SMT POWER INDUCTORS
Flat Coils - PG0077NL and PG0084NL Series
Height:
6.5mm Max (PG0077) and 4.40mm Max (PG0084)
Footprint:
14.5mm x 13.0mm Max
Current Rating:
up to 45A
Inductance Range:
0.38µH to 2.65µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +95°C
1
Part
8,9
Number
PG0077.401NL
PG0077.801NL
PG0077.142NL
PG0077.202NL
PG0077.282NL
PG0084.351NL
PG0084.651NL
PG0084.112NL
Inductance
@Irated
(μH TYP)
0.34
0.68
1.16
1.66
2.32
0.28
0.52
0.88
2
Irated
3
(A)
45
35
27
23
19
40
32
24
DCR
(m
Ω)
TYP
0.75
1.20
2.00
2.80
4.10
1.30
2.30
3.60
MAX
0.80
1.30
2.10
2.90
4.20
1.80
2.80
4.20
Inductance
@0A
D C
(μH ±20%)
0.45
0.80
1.40
2.00
2.80
0.35
0.65
1.10
Saturation
4
Current
Isat
(A)
48
38
28
24
20
40
32
24
Heating
5
Current I
D C
(A)
45
35
27
23
19
61
45
34
Core Loss
6
Factor
K1
K2
1.68E-9
1.68E-9
1.68E-9
1.68E-9
1.68E-9
1.27E-9
1.27E-9
1.27E-9
33.5
42.5
57.8
67.6
80.1
28.7
38.1
50.1
Mechanical
X
Y
.441
11,20
Schematic
1
2
.091
2,30
.612 ± .005
15,55 ± 0,12
PG0077
PG0084
Weight
.................5.5 grams......3.5 grams
Tape & Reel............300/reel
........400/reel
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
.512 MAX
13,00
PG0077.XXX
PG0084.XXX
Date Code
Country of Origin
.165
4,20
.205 ± .005
5,20 ± 0,12
2x .197 ± .005
5,00 ± 0,12
Part Number
PG0077.401
PG0077.801
PG0077.142
PG0077.202
PG0077.282
PG0084.351
PG0084.651
PG0084.112
Max. Length
“X” (in./mm)
.571/14,50
.571/14,50
.551/14,00
.551/14,00
.551/14,00
.551/14,00
.551/14,00
.543/13,80
Max. Height
“Y” (in./mm)
.256/6,50
.256/6,50
.256/6,50
.256/6,50
.256/6,50
.173/4,40
.173/4,40
.173/4,40
Max. Height
“Z” (in./mm)
.276/7,00
.276/7,00
.276/7,00
.276/7,00
.276/7,00
.173/4,40
.173/4,40
.173/4,40
SUGGESTED PAD LAYOUT
.520
13,20
.453
11,50
.598
15,20
.945 ± .012
24,00 ± 0,30
Z
.945
24,00
TAPE & REEL LAYOUT
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
62
SPM2007 (11/07)
SMT POWER INDUCTORS
Flat Coils - PG0077NL and PG0084NL Series
Notes from Tables
1. The temperature of the component (ambient plus temperature rise) must
be within the standard operating temperature range.
2. Inductance at Irated is a typical inductance value for the component taken
at rated current.
3. The rated current listed is the lower of the saturation current @ 25°C or
the heating current.
4. The saturation current, I
SAT
, is the current at which the component
inductance drops by 20% (typical) at an ambient temperature of 25°C.
This current is determined by placing the component in the specified
ambient environment and applying a short duration pulse current (to
eliminate self-heating effects) to the component.
5. The heating current, I
DC
, is the DC current required to raise the
component temperature by approximately 40°C. The heating current is
determined by mounting the component on a typical PCB and applying
current for 30 minutes. The temperature is measured by placing the ther-
mocouple on top of the unit under test. Take note that the component’s
performance varies depending on the system condition. It is suggested
that the component be tested at the system level, to verify the
temperature rise of the component during system operation.
6. Core loss approximation is based on published core data:
Core Loss
= K1 * (f)
1.035
* (K2ΔI)
2.263
Where: Core Loss
= in Watts
f
= switching frequency in kHz
K1 & K2
= core loss factors
Δ
I
= delta I across the component in Ampere
Δ
K2ΔI
= one half of the peak to peak flux density
across the component in Gauss
7. Unless otherwise specified, all testing is made at 100kHz, 0.1V
AC
.
8. Optional Tape & Reel packaging can be ordered by adding a "T" suffix to
the part number (i.e. PG0077.401NL becomes PG0077.401NLT). Pulse
complies to industry standard tape and reel specification EIA481.
9. The "NL" suffix indicates an RoHS-compliant part number. Non-NL suffixed
parts are not necessarily RoHS compliant, but are electrically and
mechanically equivalent to NL versions. If a part number does not have the
"NL" suffix, but an RoHS compliant version is required, please contact
Pulse for availability.
Inductance vs Current Characteristics
3.0
2.5
2.0
1.5
1.0
PG0077.801
0.5
0
PG0077.401
8.5
10.5
16.5
18.5
20.5
22.5
24.5
26.5
28.5
30.5
32.5
34.5
36.5
38.5
40.5
42.5
42.5
44.5
44.6
12.5
46.5
48.5
46.5
48.5
50.6
52.5
14.5
0.5
2.5
4.5
6.5
PG0077 Series
PG0077.282
I N D U C TA N C E
(µ
H )
PG0077.202
PG0077.142
BIAS CURRENT (A)
2.8
PG0084 Series
2.4
I N D U C TA N C E
(µ
H )
2.0
1.6
1.2
PG0084.112
0.8
0.4
0
PG0084.651
PG0084.351
8.6
10.5
16.5
18.5
20.6
22.5
24.5
26.6
28.5
30.5
32.6
34.5
36.5
38.6
40.5
54.5
12.5
BIAS CURRENT (A)
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
63
56.6
58.5
14.6
0.5
2.6
4.5
6.5
SPM2007 (11/07)
