NTCLE413, NTCLE428
www.vishay.com
Vishay BCcomponents
NTC Thermistors, Mini Epoxy PVC Insulated Leads
FEATURES
• High adhesive strength between the PVC wire
and the encapsulating lacquer
• Accurate down to ± 0.3°C
• Small body of max. 3 mm for easy installation
• Material categorization:
For definitions of compliance please see
www.vishay.com/doc?99912
APPLICATIONS
• Temperature measurement, sensing and control
• On battery packs, heat-sinks, tubing, enclosures, etc.
DESCRIPTION
QUICK REFERENCE DATA
PARAMETER
Resistance value at 25 °C
Tolerance on
R
25
-value
B
25/85
-value
Tolerance on B
25/85
Operating temperature
range at zero dissipation
Maximum power
dissipation at 55 °C
Accuracy of temperature
measurement (for 1%
types)
Dissipation factor
(in still air)
Response time
(in oil)
Climatic category
(LCT/UCT/days)
Minimum dielectric
withstanding voltage
between leads and
coated body
Weight (40 mm length)
VALUE
4.7K to 100K
±1.0 to ± 5.0
3435 to 4190
± 0.5 to ± 1.5
- 40 to 105
100
± 0.5 between 0 and 40
± 1.0 between - 40 and 80
3
2.5
40/105/28
UNIT
%
K
%
°C
mW
°C
mW/K
s
These sensors consist of small NTC chip soldered between
stranded Awg#30, 105 °C resistant, PVC (UL2651), or PVC
105 °C single hook-up wires (acc. to UL1061). Terminations
are solder dipped. They are lacquered and insulated with a
black epoxy coating.
MARKING
Black lacquered body without additional mark
PACKAGING
SPQ: 125 items (for standard 40 mm lead wire length)
MOUNTING
By soldering the wire end, or crimping connector. The body
can be inserted in a tube, free in air, tape attached or glued.
Not intended for fluid immersed applications or continuous
contact with water. Not for potting in hard material or
over-molding applications. Consult Vishay for specific
application or mounting.
DESIGN-IN SUPPORT
500
0.2
V
RMS
g
• For complete curve computation in °C or °F, visit:
www.vishay.com/resistors-non-linear/curve-computation-list
• Other R/T curves available on request
• The lead length can be customized
• Connectors can be added to the wire end
DIMENSIONS
in millimeters
Electronic components of assessed quality measured in accordance with IEC 60539-1
Outline
NTCLE413E2
NTCLE428E3
Ød
D
L2
L1
L
W
L3
L1
L
L2
Ød
D
Ø 0.30
D
L
L1
L2
L3
W
Ød
Revision: 12-Oct-12
Ø 3 max.
40 ± 5 (or refer to table SAP description)
10 max.
3±1
15 (for information)
2 (for information)
1 (for information)
Ø 3 max.
40 ± 5 (or refer to table SAP description)
10 max.
3±1
-
-
0.85 (for information)
Document Number: 29078
1
For technical questions, contact:
nlr@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
NTCLE413, NTCLE428
www.vishay.com
Vishay BCcomponents
GENERAL ORDER INFORMATION
PART NUMBER: NTC L E413 E2 103 H 400
N
T
C
L
E
4
1
3
E
2
1
0
3
H
4
0
0
ADDITIONAL
INFORMATION
Blank
= No special
Special B
25/85
value:
L
(low):
3000
B
25/85
< 3500
M
(medium):
3500
B
25/85
< 3750
H
(high):
3750
B
25/85
< 4000
X
(very high):
4000
B
25/85
< 4250
PRODUCT
EXECUTION
FAMILY
NTC
L
= Leaded
TYPE
E413
=
Epoxy,
PVC
Awg#30
105 °C
UL2651
E428
=
Epoxy,
PVC
Awg#30
105°C
single
hook-up
RoHS COMPLIANCE
TERMINATION TYPE
E2
= Sn alloy
E3
= Pure Sn
E4
= Pure metal
(other than Sn)
R
25
-VALUE
R
25
TOL.
LEAD LENGTH
abc
= ab x 10
c
(in millimeters)
Examples:
400
= 40 x 10
0
= 40 mm
102
= 10 x 10
2
= 1000 mm
472
= 47 x 10
2
= 4700
F
=1%
2
= 5000
502
= 50 x 10
G
=2%
103
= 10 x 10
3
= 10 000
H
= 3 %
473
= 47 x 10
3
= 47 000
J
= 5 %
104
= 10 x 10
4
= 100 000
Cxxxxx
= Customized
C:
With 2 poles connector
MOLEX 50212-8000/
MOLEX 35507-0200,
pitch 2 mm
ELECTRICAL DATA AND ORDERING INFORMATION
SAP MATERIAL AND ORDERING NUMBER
(2)
k
NTCLE413E2472H400
NTCLE413E2502H400
NTCLE413E2103F400L
NTCLE413E2103F520L
NTCLE413E2103F102L
NTCLE413E2103J520L
NTCLE413E2103H400
NTCLE413E3103H301C
(1)
NTCLE413E2103H401
NTCLE413E2473H400
NTCLE413E2104H400
NTCLE428E3472H400
NTCLE428E3502H400
NTCLE428E3103F400L
NTCLE428E3103F520L
-
-
NTCLE428E3103H400
NTCLE428E3103H301
-
NTCLE428E3473H400
-
4.7
5
10
10
10
10
10
10
10
47
100
R
25
±%
3
3
1
1
1
5
3
3
3
3
3
K
3984
3984
3435
3435
3435
3435
3984
3984
3984
4090
4190
B
25/85
±%
0.5
0.5
1
1
1
1
0.5
0.5
0.5
1.5
1.5
mm
40
40
40
52
1000
52
40
300
400
40
40
L
R/T TABLE
± mm
5
5
5
5
20
5
5
10
10
5
5
Table 1
Table 2
Table 3
Table 3
Table 3
Table 4
Table 5
Table 5
Table 5
Table 6
Table 7
Note
(1)
NTCLE413E2103H301C:
“C” = Connector MOLEX
50212-8000 or equivalent. Connector housing, 2 poles. MOLEX 35507-0200 Sherlock 2.0 mm.
(2)
Preferred types are marked in
bold
Revision: 12-Oct-12
Document Number: 29078
2
For technical questions, contact:
nlr@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
