Pin strip |
Spacing 5.0 mm
STL950/..F-5.0-V-GREEN
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
-
-
-
-
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
1.4 mm
Brass
Copper Alloy
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 5.0 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
20.00
25.00
30.00
35.00
40.00
45.00
50.00
55.00
60.00
65.00
70.00
75.00
80.00
85.00
90.00
95.00
100.00
105.00
110.00
115.00
120.00
125.00
130.00
Article Designation
STL950/2F-5.0-V-GREEN
STL950/3F-5.0-V-GREEN
STL950/4F-5.0-V-GREEN
STL950/5F-5.0-V-GREEN
STL950/6F-5.0-V-GREEN
STL950/7F-5.0-V-GREEN
STL950/8F-5.0-V-GREEN
STL950/9F-5.0-V-GREEN
STL950/10F-5.0-V-GREEN
STL950/11F-5.0-V-GREEN
STL950/12F-5.0-V-GREEN
STL950/13F-5.0-V-GREEN
STL950/14F-5.0-V-GREEN
STL950/15F-5.0-V-GREEN
STL950/16F-5.0-V-GREEN
STL950/17F-5.0-V-GREEN
STL950/18F-5.0-V-GREEN
STL950/19F-5.0-V-GREEN
STL950/20F-5.0-V-GREEN
STL950/21F-5.0-V-GREEN
STL950/22F-5.0-V-GREEN
STL950/23F-5.0-V-GREEN
STL950/24F-5.0-V-GREEN
Article Number
50950026101E
50950036101E
50950046101E
50950056101E
50950066101D
50950076101D
50950086101D
50950096101D
50950106101D
50950116101D
50950126101D
50950136101D
50950146101D
50950156101D
50950166101D
50950176101D
50950186101D
50950196101D
50950206101D
50950216101D
50950226101D
50950236101D
50950246101D
PU
100
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule -
min
Stranded with Ferrule -
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Flansch
Gewindeeinsatz
Contact Pin
Colours
GREEN
BASALT GREY
LIGHT GREEN
21
RAL6018
RAL7012
similar RAL 6018
RAL6018
22
23
24
RAL7012
similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Accessories
Counterparts (Spacing 5.0 mm)
Pin Strip/Terminal Blocks
AK950
AK4951
Figure
Designation
Coding star CS2-5.0/5.08-RED
Article Number
50000000024
Dividing element SE-STL950-GREEN
50950000002
Ratings
Usegroup
Rated Voltage
Rated Current
Overvoltage Category
Test Voltage
Pollution Degree
B
300 V
15 A
1.6 kV
C
150 V
15 A
1.6 kV
D
300 V
10 A
1.6 kV
250 V
12 A
III
4.0 kV
3
