstellhilfe
Schraubklemmen
t
v
12.02.03/0046-03
Diese Kopie wird bei technischen Änderungen nicht berichtigt oder zurückgezogen.
Bernstein AG,
Postfach 1164, D-32437 Porta Westfalica
Technical Data
Inductive Proximity Switch
Type:
KIB-N44PP/015 KLS
Part. No.:
650.2954.009
Wiring Diagram
1
I
2/4
3
5
-
Auxiliary output
+
The auxiliary output is active, if the red LED
(adjusting help) flashes.
The PNP normally open or PNP normally closed
function can be selected via an integrated switch.
Technical Data according to EN 60947-5-2
Elektrical Data
O
perational voltage range
Rated insolation voltage
Rated impulse withstand voltage
Voltage drop
Utilization category
Rated operational current
Off-state current
No-load supply current
Type of protection
Short-circuit protection
Rated operating distance
Assured operating distance
Repeat accuracy
Differential travel (hysteresis)
Frequency of operating cycles
Switching function
Mounting
False polarity protection
Output
Time delay before availability
Elektromagnetic compatibility (EMC)
Electromagnetic field test
Electrostatic discharge test
Electrical fast transient immunity test
Radiated disturbance field strength
Impulse voltage withstandability
Mechanical Data
Operating temperature
Housing
Indication
Termination type
U
B
U
i
U
imp
U
d
I
e
I
r
I
0
s
n
s
a
R
H
f
10 60V DC
75V DC
500V
v
2,4V
DC-13 @ I
e
= 50mA and U
e
= 33V DC
v
400mA (auxiliary output: 50mA)
< 0,1mA
< 10mA
IP 65 (only with locked cover and fixed cable pland)
pulsed
15mm
0 ... 12,2mm
v
5%
[
10%
100Hz
DC, programmable switch
flush
yes
permanent overload and s.c.p.
v
50ms
IEC 61000-4-3
IEC 61000-4-2
IEC 61000-4-4
EN55011
IEC 255-5
-25°C bis +70°C
PA 6.6, red / black
LED, green: operating voltage
LED, yellow: output
LED, red:
adjusting help
screw type terminals
t
v
12.02.03/0046-03
Data Sheets are subjects to change without further notice.
Bernstein AG,
P.o. box 1164, D-32437 Porta Westfalica
